叶盘系统频率转向与模态耦合特性分析
Characteristic analysis of frequency veering and mode interaction of bladed disks
-
摘要: 叶盘系统频率转向现象是系统模态间相互耦合的结果,并在较大程度上影响系统的振动特性.本文以系统模态能量的角度,从叶盘系统特征方程中导出各子模态能量的表达式,并利用集中参数模型,系统地研究了叶盘系统频率转向特性与系统模态中各子模态能量的变化规律.通过研究叶盘模态耦合能量的变化特性,较为全面地分析和总结了系统频率转向与各子模态能量变化之间的内在联系.Abstract: Frequency veering in a bladed disk is the result of system mode interaction,which will greatly affect the vibrational characteristics of the system.In view of system modal power,the expressions of various sub-mode powers were derived from the eigenfunction of a bladed disk in this paper.By using a lumped parameter model,the characteristics of frequency veering and variations of sub-mode powers were systematically investigated.While studying comprehensively the variation features of the mode interaction power of the bladed disk,the interaction between frequency veering and variations of sub-mode powers was thoroughly analyzed and summarized.This method and conclusion could provide a fundamental theory for looking into the physical insight of frequency veering of a bladed disk.
-
Key words:
- bladed disk /
- frequency veering /
- mode interaction /
- mode power /
- characteristic analysis
