跨声速轴流压气机叶片周向弯曲的数值优化

张晓东; 吴虎; 黄健; 马聪慧

跨声速轴流压气机叶片周向弯曲的数值优化

西北工业大学动力与能源学院, 西安 710072

计量
- 文章访问数: 1735
- HTML浏览量: 194
- PDF量: 470
- 被引次数: 0
出版历程
- 收稿日期: 2007-09-18
- 修回日期: 2008-03-19
- 刊出日期: 2008-10-28

Numerical optimization of transonic axial compressor by bowed blades

School of Power and Energy, Northwestern Polytechnical University, Xi'an 710072, China

摘要

摘要: 采用优化软件ISIGHT作为平台,集成了三维粘性流计算软件NUMECA和轴流压气机叶片造型程序,建立了一套叶轮机械气动性能优化系统.针对跨声速轴流压气机动叶和静叶的周向弯曲进行了优化.结果在整条特性线上,该级压气机的效率和压比都得到了不同程度的提高,充分验证了该叶轮机械气动性能优化系统的可靠性.同时表明转子的尖部反弯可以有效地减小叶尖间隙的横向流动.
- 数值优化 /
- 弯曲动叶 /
- 轴流压气机
Abstract: A compressor automated optimization system was investigated,which composed of software ISIGHT,NUMECA and a sophisticated blade-design program.For testing its validity,a single-stage transonic compressor was optimized by changing circumferential stacking line of blade.The results show efficiency and pressure ratio is improved in whole characteristic curve;the investigation indicated the negative bow of rotor tip can improve flow structure and validated the compressor automated optimization system.
- numerical optimization /
- bowed rotor /
- transonic axial compressor

HTML

参考文献(7)

[1]	Jang C M,Kim K Y.Optimization of stator blade using response surface method in a single-stage transonic axial compressor[J].Power and Energy,2005,219(8):595-603.
[2]	LIAN Yongsheng.Multi-objective optimization of a transonic compressor blade using evolutionary algorithm[R].AIAA 2005-1816.
[3]	Amano R S,Xu C.Blade sweep effects of turbomachinery[R].AIAA 2005-48.
[4]	宋立明,李军,丰镇平.三维跨音速压气机叶栅多目标气动优化设计[J].工程热物理学报,2007,5:223-225.SONG Liming,LI Jun,FENG Zhenping.Multi-objective optimization design of the 3-D transonic compressor CflScade[J].Journal of Engineering Thermophysics,2007,5;223-225.(in Chinese)
[5]	高学林,袁新.叶轮机械全三维粘性气动优化设计系统[J].中国电机工程学报,2006,4:88-92.GA0 Xuelin,YUAN Xin.Full 3-D viscous aerodynamic optimization design system for turbomachinery[J].Proceedings of the Chinese Society Electrical Engineering,2006,4:88-92.(in Chinese)
[6]	伊卫林,黄鸿雁.基于数值优化的跨音速压气机动叶三维设计[J].燃气轮机技术,2006,7:34-38.YI Weilin,HUANG Hongyan.Three-dimension design of transonic compressor through numerical optimization[J].The Technology of Gas Engine,2006,7:34-38.(in Chinese)
[7]	伊卫林,黄鸿雁,韩万金.跨声速压气机动叶周向弯曲的数值优化设计[J].航空动力学报,2006,21(3):480-484.YI Weilin,HUANG Hongyan,HAN Wanjin.Numerical optimization design of circumferentially curved transonic compressor rotor[J].Journal of Aerospace Power,2006.21(3):480-484.(in Chinese)
