半封闭肋化通道射流冲击的实验

谭蕾; 张靖周; 杨卫华

半封闭肋化通道射流冲击的实验

1.
南京航空航天大学航天学院, 南京 210016
2.
南京航空航天大学能源与动力学院, 南京 210016

计量
- 文章访问数: 1761
- HTML浏览量: 208
- PDF量: 436
- 被引次数: 0
出版历程
- 收稿日期: 2007-08-01
- 修回日期: 2007-11-07
- 刊出日期: 2008-09-28

Experimental research on jet impingement inside semi-confined rib-roughed channel

1.
College of Astronautics, Nanjing University of Aeronautics and Astronautics, Nanjing 210016, China
2.
College of Energy and Power Engineering, Nanjing University of Aeronautics and Astronautics, Nanjing 210016, China

摘要

摘要: 运用红外热像测试技术对半封闭肋化通道单排孔射流冲击进行了热像显示实验,揭示出射流雷诺数、冲击间距、肋型排布方式对传热特性的影响规律,并开展了冲击孔流量系数的研究.结果表明:在本文研究范围内,冲击间距与孔径比Zn/d=1时壁面射流区换热效果最好;V型肋化通道在壁面射流区获得了最佳换热效果;冲击孔流量系数随雷诺数增加而变大;在其它工况相同的情况下,V型顺流肋化通道内冲击孔流量系数最大.
- 冲击冷却 /
- 粗糙肋 /
- 强化传热 /
- 热显示 /
- 流量系数
Abstract: Thermal visualization of jet impingement inside semi-confined rib-roughed channel was tested by thermograph to investigate the effects of impinging Reynolds number,jet-to-surface spacing as well as the ribs arrangement on heat transfer characteristics.The discharge coefficient for jet impingement was also analyzed.Results show that the impingement cooling effectiveness of ribbed surface is affected extremely by the jet-to-surface spacing,and the best effectiveness is achieved under the jet-to-surface space equaling to 1;the rib pattern also exerts great impact on cooling effectiveness,in present research the V-shaped ribs have best performance;the discharge coefficient is enhanced with the increase of impinging Reynolds number and the best result is obtained in V-up channel.
- impingement cooling /
- rib /
- enhanced heat transfer /
- thermal visualization /
- discharge coefficient

HTML

参考文献(10)

[1]	顾维藻,神家锐,马重芳,等.强化传热[M].北京:科学出版社,1992.
[2]	张靖周,李永康,谭晓茗.阵列射流冲击冷却局部对流换热特性的数值计算与试验验证[J].航空学报,2004,25(4):339-342.ZHANG Jingzhou,LI Yongkang,TAN Xiaoming.Numerical computation and experimental investigation on convective heat transfer characteristics for jet array impingement[J].Acta Aeronautica et Astronautica Sinica,2004,25(4):339-342.(in Chinese)
[3]	ZHANG Jingzhou,LI Liguo.High resolution heat transfer coefficient measurement for jet impingement using thermochromic liquid crystals[J].Chinese Journal of Aeronatics,2001,14(4):205-209.
[4]	张泽远,张靖周,杨卫华.半封闭通道射流冲击换热特性的实验[J].航空动力学报,2006,21(4):626-630ZHANG Zeyuan,ZHANG Jingzhou,YANG Weihua.Convective heat transfer of jet impingement inside semiconfined channel[J].Journal of Aerospace Power,2006,21(4):626-630.(in Chinese)
[5]	许全宏,林宇震.刘高恩.封闭空间内单孔冲击局部换热特性研究[J].航空动力学报,2002,17(3):341-343.XU Quanhong,LIN Yuzhen,LIU Gaoen.Investigation of impingement heat transfer of single hole in a limited space[J].Journal of Aerospace Power,2002,17(3):341-343.(in Chinese)
[6]	Tanda G.Heat transfer in rectangular channels with transverse and V-shape broken ribs[J].International Journal of Heat and Mass Transfer,2004,47:29-243.
[7]	Karwa R.Experimental study of augmented heat transfer and friction in asymmetrically heated rectangular ducts with ribs on the heated wall in transverse,inclined,Vcontinuous and V-discrete pattern[J].International Journal of Heat and Mass Transfer,2003,30(2):241-250.
[8]	Han J C,Glicksman L R,Roshenow W M.An investigation of heat transfer and friction for rib-roughened surfaces[J].International Journal of Heat and Mass Transfer,1978,21:1143-1156
[9]	Han J C,Park J S.Developing heat transfer in rectangular channels with rib turbulators[J].Journal of Heat &Mass Transfer,1988,31(1):183-195.
[10]	Kim H M,Kim K Y.Design optimization of rib-roughened channel to enhance turbulent heat transfer[J].International Journal of Heat and Mass Transfer,2004,47:5159-5168.
