低雷诺数条件下涡轮性能的计算研究
Study on turbine performance at low Reynolds number
-
摘要: 基于求解欧拉方程的方法,发展了能将多种不同损失模型耦合起来的涡轮S2流面准三维计算程序.并在不同雷诺数条件下对三台发动机涡轮部件性能进行了计算.计算结果表明,三套涡轮的效率及流通能力随雷诺数减小的变化量低于俄罗斯经验关联曲线所给出的变化量,但总体趋势比较吻合,不同的模型计算结果差别较大.Abstract: The Quasi-three dimensional calculation program of S2 stream surface incorporated with some different loss model is developed on the base of solving Euler equation.And the performance of 3 different sets of turbine components is calculated at different Reynolds numbers.The prediction results show that the predicted values of variations of both turbine efficiency and flow capacity with Reynolds number decreasing show smaller than that of Russia correlation,but the overall trend agrees,and the prediction results using different loss model are greatly different.
-
Key words:
- turbine performance /
- euler equation /
- S2 stream surface /
- loss model /
- reynolds number
-
[1] Bons J P,Sondergaard R,Rivir R B.Turbine separation control using pulsed vortex generator jets[J].ASME Journal of Turbomachinery,2001,123:198-206. [2] Novak R A.Streamline curvature computing procedures for fluid problems[J].ASME Journal of Engineering for Power,1961,10:478-490. [3] Marsh H.Adigital computer program for through flow fluid mechanics in an arbitrary turbomachine using a matix method[R].Aeronautical Research Council R & M No.3509,1968. [4] 傅德薰.流体力学数值模拟[M].北京:国防工业出版社.1993. [5] Ainley D G,Mathieson G C R,A method of performance estimation for axial-flow turbine[R].British Aeronautical-Research Council,R & M 2974,1951. [6] Dunham J,Came P M,Improvements to the ainley-mathieson method of turbine performance prediction[J].ASME,70-GT-2,1970. [7] Kacker S C,Okapuu U,A mean line prediction method for axial flow turbine efficiency[J].ASME 81-GT-58. [8] Traupel W.Thermische turbomaschinen[M].Berlin:Springer Verlag,1958. [9] Zehner P.Calculation of four-quadrant characteristics of turbines[R].ASME 80-GT-2. [10] Smith D J L,Johnston I H.Investigations on an exprimental single-stage turbine of conservative design[R].N.G.T.E.Report NOR.283,R.292.1967. [11] Whitney W J,Schum H J,Behning F P.Cold-air Investigation of a turbine for high-temperature-engine application,I V-Two-stage turbine performance[R].NASA TN D-3751.1972. [12] 孙大伟,乔渭阳.涡轮叶型损失模型的分析研究[C]//中国高等教育学会工程热物理专业委员会第十三届全国学术会议论文集,N0.D-07009.西安:西安交通大学,2007. [13] 李特维诺夫·尤阿.航空涡轮喷气发动机的特性和使用性能[M].北京:国防工业出版社,1968.
