支板阻力特性实验

Experimental investigation on drag of strut

College of Aerospace and Material Engineering, National University of Defense Technology, Changsha 410073, China

摘要: 实验在超燃冲压发动机直连式试验台进行,燃烧式加热器出口气流马赫数为2.7,总温为1 337 K.利用推力测量系统对不同结构尺寸支板的冷流阻力和热试阻力进行了研究.比较了高度分别为37.5 mm和71 mm,后掠角分别为0°,30°和45°的支板冷流阻力,结果表明支板的冷流阻力随支板高度的增大而增大,随后掠角的增大而减小;实验还在燃烧模态下对不同当量比时支板的阻力进行了对比,结果表明支板的热试阻力比冷流阻力小,且支板的热试阻力随当量比的增加而减小.
- 超燃冲压发动机 /
- 支板 /
- 阻力
Abstract: Experiments were conducted in a scramjet direct-connected wind tunnel facility with a combustion heater,which supplies Mach 2.7 airflow with a total temperature of 1 337 K.The drags of struts with different heights(H=37.5,71mm) and sweepback angles(0°,30°,45°) were studied by a thrust-measuring system.Experimental results in cold flow indicate that,the drag of strut rises with increase of height and declines with increase of sweepback angles.The drags of struts under combustion condition of different fuel equivalence ratios were investigated.It is found that the drag of strut under combustion condition is less than that in cold flow,and declines with increase of fuel equivalence ratio.
- scramjet /
- strut /
- drag

[1]	Rogers R C,Capriotti D P,Guy R W.Experimental supersonic combustion research at NASA Langley[R].AIAA 1998-2506.
[2]	Semenov V L.The possibility in vestigation of strut fuel feed system use in scramjet combustors on results of tests with hydrocarbon fuel[R].AD A332687,1997.
[3]	Kodera M,Sunami T,Scheel F.Numerical study on the supersonic mixing enhancement using streamwise vortices[R].AIAA 2002-5117.
[4]	俞刚,李建国.氢/空气超声速燃烧研究[J].流体力学实验与测量,1999,13(1):1-12. YUG ang,LI Jianguo.Investigation on supersonic combustion of hydrogen/air[J].Experiments and Measurements in Fluid Mechanics,1999,13(1):1-12.(in Chinese)
[5]	余勇,丁猛,刘卫东,等.煤油超音速燃烧的试验研究[J].国防科技大学学报,2004,26(1):1-4. YU Yong,DING Meng,LIU Weidong,et al.Experimental study of supersonic combustion of kerosene[J].Journal of National University of Defense Techonology,2004,26(1):1-4.(in Chinese)
