微阵列射流冲击肋化表面传热特性
Investigation on heat transfer of micro-jet array impinging on pin-fin surface
-
摘要: 以去离子水为工质,对微阵列射流冲击光滑和肋化表面的传热特性进行了实验研究,并以光滑表面传热性能为基准,讨论了肋化表面强化因子(ε)变化规律.实验结果表明:①浸没和自由射流的传热系数均受无量纲射流距离(H/d)影响;提高射流Re数和减小无量纲孔间距(S/d)都能够增强换热.②浸没射流ε受H/d影响大,而自由射流ε基本不受H/d影响;两种射流方式的ε都随Re数增大,且渐趋于一个常数.③对流热阻在各种射流情况下均随流量不断下降,但下降趋势逐渐平缓,当流量大到一定时,热阻基本不再降低.Abstract: An investigation on heat transfer of a micro-jet array impinging smooth and pin fin surfaces was conducted.The experimental results indicate that:(1)the dimensionless nozzle-to-target spacing(H/d) has notable effects on heat transfer coefficient of both free-surface and submerged jet impingement,and heat transfer may be enhanced with increasing Reynolds number or decreasing dimensionless jet-to-jet spacing(S/d).(2)the enhancement factor(ε) is not influenced by H/d for free surface jet,but it is sensitive to variation of H/d for submerged jet.For both free-surface and submerged jet impingement,ε increases with increasing Re.(3)The convection resistance decreases,at first rapidly and then slowly,with increasing liquid flow rate.
-
Key words:
- micro-jet array /
- pin fin surface /
- enhancement factor /
- convection resistance
