叶片内部蒸汽冷却的数值模拟
Numerical simulation of a steam-cooled vane
-
摘要: 在某燃气轮机第二级导向叶片的基础上,对叶片内部进行了设计并采用内部蒸汽冷却方式.采用非结构化网格和Realizable k-ε紊流模型,对同时带15°,30°和45°肋的叶片内外流场以及叶片本身进行了三维热耦合的定常数值模拟.热耦合采用在流固耦合面的热对流和固体导热来实现.内部冷却介质选用比空气热容大,粘度低的水蒸汽.结果表明:带肋的通道流场非常复杂,扰流肋的存在使各壁面的换热都得到了增强,相对于光滑通道换热显著,有明显的冷却痕迹,冷却效果明显;采用蒸汽冷却比用空气冷却效果要好;压力面温度普遍低于吸力面温度.Abstract: The steam cooling method was applied in this paper to study the design and characteristics of cooling structure for a vane of gas turbine.The unstructured meshes and realizable k-ε turbulence model were used to study the flow behaviors both inside and outside the grid-ribbed rectangular channel with 15°,30° and 45° rib-roughened wall through 3-Dcoupled numerical simulation.Coupling heat exchange was achieved by heat transfer and solid conduction on the coupled-side of fluid and solid.The cooling medium was steam which had greater Cp and lower viscidity than air.Results show that the flow of the passage is very complex.Heat transfer is enhanced because of the ribs.Ribbed wall has better heat transfer effect than the no rib wall and the cooling effect is obvious.Cooling effect is better by using the steam than by using the air.The numerical result shows the temperature on pressure surface is lower than suction surface.
-
Key words:
- steam cooling /
- heat coupled /
- rib /
- numerical simulation
-
[1] Facchini B,Ferrara G,Innocenti L.Blade cooling improvement for heavy duty gas turbine:the air coolant temperature reduction and the introduction of steam and mixed steam/air cooling[J].Int,J,Therm.Sci.,2000,39:74-84. [2] Kruger U,Kusterer K,Lang G.Analysis of the influence of cooling steam conditions on the cooling efficiency of a steam-cooled vane using the conjugate calculation technique[R].ASME Turbo Expo 2001-GT-0166. [3] 胡宗军,吴铭岚.采用蒸汽冷却的各种燃气轮机循环性能分析[J].上海交通大学学报,1999,33(3):335-338.HU Zongjun,WU Minglan.Performance analysis of various gas turbine cycles using steam cooling[J].Journal of Shanghai Jiao Tong University,1999,33(3):335-338.(in Chinese) [4] 李海滨,冯国泰,王松涛,等.涡轮三维叶栅的气热耦合数值模拟[J].工程热物理学报,2003,24(5):770-772.LI Haibin,FENG Guotai,WANG Songtao,et al.Numerical simulation method of aerodynamigs-themodynamics coupling in 3-D turbine cascade[J].Journal of Engineering Thermophysics,2003,24(5):770-772.(in Chinese) [5] 张勃,吉洪湖,张靖周,等.网格式肋化通道换热与总压损失特性研究[J].航空动力学报,2004,19(2):201-205.ZHANG Bo,Jl Honghu,ZHANG Jingzhou,et al.Experimental study of heat transfer and total pressure drop of a grid-ribbed rectangular channel[J].Journal of Aerospace Power,2004,19(2):201-205.(in Chinese) [6] 董威,黄维娜.某型发动机涡轮冷却叶片的流动换热耦合计算研究[J].燃气涡轮实验与研究,2006,19(2):14-17.DONG Wei,HUANG Weina.Coupled computation study of the cooling turbine blade[J].Gas Turbine Experiment and Research,2006,19(2):14-17.(in Chinese) [7] 董瑜,郑洪涛,杨凡.蒸汽冷却叶片耦合传热的数值模拟[R].南京:中国航空学会第六届动力年会,2006,CSAA 06-P-116. -
