航空发动机转子-滚动轴承-支承-机匣耦合系统的碰摩故障分析与验证

陈果; 李成刚; 王德友

航空发动机转子-滚动轴承-支承-机匣耦合系统的碰摩故障分析与验证

1.
南京航空航天大学民航学院, 南京 210016
2.
沈阳航空发动机设计研究所强度振动技术中心, 沈阳 110015

基金项目: 国家自然科学基金(50705042);航空科学基金(2007ZB52022)

计量
- 文章访问数: 1560
- HTML浏览量: 1
- PDF量: 479
- 被引次数: 0
出版历程
- 收稿日期: 2007-06-28
- 修回日期: 2007-09-25
- 刊出日期: 2008-07-28

Nonlinear dynamic analysis and experiment verification of rubbing faults of rotor-ball bearing-support-stator coupling system for aero-engine

1.
College of Civil Aviation, Nanjing University of Aeronautics and Astronautics, Nanjing 210016, China
2.
Strength and Vibration Technique Center, Shenyang Aero-engine Design Institute, Shenyang 110015, China

摘要

摘要: 针对实际的航空发动机转子系统,建立了含碰摩故障的转子-滚动轴承-支承-机匣耦合动力学模型.在模型中,考虑了机匣运动,弹性支承、挤压油膜阻尼,充分考虑了轴承间隙、滚珠与滚道的非线性赫兹接触力以及由滚动轴承支撑刚度变化而产生的变柔性(VaryingcomplianceVC)振动.运用数值积分方法获取了系统响应,并建立带机匣的航空发动机转子实验器进行碰摩故障实验,仿真结果与实验结果比较分析表明了模型的有效性.
- 航空发动机 /
- 转子 /
- 滚动轴承 /
- 弹性支承 /
- 机匣 /
- 碰摩
Abstract: Anew rotor-ball bearing-support-stator coupling system dynamic model including rubbing fault was established for rotor-bearing system of practical aeroengine.In the model,the stator motion,the flexible support,squeeze film damper(SFD) were considered,and the nonlinear factors of ball bearing such as the clearance of bearing,nonlinear Hertzian contract force between balls and races,and the varying compliance vibration because of periodical variety of contact position between balls and races were modeled.The numerical integral method was employed to obtain system's responses,and an aeroengine tester with stator was established to carry out rubbing fault experiment.Finally,the simulation results from rotor-ball bearing-support-stator coupling model were compared with the experiment results in order to indicate the validity of the new model.
- aero-engine /
- rotor /
- ball bearing /
- flexible support /
- stator /
- rubbing
