气膜孔形状对导叶冷却效果影响的数值研究

姚玉; 张靖周; 郭文

气膜孔形状对导叶冷却效果影响的数值研究

南京航空航天大学能源与动力学院, 南京 210016

计量
- 文章访问数: 1716
- HTML浏览量: 173
- PDF量: 483
- 被引次数: 0
出版历程
- 收稿日期: 2007-09-12
- 修回日期: 2007-12-06
- 刊出日期: 2008-09-28

Numerical study of cooling effectiveness of different film cooling holes on stator blade

College of Energy and Power Engineering, Nanjing University of Aeronautics and Astronautics, Nanjing 210016, China

摘要

摘要: 根据导向叶片的曲面结构,运用剪应力输运方程(SST)湍流模型,针对簸箕形、锥形和缝形气膜孔的流场和冷却特性同圆形气膜孔进行了对比研究.研究结果为:随着冷气入口压力的增加,各种冷却结构的冷却效果也在增加;而在相同的冷气入口压力条件下,各种形状气膜孔的冷却流量和冷却效果不尽相同,在该研究条件下,簸箕形和缝形气膜孔的冷却效果最好,锥形孔次之.
- 涡轮叶片 /
- 气膜冷却 /
- 数值计算
Abstract: The flow field and film cooling characteristics on the blade surface were numerically investigated using the shear-stress transport(SST) two-equation turbulent model,so as to understand the influences of film-cooling holes on cooling effectiveness.The flow and cooling effectiveness for four configurations of film cooling holes were compared.Results show that the cooling effectiveness for each film cooling hole increases with the increment of the coolant entrance total pressure.Under the same coolant entrance total pressure,the cooling effectiveness of the dustpan and slot film cooling holes are the best,followed by that of the taper film cooling hole.
- turbine blade /
- film cooling /
- numerical computation

HTML

参考文献(10)

[1]	Sargison J E,Guo S M,Oldfield M L G,et al.A converging slot-hole film-cooling geometry.Part 1:Low-speed flat-plate heat transfer and loss[R].ASME Turbo Expo No.2001-GT-0126,2001.
[2]	Nasir H,Acharya S,Ekkad S.Improved film coolingfrom cylindrical angled holes with triangular tabs:Effect of tab orientations[J].International Journal of Heat and Fluid Flow,2003,24; 657-668.
[3]	Goldstein R J,Eckert E R G,Burggraf B.Effects of hole geometryand desity on three-dimensional film cooling[J].International Journal of Heat and Mass Transfer,1992,17:595-607.
[4]	sehmidt D,Sen B,Bogard D.Film cooling with compound angle holes:Adiabatic effectiveness[J].Journal of Turbomachinary,1996,118:807-813.
[5]	朱惠人,许都纯,刘松龄,等.簸箕形排孔气膜冷却实验研究[J].航空学报,1997,18(5):535-538.ZHU Huiren,XU Duchun,LIU Songling,et al.Film cooling experimental investigation of a row of dust-pan shaped holes[J].Chinese Journal of Aeronautics,1997,18(5):535-538.(in Chinese)
[6]	李永康.张靖周,姚玉.利用三角形突片改善气膜冷却效率的数值研究[J].航空动力学报,2006,21(1):83-87.LI Yongkang,ZHANG Jingzhou,YAO Yu.Numerical investigation on improvement of film cooling effectiveness using delta-shaped tabs[J].Journal of Aerospace Power,2006,21(1):83-87.(in Chinese)
[7]	郭婷婷,刘建红,宋东辉,等.不同形状气膜孔对气膜冷却效果的影响[J].动力工程,2006,26(3):333-336.GUO Tingting,LIU Jianhong,SONG Donghui,et al.Influence of jet orifice geometry on film-cooling effectiveness[J].Journal of Power Engineering,2006,26(3):333-336.(in Chinese)
[8]	刘江涛,吴海玲,陶涛,等.斜孔气膜冷却数值模拟分析[J].工程热物理学报,2004,25(6):1034-1036.LIU Jiangtao,WU Hailing,TAO Tao,et al.Numerical simulation of film cooling[J].Journal of Engineering Therrnophysics,2004,25(6):1034-1036.(in Chinese)
[9]	陶文铨.数值传热学[M].西安:西安交通大学出版社,1992.
[10]	曹玉璋,陶智,徐国强,等.航空发动机传热学[M].北京:北京航空航天大学出版社,2005.
