梯形突片气膜冷却特性的实验

Experimental study on cooling characteristics of film cooling with trapezoid tabs

College of Power and Energy Engineering, Nanjing University of Aeronautics and Astronautics, Nanjing 210016, China

摘要: 为了研究突片对气膜冷却的影响规律,设计了3种不同堵塞比的梯形突片,采用红外摄像仪对不同形状突片冷却结构的壁面温度场进行了测试,并对气膜冷却特性的影响规律进行了实验研究.研究结果表明,与无突片的气膜冷却相比,突片的存在大大提高了气膜冷却效率和对流换热系数;冷却效率沿气流方向存在一个最佳吹风比值;对流换热系数在本实验范围内,堵塞比为0.214时气膜冷却对流换热系数最大.
- 突片 /
- 冷却效率 /
- 换热系数 /
- 气膜冷却
Abstract: In order to study the effect of tabs on film cooling,three test pieces with different geometrical dimensions were designed,and the infrared camera was used to measure the temperature distribution on the wall.The cooling characteristics was experimentally studied.The results show that the efficiency of film cooling and the convective heat transfer coefficient of film cooling with tabs have improved markedly in the presence of tabs.The cooling efficiency has an optimal blowing ratio value along the streamwise direction;while the blockage ratio is 0.214,the convective heat transfer coefficient reaches its maximum value in the range of the experiment.
- tab /
- cooling efficiency /
- heat transfer coefficient /
- film cooling

[1]	葛绍岩,刘登瀛,徐靖中,等.气膜冷却[M].北京:科学出版社,1985.
[2]	Nasir H,Acharya S,Ekkad S.Improved film cooling from cylindrical angled holes with triangular tabs:effect of tab orientation[J].Internatianal Journal of Heat and Fluid Flow,2003,24:657-668.
[3]	Jia R,Sunden B,Miro P,et al.Numerical and experimental study of the slot film cooling jet with various angles[C]// Proceeding of the ASME Summer Heat Transfer Conference.Lasvegas:[s.n.],2003:845-856.
[4]	Bradbury L J,Khadem A H.The distortion of a jet by tabs[J].Journal of Fluid Mechnics,1975,70(4):801-813.
[5]	Zaman K B M Q.Reduction of jet penetration in a cross-flow by using tabs[R].AIAA Paper 98-3276.
[6]	Zaman K B M Q.Effect of oscillating tabs on a jet-in-cross-flow[R].AIAA Paper 2003-0632.
[7]	杨卫华,李永康,张靖周,等.突片作用下气膜冷却效率的实验研究[J].航空动力学报,2007,22(3):381-383.YANG Weihua,LI Yongkang,ZHANG Jingzhou,et al.Experimental study of cooling efficient of film cooling with tab[J].Journal of Aerospace Power,2007,22 (3):381-383.(in Chinese)
[8]	杨卫华,马国锋,张靖周.突片作用下气膜冷却对流传热特性的试验研究[J].航空动力学报,2006,21(6):978-983.YANG Weihua,MA Guofeng,ZHANG Jingzhou.Experimental study on convective heat transfer characteristics of film cooling with tab[J].Journal of Aerospace Power,2006,21(6):978-983.(in Chinese)
