进口附面层对大转角弯曲扩压叶栅气动性能的影响

陈绍文; 陈浮; 王仲奇

进口附面层对大转角弯曲扩压叶栅气动性能的影响

哈尔滨工业大学能源科学与工程学院, 哈尔滨 150001

基金项目: 国家自然科学基金(50646021);高等学校博士学科点专项科研基金(20060213007)

计量
- 文章访问数: 1377
- HTML浏览量: 1
- PDF量: 452
- 被引次数: 0
出版历程
- 收稿日期: 2007-07-05
- 修回日期: 2007-10-26
- 刊出日期: 2008-07-28

Effects of inlet boundary layar on aerodynamic performance of bowed compressor cascades with large camber angle

Energy Science and Engineering School, Harbin Institute of Technology, Harbin 150001, China

摘要

摘要: 在低速条件下,对不同进口附面层厚度的大折转角环形弯曲扩压叶栅进行了实验和数值研究,分析了在不同厚度的进口附面层条件下叶片弯曲对扩压叶栅气动性能的影响.结果表明,相比实验进口附面层条件,当进口附面层较薄时,在多数冲角情况下采用正弯叶片对叶栅气动性能的改善程度都有所增大,而较大正冲角时,在较大折转角叶栅中采用较大弯角的正弯曲叶片仍然引起损失激增.
- 进口附面层 /
- 扩压叶栅 /
- 弯曲叶片 /
- 叶型折转角
Abstract: The annular bowed compressor cascads with large camber angle under different inlet boundary layers thicknesses were investigated experimentally and numerically under low-speed condition.The effects of bowed blade on aerodynamic performance of compressor cascade were analyzed under different inlet boundary layer thicknesses.The results show that,when the inlet boundary layer is getting thinner,the aerodynamic performance of cascades improves under most flow conditions.However,the total loss will rise sharply if bowed blade with bigger incidences is adopted in the cascade with larger camber angle when the bowed angle is bigger.
- inlet boundary layer /
- compressor cascade /
- bowed blade /
- camber angle

HTML

参考文献(7)

[1]	Axel F.Walter R,Joerg R S.Performance of strongly bowed stators in a 4-stage high speed compressor[R].ASME Paper GT2003-38392.
[2]	SHANG Erbing,WANG Zhongqi,SU Jiexian.The experimental investigations on the compressor cascades with leaned and curved blade[R].ASME Paper,93-GT-50.
[3]	陈浮,陈绍文,王可立,等.大折转角弯曲扩压叶栅变冲角性能研究EJ3.工程热物理学报,2006,27(2):220-222.CHEN Fu,CHEN Shaowen,WANG Keli,et al.Performance of curved compressor cascades with large camber angles at different incidences[J].Journal of Engineering Thermophysics,2006,27(2):220-222.(in Chinese)
[4]	陈绍文,陈浮,王可立,等.采用弯叶片的不同折转角压气机叶栅流场气动性能[J].推进技术,2007,28(3):170-175.CHEN Shaowen,CHEN Fu.WANG Keli.et al.Aerodynamic performance study of curved compressor cascades with different camber angles[J].Journal of PropulsionTechnology,2007,28(3):170-175.(in Chinese)
[5]	韩万今,吕卫红,卢文才,等.进口附面层对大转角弯叶片损失的影响[J].工程热物理学报,1994,15(4);391-394.HAN Wanjin,LU Weihong,LU Wencai,et al.The influence of thicknesses of inlet boundary layers on losses in cascades[J].Journal of Engineering Thermophysies,1994,15(4):391-394.(in Chinese)
[6]	Breugelmans F A E.Influence of incidence angle on the secondary flow in compressor cascade with different dihedral distribution[R].ISABE Paper 85-7078.
[7]	钟兢军,刘毓国,苏杰先,等.进口附面层厚度对弯叶片扩压叶栅损失的影响[J].工程热物理学报,1997,18(5):553-557.ZHONG Jingjun,LIU Yuguo,SU Jiexian,et al.The effects of inlet boundary layer thickness on the loss of curved blade compressor cascade[J].Journal of Engineering Thermophysics,1997,18(5):553-557.(in Chinese)
