轴流压气机对周向总压畸变非定常响应的数值模拟

黄健; 吴虎; 张晓东; 党春宁

轴流压气机对周向总压畸变非定常响应的数值模拟

1.
西北工业大学动力与能源学院, 西安 710072
2.
第二炮兵工程学院, 西安 710025

基金项目: 国家自然科学基金(10377013)

计量
- 文章访问数: 1948
- HTML浏览量: 433
- PDF量: 418
- 被引次数: 0
出版历程
- 收稿日期: 2007-09-07
- 修回日期: 2007-11-10
- 刊出日期: 2008-09-28

Numerical investigation of the response of axial flow compressor to circumferential total pressure distortion

1.
School of Power and Energy, Northwestern Polytechnical University, Xi'an 710072, China
2.
The Second Artillery Engineering Institute, Xi'an 710025, China

摘要

摘要: 基于给定的进气周向总压畸变谱,应用非定常三维时间精确数值计算的方法,研究了NWPU-1轴流压气机转子对周向总压畸变的响应,初步揭示了其在进气周向总压畸变条件下的失速机理.结果表明,在84%设计转速,进气周向总压畸变使转子性能明显下降,其失速点流量增加了4.1%,效率下降了0.5%.进气周向总压畸变引起侧流,导致叶片负荷的变化,部分叶片的负荷过重,叶顶间隙泄漏涡几乎堵塞了整个通道,某些叶片的前缘出现溢流,最终导致压气机转子失速.
- 周向压力畸变 /
- 非定常响应 /
- 数值计算 /
- 轴流压气机 /
- 气动稳定性
Abstract: Based on the given circumferential total pressure distortion of steady inlet flow,the response of an axial flow compressor rotor to the circumferential total pressure distortion of steady inlet flow was investigated numerically using 3-Dtime-accurate unsteady algorithm with the help of NWPU-1 axial flow compressor rig.The results show that,at 84 percent of design speed,the overall performance of compressor rotor is reduced due to distortion,with inlet flow circumferential distortion,the efficiency of ompressor rotor is decreased by 0.5 percent and the equivalent weight flow increases by 4.1 percent at near-stall condition if compared with clean inlet flow.Circumferential flow redistribution due to distortion tends to make the load of several blades too high,the blockage zone caused by tip leakage vortex is full of the whole passage,leading to the occurrence of stall.
- circumferential pressure distortion /
- unsteady response /
- axial flow compressor /
- numerical investigation /
- aerodynamic stability

HTML

参考文献(10)

[1]	Hah C.Effects of inlet distortion on the flow field in a transonic compressor rotor[J].ASME J.Turbomachinary,1998,120:233-246.
[2]	Rabe D.Influence of inlet distortion on transonic compressor blade loading[R].AIAA Paper 95-2461.
[3]	Marshall J G.Prediction of low engine order inlet distortion driven response in a low aspect ratio fan[R].ASME Paper 2000-GT-0374.
[4]	Mokelke H.The prediction of steady,circumferential pressure and temperature distortions in multistage axial flow compressors[J].ASME J.for Power,1980,102:448-458.
[5]	Camp T R,Day I J.A study of spike and modal stall phenomena in a low-speed axial compressor[J].ASME J.Turbomachinery,1998,120:393-401.
[6]	Vo H D,Tan C S,Greitzer E M.Criteria for spike initiated rotating stall[R].ASME GT2005-68374,2005.
[7]	梁武昌.楚武利,朱俊强,等.非轴对称尖部间隙对轴流压气机性能影响的实验研究[J].航空动力学报,2004,19(2):233-236.LIANG Wuchang,CHU Wuli,ZHU Junqiang,et al.Effects of asymmetric tip clearance on axial flow compressor performance[J].Journal of Aerospace Power,2004,19(2) ;233-236.(in Chinese)
[8]	卢新根.轴流压气机内部流动失稳及其被动控制策略研究[D].西安:西北工业大学,2007.LU Xingen.Flow instability and its passive control strategies in axial-flow compressor[D].Xi'an:Northwestern Polytechnical University,2007.(in Chinese)
[9]	卢新根,楚武利,朱俊强,等.轴向斜缝机匣处理与转子通道之间耦合流动分析[J].工程热物理学报,2006,27(2):226-228.LU Xingen,CHU Wuli,ZHU Junqiang,et al.Analysis of the coupled flow through the axial skewed slots casing treatment and rotor passage[J].Journal of Engineering Thermophysica,2006,27(2):226-228.(in Chinese)
[10]	胨涛,徐纲,徐燕骥,等.总压进口畸变与失速裕度相互关联非定常特征的数值模拟[J].工程热物理学报,2004,25(3):399-401.CHEN Tao,XU Gang,XU Yanji,et al.Numerical simulation of unsteady characteristic interaction between total pressure inlet distortion and stall margin[J].Journal of Engineering Tharmophysics,2004,25 (3):399-401.(in Chinese)
