总压畸变在三级轴流压气机中的传递性能研究
Study on transfer characteristics in 3-stage compressor with inlet pressure distortion
-
摘要: 介绍了一种计算进气畸变的方法.通过求解非稳态三维欧拉方程,计算压气机各截面气流参数分布.以74A三级压气机为例,进行了周向总压畸变传递特性计算,得到了压气机进口存在总压畸变时总压、静压、总温和流量系数在各截面上的分布规律,得出了畸变强度、畸变范围和畸变位置在轴向上的分布规律.Abstract: A method of calculating the axial-flow compressor flow field under distortion was presented.The stage distribution in different faces was computed by solving the unsteady 3-D Euler equations.The transfer characteristic for 74A compressor,for example,was computed under the inlet circumferential total pressure distortion,then the distribution of total pressure,static pressure,total temperature and flow coefficient in different faces were obtained.The distribution of the distortion intensity,distortion range and distortion position in axial direction was acquired.
-
Key words:
- compressor /
- inlet distortion /
- distortion intensity /
- stability
