基于优化算法的压气机叶片气动设计
Aerodynamic design of compressor blade using optimization algorithm
-
摘要: 将数值最优化方法与叶轮机械正问题流场计算相结合,实现对风扇/压气机叶片积叠线、子午面流道和沿径向弦长分布组合的优化设计,数值最优化采用基于局域网的并行遗传算法.运用该软件对NASArotor67风扇转子进行重新设计,设计目标为设计点压比和流量不变、效率最高以及堵点流量不变.与原风扇转子比较,稳定工作流量范围略增大并且在整个工作流量范围内优化转子压比近于不变、效率提高约0.5个百分点.Abstract: An automatic aerodynamic optimization system for axial compressor was constructed,which was composed of turbomachinery flow field simulations in3-D Navier-Stokes equation methods,grid automatic generations,parameterizations of blade profiles,meridional channels and stacking line and the advanced parallel genetic algorithm based on intranet.In construction of objective functions,design point adiabatic efficiency,mass flow rates,pressure ratio and non-design point mass flow rates was considered.NASArotor67 was redesigned using the optimization system,and the present method successfully obtained a design that improved adiabatic efficiency by 0.5% compared with the rotor67 while satisfying mass flow rate and pressure ratio.
-
[1] Egartner W.Working range optimization for turbine and compressor blading[J].Journal of Computational and Applied Mathematics,2000,120(3):59-65. [2] Pierret S,Van den Braembussche R.A turbomachinery blade design using a Navier-Stokes solver and artificial neural network[J].Journal of Turbomachinery,1999,121(4):326-332. [3] Ahn C S,Kim K Y.Aerodynamic design optimization of a compressor rotor with Navier-Stokes analysis,proceedings of the institution of mechanical engineers[J].Part A-Journal of Power and Energy,2003,217(2):179-184. [4] Oyama A,Liou M S,Obayashi S.High-fidelity swept and leaned rotor blade design optimization using evolutionary algorithm[R].AIAA2003-4091 [5] Denton J D.The use of a distributed body force to simulate viscous effects in 3D flow calculations[R].ASME Pa-per,N0.86-GT-144,1986. [6] Anthony J S,Jerry R W,Michael D H,et al.Laser anemometer measurements in a transonic axial-flow fan rotor[R].NASA Technical Paper 2879,1989. [7] 周明,孙树栋.遗传算法原理及应用[M].北京:国防工业出版社,2001. [8] 袁晓辉,袁艳斌,王乘,等.一种新型的自适应混沌遗传算法[J].电子学报,2006,34(4):708-712.YUAN Xiaohui,YUAN Yanbin,WANG Cheng,et al.A novel self-adaptive chaotic genetic algorithm[J].Acta Electronic Sinica,2006,34(4):708-712.(in Chinese) [9] 张小华.江国和,沈荣瀛.一种自适应伪并行改进遗传算法[J].华东船舶工业学院学报,2005,19(3):65-69.ZHANG Xiaohua,JIANG Guohe,SHEN Rongying.An improved self-adaptive pseudo parallel genetic algorithm[J].Journal of East China Shipbuilding Institute (Natural Science Edition),2005,19(3):65-69.(in Chinese) [10] 周正贵,汪光文.基于数值优化方法的离心压气机工作轮气动设计[J].航空学报,2006,27(1):10-15.ZHOU Zhenggui,WANG Guangwen.Aerodynamic design of impeller using numerical optimization method[J].Acta Aeronautica et Astronautica Sinica,2006,27(1):10-15.(in Chinese)
