头部旋涡蒸发管式直径6cm环形燃烧室设计和试验

姚尚宏; 雷雨冰; 朱岩

头部旋涡蒸发管式直径6cm环形燃烧室设计和试验

南京航空航天大学能源与动力学院, 南京 210026

基金项目: 国家自然科学基金(10577011);基础预研项目

计量
- 文章访问数: 1740
- HTML浏览量: 3
- PDF量: 497
- 被引次数: 0
出版历程
- 收稿日期: 2008-12-02
- 修回日期: 2009-06-01
- 刊出日期: 2009-12-28

Design and experimental research on 6 cm-diameters head-swirl micro-combustor

College of Energy and Power Engineering, Nanjing University of Aeronautics and Astronautics, Nanjing 210016, China

摘要

摘要: 为提高微型燃烧室性能,提出头部旋涡蒸发管式微型环形燃烧室设计方案.在常温常压下开展了燃烧室冷态和热态性能试验,得到了燃烧室的阻力特性、贫油熄火特性和燃烧效率特性.结果表明:微型燃烧室未进入模化状态;头部旋涡结构对火焰的稳定性能相比直流式环形燃烧室有较大改善,负载参数达到较高水平;燃烧效率达到0.8,燃油驻留时间短是导致燃烧效率偏低的主要因素.头部旋涡结构用于微型燃烧室中显著提高了燃烧室的贫油熄火特性.
- 头部旋涡 /
- 微型燃烧室 /
- 贫油熄火 /
- 燃烧效率 /
- 性能试验
Abstract: The concept of new form of combustor named as head-swirl micro-combustor was studied to improve the performance of the micro-combustor.The experiment on the ambient temperature and pressure was carried out,the resistance characteristic shows that the combustor couldn't get into modeling state.The characteristics of the limit blow-out show that,the head swirl takes great advantage in keeping the fire stabilization,and the loading parameter is more satisfactory than that without the head swirl,the combustion efficiency is 0.8 at most,the major reason to the low efficiency is attributed to the short residual time for gas to stay in the combustor.The structure of head-swirl is successfully used in the micro-combustor design.
- head-swirl /
- micro-combustor /
- limit blow-out /
- combustion efficiency /
- performance experiment

HTML

参考文献(17)

[1]	梁德旺,黄国平.厘米级微型涡轮喷气发动机主要研究进展[J].燃气涡轮试验与研究,2004,17(2):9213.LIANG Dewang,HUANG Guoping.Recent develop ment and key techniques of micro-turbine in centimeter size[J].Gas Turbine Experiment and Research,2004,17(2):9-13.(in Chinese)
[2]	Spadaccini C M,Mehra A,Zhang X,et al.High power density silicon combustion systems for micro gas turbine engines[J].Journal of Engineering for Gas Turbines and Power,2003,125:709-719.
[3]	曾川,王洪铭,单鹏.微涡喷发动机离心甩油盘环形折流燃烧室的设计与试验研究[J].航空动力学报,2003,18(1):92-96.ZENG Chuan,WAN G Hongming,SHAN Peng.The de-sign and study of the annular combustion chamber wit h cent rif ugal f uel injection[J].Journal of Aero space Pow-er,2003,18(1):92-96.(in Chinese)
[4]	熊庆荣,雷雨冰,黄国平,等.厘米级微型蒸发管式燃烧室性能试验研究[J].航空动力学报,2007,22(5):7332738.XION G Qingrong,LEI Yubing,HUANG Guoping,et al.Experimental research on a centimeter-scale micro com-bustor wit h vaporizing t ube[J].Journal of Aerospace Power,2007,22(5):733-738.(in Chinese)
[5]	Sullivan R E,Novick A S,Miles G A.Small gas turbine combustorprimary zone development[R].AIAA 1982-1159.
[6]	Sullivan R E,Sutton R,Miles G,et al.Application of 3D aerodynamic combustion model to combustor primary zone study[R].AIAA 1983-1265.
[7]	Prociw L A,Hu T C J,Hastings R R.Reducing tempera-t ure dist ribution factor(TDF)for advanced small gas t ur-bine engines[R].A GARD SEE N94-34431.
[8]	Martino P D,Cinque G,Colantuoni S,et al.Experimen-tal and computational result s from an advanced reverse-flow gas turbine combustor[R].AIAA 952-999.
[9]	Mc Guirk J J,Spencer A.Coupled and uncoupled CFD p re-diction of the characteristics of iet s from combustor air ad-mission port s[J].Journal of Engineering for Gas Turbines and Power,2001,123:327-332.
[10]	Spencer A,Mc Guirk J J.LDA measurements of feed an-nulus effects on combustor liner port flows[J].Journal of Fluids Engineering,2001,123:219-227.
[11]	Sturgess G J,Gogineni S.Influences of airblast-ato mizing fuel injector design on primary zone flame characteristics at blowout[R].AIAA 97-0269.
[12]	Sturgess G J,Gogineni S,Shouse D T,et al.Emissions and operability trades in the primary zones of gas turbine combustors[R].AIAA 96-2758.
[13]	Sturgess G J,Sloan D G,Lesmerises A L,et al.Design and develop ment of a research combustor for lean blow-outStudies[J].Journal of Engineering for Gas Turbines and Power,1992,114:13-19.
[14]	Ballal D R,Vangsness M D,Heneghan S P,et al.Studies of lean blowout in a research combustor[R].AGARD SEE N94-29246.
[15]	Rizk N K,Lefebvre A H.Spray characteristics of plain-jet airblast atomizers[R].ASME Paper 832GT2138,1983.
[16]	林宇震,刘俊,许全宏,等.微小“Г”型蒸发管在常压条件下蒸发率研究[J].航空动力学报,2006,21(5):843-847.LIN Yuzhen,LIU Jun,XU Quanhong,et al.study on vaporization rate of a miniГ2vaporizer under at mosp heric pressure condition[J].Journal of Aerospace Powe,2006,21(5):843-847.(in Chinese)
[17]	Khan Q S,Baek S W,Lee S Y.Effect of droplet initial di-ameter on droplet vaporization regimes for kerosene fuel droplet[R].AIAA 2007-1181.
