利用小孔射流改善气膜冷却效率的数值研究

蒋永健; 何立明; 苏建勇; 于锦禄

利用小孔射流改善气膜冷却效率的数值研究

1.
空军工程大学工程学院, 西安 710038
2.
空军飞行试验训练基地, 沧州 061000

基金项目: 国家自然科学基金(50276070)

计量
- 文章访问数: 1804
- HTML浏览量: 224
- PDF量: 448
- 被引次数: 0
出版历程
- 收稿日期: 2007-07-24
- 修回日期: 2007-11-20
- 刊出日期: 2008-08-28

Numerical investigation on improvement of film cooling effectiveness with small coolant jets

1.
The Engineering Institute, Air Force Engineering University, Xi'an 710038, China
2.
Air Force Flight-Test Training Base, Cangzhou 061000, China

摘要

摘要: 为了获得气膜孔下游放置一对射流小孔对气膜冷却效率的影响规律,采用数值模拟方法研究了不同吹风比下射流小孔出口位置尺寸不同时流动过程和冷却效率的分布情况,并与常规气膜孔冷却结构形式进行对比,以揭示小孔射流改善气膜冷却效率的作用机理.研究表明:在常规气膜孔下游开两个射流小孔后,两射流小孔分别产生一个较弱的与气膜孔反向涡对方向相反的反向涡对,反向涡对的相互作用减弱了气膜孔反向涡对的强度,使气膜的贴壁效果更好,提高了气膜孔的冷却效率.在各吹风比条件下,气膜孔下游有射流小孔时,冷却效率都有一定的提高,并且射流小孔间距较大时对两气膜孔中心线之间的横向平均冷却效率改善较大,吹风比较大时,效果更明显.
- 气膜冷却 /
- 射流 /
- 流动传热
Abstract: To investigate the influence of small coolant jets on film cooling effectiveness,the distributions of the flow fields and cooling effectiveness with the small jets at different outlet placement under several blowing ratios were numerically studied.And the distributions were compared with the distributions of the baseline holes to reveal the good effects of the small coolant jets on the film cooling performance.The results show that,the new interaction between the weaker counter-rotating vortex pairs(CRVP) generated by the small jets and the CRVPgenerated by the main coolant jet weakens the mixing strength of the coolant jets with the hot cross flow,so the film effectiveness is higher with better coverage on the hot side under several blowing ratios.And the spanwise cooling effectiveness is improved significantly when the distance between the two small coolant jets is longer and the blowing ratio is higher.
- film cooling /
- jet /
- flow and heat transfer

HTML

参考文献(11)

[1]	Bunker R S.Film cooing effectiveness due to discrete holes with a transverse surface slot[R].ASME Paper GT-2002-30178,2002.
[2]	Wang T,Chintalapati S,Bunker R S,et al.Jet mixing in a slot[J].Experimental Thermal and Fluid Science,2000,22:1-17.
[3]	Schmidt D,Sen B,Bogard D.Film cooling with compound angle holes:adiabatic effectiveness[J].Journal of Turbomachinary,1996,118:807-813.
[4]	朱惠人,许都纯,刘松龄.气膜孔形状对排孔下游冷却效率的影响[J].航空学报,2002,23(1):75-78.ZHU Huiren,XU Duchun,LIU Songling.Effects of hole shape on film cooling effectiveness[J].Acta Aeronautic et Astronautic Sinica,2002,23(1):75-78.(in Chinese)
[5]	林宇震.燃烧室多斜孔壁气膜冷却研究[D].北京:北京航空航天大学,1997.
[6]	Nasir H,Acharya S,Ekkad S.Improved film cooling from cylindrical angled holes with triangular tabs:effect of tab orientations[J].International Journal of Heat and Fluid,2003,24:657-668.
[7]	李永康,张靖周,姚玉.利用三角形突片改善气膜冷却效率的数值研究[J].航空动力学报,2006,21(1):83-87.LI Yongkang,ZHANG Jingzhou,YAO Yu.Numerical investigation on improvement of film cooling effectiveness using delta-shaped tabs[J].Journal of Aerospace Power,2006,21(1):83-87.(in Chinese)
[8]	Yiping Lu,Hasan Nasir,Ekkad S V.Film cooling from a row of holes embedded in transverse slots[R].ASME Paper GT2005-68598,2005.
[9]	Na S,Shih T I P.Increasing adiabatic film cooling effectiveness by using an upstream ramp[R].ASME Paper GT2006-91163,2006.
[10]	Javadi K,Taeibi-Rahni M,Darbandi M.Jet into cross flow boundary layer control an innovation in gas turbine blade cooling[R].35th AIAA Fluid Dynamics Conference,AIAA 2005-5272,2005.
[11]	Leylek J H,Zerkle R D.Discrete jet film cooling:a comparison of computational results with experiments[J].ASME Journal of Turbomachinery,1994,116:358-368.
