基于预定啮合特性的点啮合齿面设计方法

周凯红; 唐进元; 严宏志

基于预定啮合特性的点啮合齿面设计方法

1.
中南大学机电学院现代复杂装备设计与极端制造教育部重点实验室, 长沙 410075
2.
桂林航天工业高等专科学校机械系, 桂林 541004
3.
中南大学机电学院现代复杂装备设计与极端制造教育部重点实验室, 长沙410075

基金项目: 国家重点基础研究发展计划(973计划)(2005CB724100);国家自然科学基金(50875263)

计量
- 文章访问数: 1278
- HTML浏览量: 3
- PDF量: 451
- 被引次数: 0
出版历程
- 收稿日期: 2009-03-21
- 修回日期: 2008-08-10
- 刊出日期: 2009-11-28

Research on meshing characteristics-based design of point-contact tooth surface

1.
Key Laboratory of Modern Complex Equipment Design and Extreme Manufacturing, Ministry of Education, School of Mechanical and Electrical Engineering, Central South University, Changsha 410075, China
2.
Department of Machinery Engineering, Guilin College of Aerospace Technology, Guilin 541004, China
3.
Key Laboratory of Modern Complex Equipment Design and Extreme Manufacturing, Ministry of Education, School of Mechanical and Electrical Engineering, Central South University, Changsha 410075, China

摘要

摘要: 针对格里森螺旋锥齿轮齿面设计方法无法在整个齿面接触传动过程中有效控制齿面啮合特性的不足,论述一种按预定的啮合特性设计点啮合齿面的理论和方法:啮合齿面的接触迹线上每一点的几何结构按预定的齿面啮合特性要求设计,而与特定的机床结构参数无关.啮合点的二阶接触参数通过弹性齿轮副的载荷-变形效应条件,而不是接触区的位置、大小和形状来设计.实例计算和分析表明本文的点啮合齿面设计方法是格里森齿面设计方法在数控技术条件下的发展和完善.
- 齿面啮合特性 /
- 条件数 /
- 螺旋锥齿轮 /
- 点啮合齿面
Abstract: For deficiency of the Gleason design technique for the spiral bevel gears,in which the meshing function is unable to be predesigned in whole tooth contact,a theory for the meshing characteristic-oriented design of point-contact tooth surface was presented.The geometry of the points on the path of contact was determined from the predesigned meshing characteristics,unrelated to any specific machine tool adjustment parameter.The second-order parameters of tooth flank were studied by load-deformation condition of elastic gears instead of the dimension,position and orientation of the contact ellipse.A numerical example was given to proved that above-mentioned design method is improvement and development of Gleason spiral bevel gears design method.
- meshing characteristics /
- condition number /
- spiral bevel gears /
- point-contact tooth surface
