微型涡喷发动机燃烧室设计研究
Design and study of annular combustor for micro-turbine engine
-
摘要: 设计了微型环型燃烧室,并对其燃烧过程进行数值模拟,同时根据模拟结果对燃烧室进行了优化设计及二次计算.计算中入口边界参数采用等熵数值计算结果,喷雾性能参数通过试验获得,考虑了湍流化学反应、热辐射、液滴的蒸发及二次雾化等情况,计算结果可以较为准确地反映燃烧室的实际燃烧情况.对优化设计前后的模拟结果进行比较分析,结果表明优化后的燃烧室设计合理,燃料可以充分燃烧,各项性能参数基本符合设计要求,能够为燃烧室的进一步优化设计提供改进依据.Abstract: A micro annular combustor was designed based on research both inland and oversea,and simulated the combustion in the annual combustor.And then,according to the simulation result,the design of combustor was optimized and re-computed.All case including chemical reaction,heat radiation,evaporating of fuel and secondary breakup of spray was comprised in numerical simulation,the boundary condition of inlet was gained through computing and the parameter of spray was gained through experiment.The result of computation can reflect the reality case exactly.At last,the numerical simulation result of two combustor was compared,the result indicate the optimized design is reasonable,fuel can combusted sufficiently in chamber and the performance parameter is satisfied the design requirement.All data can provide numerical foundation for better performance in combustion chamber.
-
Key words:
- combustor design /
- micro-turbine engine /
- numerical simulation
-
[1] 梁德旺,黄国平.厘米级微型涡轮喷气发动机主要研究进展[J].燃气涡轮试验与研究,2004,17(2):9-13.LIANG Dewang.HUANG Guoping.Recent development and key techniques of micro-turbine in centimeter size[J].Gas Turbine Experiment and Research.2004,17(2):9-13.(in Chinese) [2] Saburo Y,Kana O.Concept and experiment of a flat-flame micro-combuster for ultra micro gas turbine[R].AIAA 2002-3771. [3] Jacobson S A.Aerothermal challenges in the design of a microfabricated gas turbine engine[R].AIAA-98-2545. [4] Dellimore K,Cadou C.Fuel-air mixing challenges in micropower systems[R].AIAA2004-301. [5] 张文普,丰镇平.微型燃气轮机燃烧室性能数值研究[J].燃气轮机技术,2003,16(2):26-30.ZHANG Wenpu,FENG zhenping.Numerical study On combustion and flow in a micro turbine annular combustor[J].Gas Turbine Technology,2003,16(2):26-30.(in Chinese) [6] 曾川,王洪铭,单鹏.微涡喷发动机离心甩油盘环型折流燃烧室的设计与试验研究[J].航空动力学报,2003,18(1):92-96.ZENG Chuan,WANG Hongming,SHAN Peng.The design and study of the annular combustion chamber with centrifugal fuel injection[J].Journal of Aerospace Power,2003,18(1):92-96.(in Chinese) [7] 李聪,方蜀州,张平.微型燃气涡轮发动机喷嘴雾化性能研究[R].成都:宇航学会固体火箭发动机2006年会学术会议,2006.
