有无内部对流换热对导叶冷却效果影响的数值研究

姚玉; 张靖周; 郭文

有无内部对流换热对导叶冷却效果影响的数值研究

1.
南京航空航天大学能源与动力学院, 南京 210016
2.
中国燃气涡轮研究院, 成都 610500

计量
- 文章访问数: 1800
- HTML浏览量: 273
- PDF量: 420
- 被引次数: 0
出版历程
- 收稿日期: 2007-09-12
- 修回日期: 2007-12-06
- 刊出日期: 2008-09-28

Numerical investigation on film cooling effectiveness of stator blade with or without heat transfer

1.
College of Energy and Power Engineering, Nanjing University of Aeronautics and Astronautics, Nanjing 210016, China
2.
China Gas Turbine Establishment, Chengdu 610500, China

摘要

摘要: 根据导向叶片的曲面结构,运用剪应力输运方程(SST)湍流模型,在不同冷气入口压力条件下,对涡轮叶栅通道内部的三维流场和圆形气膜孔叶片型面的冷却效果进行了数值模拟.计算针对两种情形,即叶片内部有对流换热的情形和无对流换热的情形,结果表明随着冷气入口压力的增加,叶片有无内部对流换热的冷却效果也在增加;有内部对流换热的冷却效果较纯气膜冷却的高,尤其是在叶片前缘.
- 涡轮叶片 /
- 涡轮叶栅 /
- 气膜冷却 /
- 数值计算
Abstract: The film cooling effectiveness on the blade surface under different coolant entrance pressures was numerically investigated using the shear-stress transport(SST) two-equation turbulent model,so as to understand the influences of film-cooling holes on cooling effectiveness.Three-dimensional turbulent flow in the turbine cascade and the cooling effectiveness on the blade surface with cylindrical film cooling hole were simulated in two cases: with/without heat transfer in the blade.The results show that the cooling effectiveness increases with the increment of the coolant entrance total pressure,and the cooling effectiveness with heat transfer in the blade is better than that without heat transfer in the blade,especially in the leading edge region.
- turbine blade /
- turbine cascade /
- film cooling /
- numerical computation

HTML

参考文献(9)

[1]	Farmer J P,Seager D J,Liburdy J A.The effect of shaping inclined slots on film cooling effectiveness and heat transfer coefficient[R].ASME Paper No.97-GT-399,1997.
[2]	Juhran B A,Maiteh B Y.Film cooling and heat transfer from a combination of two rows of simple and/or compound angle holes in inline and/or staggered configuration[J].Heat and Mass Transfer,1999,34(6):495-502.
[3]	Sargison J E,GuoSM,Oldfield M L G,et al.Aconverging slot-hole film-cooling geometry Part 1:Low-speed flat-plate heat transfer and loss[R].ASME Turbo Expo No.2001-GT-0126,2001.
[4]	Yu Y,Yen C H,Shih T I P.Film cooling effectiveness and heat transfer coefficient distributions around diffusion shaped holes[J].ASME Journal of Heat Transfer,2002,124(5):820-827.
[5]	姚玉,张靖周,李永康.带三角形突片气膜冷却结构换热特性的数值研究[J].航空动力学报,2006,21(4):658-662.YAO Yu,ZHANG Jingzhou,LI Yongkang.Numerical investigation on heat transfer of film cooling with deltashaped tabs[J].Journal of Aerospace Power,2006,21 (4):658-662.(in Chinese)
[6]	徐红洲,苏红桢,刘松龄.倾斜锥形喷孔气膜冷却的流动和传热实验研究[J].推进技术,1996,17(5):52-58.XU Hongzhou,SU Hongzhen,LIU Songling.An experimental study on flow and heat transfer around a single cone-shaped film cooling hole with inclined angle of 30°[J].Journal of Propulsion Technology,1996,17(5):52-58.(in Chinese)
[7]	陶文铨.数值传热学[M].西安:西安交通大学出版社,1992.
[8]	葛绍岩,刘登瀛,徐靖中,等.气膜冷却[M].北京:科学出版社,1985.
[9]	曹玉璋,陶智,徐国强,等.航空发动机传热学[M].北京:北京航空航天大学出版社,2005.
