叶片数对微型斜流叶轮性能的影响

陈杰; 黄国平; 梁德旺; 刘玉石

叶片数对微型斜流叶轮性能的影响

南京航空航天大学能源与动力学院, 南京 210016

计量
- 文章访问数: 1668
- HTML浏览量: 118
- PDF量: 421
- 被引次数: 0
出版历程
- 收稿日期: 2007-09-16
- 修回日期: 2007-11-24
- 刊出日期: 2008-09-28

Effects of blade number on performance of micro slope impeller

College of Energy and Power Engineering, Nanjing University of Aeronautics and Astronautics, Nanjing 210016, China

摘要

摘要: 采用计算流体力学软件NAPA对叶片数不同的跨声微型斜流叶轮流场、性能进行了模拟,研究表明随着叶片数的增加,叶片载荷减小,叶背分离减小,叶片通道内流动改善,但叶片进口低压区域占叶片通道的比例增大,当叶片数增加到一定程度时主叶片不能全程加载.随叶片数的增加叶轮工作特性曲线左移的同时先上移后下移,通过与常规离心压气机最佳叶片数研究结果的对比表明,低雷诺数、微尺度效应及叶片占通道比例大使所研究微型斜流压气机的最佳叶片数略低于已有经验.
- 微型斜流叶轮 /
- 叶片数 /
- 数值模拟
Abstract: The results of a study for identifying optimum blade number of a transonic micro slope impeller with splitters were presented.An in-house-developed Navier-Stokes flow code was applied to the study.By increasing the blade,the blade load and separation on suction surface was decreased,and the internal flow was improved,but the low pressure zone was expanded in the entryway.In the event of excessive number of the blades,the full blade cannot work from the leading edge to the trail edge.Along with the augment of the blade number,the impeller performance curves move up and then down.As compared with the experience gained in the study of normal centrifugal compressor,the optimal blade number of the micro impeller is lesser.The lower Reynolds number,the effects of micro-scale and the biggish relative thickness of blade are contributing factors to produce the difference in optimal blade number.
- micro slope impeller /
- blade number /
- CFD(computational fluid dynamics)

HTML

参考文献(9)

[1]	Epstein A H.Millimeter-scale,MEMS gas turbine engines[R].Atlanta,Proceedings of ASME Turbo Expo 2003,No.GT-2003-38866.
[2]	Gerendas M.Development of a very small aero-engine[R].Munich:Proceedings of ASME Turbo Expo 2000,No.2000-GT-0536.
[3]	陈杰,黄国平,梁德旺.微型离心压气机叶轮设计与性能数值分析[R].太原:推进系统气动热力学第十届学术交流会议,2005.
[4]	Harris M M,Jones A C,Alexander E J.Miniature turbojet development at hamilton sundstrand the TJ-50,TJ-120 and TJ-30 turbojets[R].AIAA 2003,No.2003-6568.
[5]	罗晟,蔡兆麟.变叶片数和长短叶片结构对离心叶轮内三维粘性流场的影响[J].风机技术.2000,(6):3-6.LUO Sheng,CAI Zhaolin.Changing blade number and long-short blade structure to the effect of 3-D viscous flow field in centrifugal impeller[J].Compressor Blower and Pan Technology,2000,(6),3-6.(in Chinese)
[6]	刘瑞韬,徐忠.叶片数及分流叶片位置对压气机性能的影响[J].工程热物理学报,2004,25(2):223-225.LIU Ruitao,XU Zhong.Effect of blade number and splitter blade position on the performance characteristic of the compressor[J].Journal of Engineering Thermophysics,2004,25(2):223-225.(in Chinese)
[7]	Galvas M R.Analytical correlation of centrifugal compressor design geometry for maximum efficiency with specific speed[R].NASA TN D.6729,1972.
[8]	Rodgers C.Effects of blade number on the efficiency of centrifugal compressor impellers[R].Munich,Germy:Proceedings of ASME Turbo Expo 2000,2000-GT-455,2000.
[9]	徐忠.离心式压缩机原理[M].北京:机械工业出版社,1990.
