Rotor 37顶隙泄漏流的演化、影响及机匣处理
Development of tip leakage flow in NASA Rotor 37 and casing treatment
-
摘要: 在详细研究顶隙泄漏流的结构及其演化的基础上,分析了Rotor 37的失速机理,并对不同深度、宽度和位置的环向沟机匣处理方式进行了比较研究.研究发现:在该研究的顶隙高度下,发生在叶尖尾缘附近的大面积流动分离是造成压气机失速的直接原因.因而布置在叶片中段和尾缘的环向沟有利于提高压气机的喘振裕度.同时还发现,环向沟的深度对于其产生作用并没有明显的影响,而其宽度的影响则较为明显.Abstract: Based on the detailed computational fluid dynamics (CFD) study on the structure and development of tip leakage flow in NASA(National Aeronautics and Space Administration) Rotor 37,the stall mechanism was discussed.A study of the circumferential grooves casing treatment with different locations,depth and width was also performed.The simulation reveals that the large separation zone at the trailing edge near the blade tip is directly attributable to the compressor stall at the configuration studied in this paper.As a result,the circumferential grooves at the mid-chord and the trailing edge appear to be effective on the extension of the stall margin.Meanwhile,it is found that the depth of the grooves does not influence obviously its effect,while the width seems to be a more important parameter.
-
Key words:
- transonic compressor /
- tip leakage flow /
- stall mechanism /
-
[1] Schlechtriem S,Loetzerich M.Breakdown of tip leakage vortices in compressors at flow conditions close to stall .ASME Paper 97-GT-41,1997. [2] Hoffman W H,Ballman J.Some aspects of tip vortex behavior in a transonic turbocompressor .ISABE Paper 2003-1223,2003. [3] Yamada K,Furukawa M,Inoue M,et al.Numerical analysis of tip leakage flow field in a transonic axial compressor rotor .IGTC Paper 2003-095,2003. [4] Rabe D C,Hah C.Application of casing circumferential grooves for improved stall margin in a transonic axial compressor .ASME Paper GT-2002-30641,2002. [5] Wilke I,Kau H P.A numerical investigation of the influence of casing treatments on the tip leakage flow in a HPC front stage .ASME Paper GT-2002-30642,2002. [6] Hathaway M.Self-recirculating casing treatment concept for enhanced compressor performance .ASME Paper GT-2002-30368,2002. [7] Yang H,Nuernberger D,Nicke E,et al.Numerical investigation of casing treatment mechanisms with a conservative mixed-cell approach .ASME Paper GT-2003-38483,2003. [8] Müller M M,Schiffer H P,Hah C.Effect of circumferential grooves on the aerodynamic performance of an axial single-stage transonic compressor .ASME Paper GT-2007-27365,2007. [9] CHEN Haixin,FU Song,HUANG Xudong.CFD nvestigation on tip leakage flow and casing treatment of a transonic compressor .ISABE-2005-1098,2005. [10] HUANG Xudong,CHEN Haixin,FU Song.CFD investigation on circumferential grooves casing treatment of a transonic compressor .AJCPP-2006-22111,2006. [11] 陈海昕,黄旭东,符松.跨声速压气机机匣处理的数值研究[J].航空动力学报,2007,22(2):298-304. CHEN Haixin,HUANG Xudong,FU Song.CFD study on casing treatment in a transonic compressor[J].Journal of Aerospace Power,2007,22(2):298-304.(in Chinese) [12] Dunham J.CFD validation for propulsion system components .AGARD Advisory Report 355,1998. -
