Console形气膜孔改善冷却效率的数值研究

姚玉; 张靖周; 周楠

Console形气膜孔改善冷却效率的数值研究

南京航空航天大学能源与动力学院, 南京 210016

基金项目: 航空基础科学基金(03C52019)

计量
- 文章访问数: 1443
- HTML浏览量: 0
- PDF量: 465
- 被引次数: 0
出版历程
- 收稿日期: 2007-10-15
- 修回日期: 2007-12-27
- 刊出日期: 2008-10-28

Numerical investigation on improvement of film cooling effectiveness with console hole

College of Energy and Power Engineering, Nanjing University of Aeronautics and Astronautics, Nanjing 210016, China

摘要

摘要: 运用剪应力输运湍流模型对Console形孔的气膜冷却结构,在不同吹风比下的气膜冷却效率的分布进行了数值研究;并在保持冷气入口相同开孔率的条件下,将其与圆形和缝形气膜孔的冷却效率进行比较.结果表明:随着吹风比的增加,Console形气膜孔的冷却效率也在增加;在相同吹风比条件下,Console形孔的冷却效率较圆形孔高,较缝形孔低;但在小吹风比时,基本与缝形孔的冷却效率相当.
- Console形孔 /
- 气膜冷却 /
- 数值计算
Abstract: The film cooling characteristics of console hole were numerically investigated using the shear-stress transport two-equation turbulent model to understand the effects of blowing ratios on cooling effectiveness.The cooling effectiveness for three configurations of film cooling holes was also studied comparatively.Results show that the cooling effectiveness for console film cooling hole increases with the increment of the blowing ratio.Under the same blowing ratio,the cooling effectiveness of the console hole is better than cylindrical hole,and lower than slot.Under the condition of low blowing ratio,the film cooling effectiveness of console is equivalent to the slot.
- console hole /
- film cooling /
- numerical computation

HTML

参考文献(12)

[1]	葛绍岩,刘登瀛,徐靖中,等.气膜冷却[M].北京:科学出版社,1985.
[2]	Goldstein R J,Eckert E R G,Burggraf B.Effects of hole geometry and desity on three-dimensional film cooling[J].International Journal of Heat and Mass Transfer,1992,17:595-607.
[3]	Schmidt D,Sen B,Bogard D.Film cooling with cornpound angle holes:Adiabatic effectiveness[J].Journal of Turbomachinary,1996,118:807-813.
[4]	Yuen C N N,Martinez-Botas R F,Whitelaw J H.Film cooling effectiveness downstream of compound and fanshaped holes[R3.ASME Paper 2001-GT-1031,2001.
[5]	Sargison J E,Guo S M,Oldfield M L G,et al.A converging slot-hole film-cooling geometry-Part 1:Low-speed flat-plate heat transfer and loss[R].ASME Turbo Expo No.2001-GT-0126,2001.
[6]	Nasir H,Acharya S,Ekkad S.Improved film cooling from cylindrical angled holes with triangular tabs:Effect of tab orientations[J].International Journal of Heat and Fluid Flow,2003,24:657-668.
[7]	Walters D K,Leylek J H.A systematic computational methodology applied to a three-dimensional film cooling flowfield[J].Journal of Turbomachinery,1997,119:777-785.
[8]	Zaman K B M Q.Reduction of jet penetration in a crossflow by using tabs[R].AIAA 98-3276,1998.
[9]	朱惠人,许都纯,刘松龄,等.簸箕形排孔气膜冷却实验研究[J].航空学报,1997,18(5):535-538.ZHU Huiren,XU Duehun,LIU Songling.et al.Film cooling experimental investigation of a row of dust-pan shaped holes[J].Acta Aeronautica et Astronautica Since,1997,18(5):535-538.(in Chinese)
[10]	徐红洲.气膜冷却的实验研究[D].西安:西北工业大学,1996.XU Hongzhou.Experimental investigation on film cooling[D].Xi'an:Northwestern Polytechnical University,1996.(in Chinese)
[11]	李永康,张靖周,姚玉.利用三角形突片改善气膜冷却效率的数值研究[J].航空动力学报,2006,21(1):83-87.LI Yongkang,ZHANG Jingzhou,YA0 Yu.Numerical investigation on improvement of film cooling effectiveness using delta-shaped tabs[J].Journal of Aerospace Power,2006,21(1):83-87.(in Chinese)
[12]	陶文铨.数值传热学[M].西安:西安交通大学出版社,1992.
