扩展型面排孔气膜冷却的实验
Film cooling experiment of row of expanded shape holes
-
摘要: 设计了三种型面的气膜孔扩展结构,研究了气膜冷却效率、壁面换热系数及流量系数随吹风比的变化规律.研究结果表明,与典型的圆柱形气膜孔相比,有后向扩展型面的气膜孔具有相对较高的冷却效率和换热系数,流量系数略有降低.扩展型面的流向扩展角对冷却效率和换热系数的影响大于侧向扩展角的影响.侧向扩展角只在特定吹风比下才对提高气膜的侧向覆盖率、进而提高气膜冷却效率起作用,它使得位于二次流出流下游的低压区域范围增大,流量系数减小.Abstract: Three types of expanded shape film-cooling holes were designed to study the change of the film cooling efficiency,heat transfer coefficient at the wall and flow discharge coefficient with the blow ratio.The result shows that: the film cooling efficiency and heat transfer coefficient of the expanded film cooling holes are higher than the typical round film cooling holes,but the flow discharge coefficient is lower.The effect of the streamwise expanded angle on the film cooling effectiveness and heat transfer coefficient is more remarkable than the laterally angle,which expands the area of the low pressure near the edge of the holes,leading to lower flow discharge coefficient.
-
Key words:
- film cooling /
- shaped holes /
- cooling effectiveness /
- heat transfer coefficient
-
[1] 葛绍岩,刘登瀛,徐靖中,等.气膜冷却[M].北京:科学出版社,1985. [2] Goldstein R J,Eckert F R,Burggraf F.Effects of hole geometry and density on three-dimensional film cooling[J].Int J Heat Mass Transfer,1974,17:595-607. [3] Gritsch M.Effect of hole geometry on the thermal performance of fan shaped film cooling holes[J].ASME,2005,127:718-725. [4] Gritsch M,Schulz A,Wittig S.Effect of internal crossflow on the effectiveness of shaped film-cooling holes[J].ASME J.Turbomach,2003,125:547-554. [5] 朱惠人,许都纯,刘松龄,等.簸箕形排孔气膜冷却实验研究[J].航空学报.1997,18(5):535-538.ZHU Huiren.XU Duchun,LIU Songling et al.Film cooling experimental investigation of a row of dust-pan shaped holes[J].Acat Aeronautica et Astronautica Siniea,1997,18(5):535-538.(in Chinese) [6] Eriksen V L.Film cooling effectiveness and heat transfer with injection through holes[R].NASA-CR-72911,1971. [7] 杨卫华,李永康,张靖周,等.突片作用F气膜冷却效率的试验研究[J].航空动力学报,2007,22(3):380-383.YANG Weihua,LI Yongkang,ZHANG Jingzhou,et al.Experimental study of cooling efficiency of film cooling with tab[J].Journal of Aerospace Power,2007,22(3):380-383.(in Chinese)
