倾转旋翼机传动系统多状态响应特性研究

基金项目: 航空科学基金(2006ZB53016)

Dynamic response analysis of the transmission of tilt-rotor in different modes

School of Mechatronics, Northwestern Polytechnical University, Xi′an 710072, China

摘要: 以倾转旋翼机发动机短舱内的传动系统为研究对象,根据设计的传动结构建立了它的动力学模型和动态响应方程,分析了倾转旋翼机旋翼在起降、巡航和过渡三种状态下的激励特性,并针对三种状态下旋翼激励的特点对传动系统动态响应进行了数值求解,最后研究了传动系统中齿轮啮合的动载系数的变化特点,并对系统的共振频率进行了探讨.研究工作对倾转旋翼机的传动系统的可靠性分析和动态优化设计等均有参考意义.
- 倾转旋翼机 /
- 传动系统 /
- 激励 /
- 动载系数 /
- 共振频率
Abstract: Based the transmission structure in the nacelle of tilt-rotor,the complex gears and shafts coupling dynamic modeling and dynamic response equations were built.And,three types of the force characteristics on the blades: cruise,hover and transition were analyzed.The dynamic response was computed using Runge-Kutta method to obtain the dynamic gearmesh coefficient.Finally,the natural frequency was discussed.The results provide some useful information to analyze the reliability and the dynamics optimization of the transmission.
- tilt-rotor /
- transmission /
- response /
- dynamic coefficient /
- natural frequency

[1]	杨军,吴希明,凡永华,等.倾转旋翼机飞行控制[M].北京:航空工业出版社,2006.
[2]	徐敏.发展我国的倾转旋翼机[C]//第十八届全国直升机年会论文集.[s.l.]:中国航空学会直升机专业分会,2002:19-22.
[3]	Rollet P.RHILP-A major step for european knowledge in tilt-rotor aeromechanics and flight dynamics[J].Air & Space Europe,2001,3(3):152-154.
[4]	孙之钊.直升机强度[M].北京:航空工业出版社,1990.
[5]	Chaari F,Hbaeib R,Fakhfakh T,et al.Dynamic response simultation of planetary gears by the iterative spectral method[J],Int.J.Simul.Mode,2005,4(1):35-45.
[6]	Kahraman A.Free torsional vibration characteristics[J].Mechanism and Machine Theory,2001,36,953-937.
[7]	Barkai S M,Rand O.Modeling and analysis of tilt-rotor aeromechanical phenomena[J].Mathl.Gomput.Modelling,1998,27,(12):17-43.
