基于环量分布的轴流双级风扇三维数值优化

何柳; 单鹏

基于环量分布的轴流双级风扇三维数值优化

何柳,
单鹏

北京航空航天大学能源与动力工程学院,北京 100191

基金项目: 中国航空工业集团公司中国燃气涡轮研究院外委课题

计量
- 文章访问数: 1687
- HTML浏览量: 145
- PDF量: 463
- 被引次数: 0
出版历程
- 收稿日期: 2009-11-04
- 修回日期: 2010-04-04
- 刊出日期: 2010-12-28

Three-dimensional aerodynamic optimization for the two-stage axial-flow fan based on work distribution

HE Liu,
SHAN Peng

School of Jet Propulsion, Beijing University of Aeronautics and Astronautics,Beijing 100191,China

摘要

摘要: 将通流设计程序和叶片造型程序引入到遗传算法同响应面模型相结合的优化系统中,调用流场模拟软件,搭建了三维轴流压气机叶片的优化平台.该优化技术有四个特点:一是为与现代设计系统相接轨,不同于常见的用纯几何方法生成叶片,采用了传统的反问题设计方法生成三维叶片;二是不同于直接优化几何参数,优化自变量选取了设计中具有物理意义的气动参数;三是针对多级压气机的优化,提出了逐级优化策略;四是在优化过程中引入了直观分析法.算例选取了环量分布作为优化自变量,对某轴流双级风扇进行了以极大化非设计点流量为目标的优化;又对其改型设计进行了以极大化设计点绝热效率为目标的优化.
- 轴流压气机 /
- 反问题设计 /
- 气动变量参数化 /
- 环量分布 /
- 逐级优化策略 /
- 直观分析法
Abstract: By integrating genetic algorithm with response surface methodology,this paper developed an optimization system,with introduction of a quasi-three-dimensional through-flow design code and a blade formatting code.While a three-dimensional CFD (computational fluid dynamics) solver was involved,this paper established a numerical aerodynamic optimization platform for three-dimensional blades of axial-flow compressors.The optimization in this paper mainly has four features.First,it applies the conventional inverse design method instead of common CAGD (computer aided geometric design) parameterization method to generate a three-dimensional blade.Second,it chooses aerodynamic parameters with physical meaning as optimization design variables instead of purely geometrical parameters.Third,it presents a stage-by-stage optimization strategy about the multistage turbomachinery optimization.Fourth,it introduces the visual analysis method into optimization.The above techniques were applied,first,to a two-stage axial-flow fan for its maximum mass flow rate,and then,to the reformed two-stage axial-flow fan for its maximum adiabatic efficiency.The work distributions were taken as design variables,which were parametrically represented by means of Bézier curves.The two examples elucidate that not only the techniques mentioned above are appropriate and effective in engineering,but also the design guidance for similar inverse design problems can be obtained from the optimization results.
- axial-flow compressor /
- inverse design /
- aerodynamic variable parameterization /

HTML

参考文献(16)

[1]	Pierret S,Van den Braembussche R A.Turbomachinery blade design using a Navier-Stokes solver and artificial neural network[J].Journal of Turbomachinery,1999,121(2):326-332.
[2]	Chung J,Shim J,Lee K D.Design of 3D transonic compressor blades using numerical optimization .AIAA-2000-0227,2000.
[3]	Kim J H,Choi J H,Kim K Y.Design optimization of a centrifugal compressor impeller using radial basis neural network method .ASME Paper GT2009-59666,2009.
[4]	Bartold A,Joos F.Optimization of a centrifugal impeller using evolutionary algorithms .ASME Paper GT2008-50805,2008.
[5]	ksüz ,Akmandor I S.Axial turbine blade aerodynamic optimization using a novel multi-level genetic algorithm .ASME Paper GT2008-50519,2008.
[6]	Bonaiuti D,Zangeneh M.On the coupling of inverse design and optimization techniques for the multiobjective,multipoint design of turbomachinery blades[J].Journal of Turbomachinery,2009,131(2):021014.(16 pages)
[7]	Arabnia M,Ghaly W.A strategy for multi-point shape optimization of turbine stages in three-dimensional flow .ASME Paper GT2009-59708,2009.
[8]	Wang D X,He L,Li Y S,et al.Adjoint aerodynamic design optimization for blades in multi-stage turbomachines:Part Ⅱ—Validation and application .ASME Paper GT2008-50209,2008.
[9]	陈志鹏,袁新.全工况性能优化在压气机多级环境中的应用[J].工程热物理学报,2008,29(2):221-224. CHEN Zhipeng,YUAN Xin.Aerodynamics optimum design of compressor blades based on numerical overall performance calculation[J].Journal of Engineering Thermophysics,2008,29(2):221-224.(in Chinese)
[10]	Veress ,Van den Braembussche R A.Inverse design and optimization of a return channel for a multistage centrifugal compressor[J].Journal of Fluids Engineering,2004,126(5):799-806.
[11]	陈波,高学林,袁新.采用NURBS的某级透平叶片全三维气动最优化设计[J].动力工程,2006,26(2):201-206. CHEN Bo,GAO Xuelin,YUAN Xin.Aerodynamic 3-dimensional optimal design by NURBS of a certain stage turbine blades[J].Journal of Power Engineering,2006,26(2):201-206.(in Chinese)
[12]	Briasco G,Bruna D,Cravero C.A NURBS-based optimization tool for axial compressor cascades at design and off-design conditions .ASME Paper GT2008-50622,2008.
[13]	Chen N X,Zhang H W,Xu Q,et al.Application of simple gradient-based method and multi-section blade parameterization technique to aerodynamic design optimization of a 3D transonic single rotor compressor .ASME Paper GT2009-59783,2009.
[14]	Verstraete T,Alsalihi Z,Van den Braembussche R A.Multidisciplinary optimization of a radial compressor for micro gas turbine applications .ASME Paper GT2007-27484,2007.
[15]	杨晶晶,单鹏.某高负荷前掠双级风扇设计与掠形机理研究[J].航空动力学报,2009,24(8):1805-1812. YANG Jingjing,SHAN Peng.Design of a high-loading two-stage forward swept fan and investigation on the swept-blading mechanism[J].Journal of Aerospace Power,2009,24(8):1805-1812.(in Chinese)
[16]	Denton J D.The calculation of three-dimensional viscous flow through multistage turbomachines[J].Journal of Turbomachinery,1992,114(1):18-26.
