混合弹流润滑下弧齿锥齿轮齿面闪温研究

谷建功; 方宗德; 扶碧波; 祝小元

混合弹流润滑下弧齿锥齿轮齿面闪温研究

1.
西北工业大学机电学院,西安 71007
2.
中国航空工业集团公司中国航空动力机械研究所,株洲 412002

基金项目: 国家自然科学基金(50875211)

计量
- 文章访问数: 1929
- HTML浏览量: 75
- PDF量: 391
- 被引次数: 0
出版历程
- 收稿日期: 2009-11-12
- 修回日期: 2010-01-18
- 刊出日期: 2010-12-28

Study on surface flash temperature for spiral bevel gears under condition of mixed elasto-hydrodynamic lubrication

1.
School of Mechanical Engineering, Northwestern Polytechnical University,Xian 71007
2.
China Aviation Powerplant Research Institute, Aviation Industry Corporation of China,Zhuzhou 412002,China

摘要

摘要: 在布洛克闪温公式的基础上,计算了混合弹流润滑下的齿面平均摩擦因数,提高了公式的计算精度.结合弧齿锥齿轮几何与承载接触分析,通过计算沿齿面啮合点的曲率半径和切向速度,提出了实际润滑状态下沿接触路径的闪温公式.经算例分析表明,弧齿锥齿轮闪温的最大值位于啮入轨迹的中部,随着接触路径的倾斜度和长度的增加,实际重合度增大,啮合点处的载荷减小,闪温的最大值明显减小,其胶合承载能力显著提高.
- 混合弹流润滑 /
- 平均摩擦因数 /
- 弧齿锥齿轮 /
- 闪温 /
- 接触路径
Abstract: The average friction coefficient in the mixed elasto-hydrodynamic lubrication state was derived from Block flash temperature formula,and the calculation precision was improved.In combination with tooth contact and loaded tooth contact analysis of spiral bevel gears,the flash temperature formula under the condition of actual lubrication state was proposed by calculating the surface curvature radiuses and tangential velocities along the contact point.The results show that,its maximum flash temperature locates in the middle of the approach path,but decreases obviously and the scuffing load capacity is enhanced significantly as the inclination and length of the contact path increase,the actual coincidence degree rises and the load at the contact point reduces.
- mixed elasto-hydrodynamic lubrication /
- average friction coefficient /

HTML

参考文献(16)

[1]	江亲瑜,王松年.齿轮抗胶合强度计算方法研究[J].润滑与密封,2001(5):9-14. JIANG Qinyu,WANG Songnian.A study on calculation method for scuffing resistance of gears[J].Lubrication Engineering,2001(5):9-14.(in Chinese)
[2]	王启义.中国机械设计大典数据库 .江西:江西科学技术出版社,2002.
[3]	Martin K F.A review of friction predictions in gear teeth [J].Wear,1978,49(2):201-238.
[4]	方宗德,刘涛,邓效忠.基于传动误差设计的弧齿锥齿轮啮合分析[J].航空学报,2002,23(3):226-230. FANG Zongde,LIU Tao,DENG Xiaozhong.Tooth contace analysis of spiral bevel gears based on the design of transmission error[J].Acta Aeronautica et Astronautica Sinica,2002,23(3):226-230.(in Chinese)
[5]	方宗德,邓效忠,任东锋.考虑边缘接触的弧齿锥齿轮承载接触分析[J].机械工程学报,2002,38(9):69-72. FANG Zongde,DENG Xiaozhong,REN Dongfeng.Loaded tooth contact analysis of spiral bevel gears considering edge contace[J].Chinsese Journal of Mechanical Engineering,2002,38(9):69-72.(in Chinese)
[6]	Castro J,Campos A,Sottomayor A,et al.Gear friction coefficient in mixed lubrication //Proceedings of Tribology and Interface Engineering Series N48,Life Cycle Tribology.Leeds,UK:Elsevier,2004:525-536.
[7]	Zhu D,Hu Y.A computer program package for the prediction of EHL and mixed lubrication characteristics,friction,subsurface stresses and flash temperatures based on measured 3-d surface roughness[J].Tribology Transactions,2001,44(3):383-390.
[8]	Gohar R.Elastohydrodynamics,Ellis Horwood series in mechanical engineering[M].New York:John Wiley & Sons,1988.
[9]	Dowson D,Higginson G R.Elastohydrodynamic lubrication[M].Oxford:Pergamon Press Ltd.,1997.
[10]	Winter H,Michaelis K.Scoring load capacity of gears lubricated with ep-oils .Montreal,Canada:AGMA Fall Technical Meeting,1983.
[11]	Hamrock B.Fundamentals of fluid film lubrications,mechanical engineering series[M].New York:McGraw-Hill International,1994.
[12]	Horng J.Contact analysis of rough surfaces under transaction conditions in sliding line lubrication[J].Wear,1998,219(2):205-212.
[13]	Gelinck E,Shipper D.Calculation of stribeck curves for line contacts[J].Tribology International,2000,33(3-4):175-181.
[14]	Williams J.Advanced in the modeling of boundary lubrication[J].Tribology Series,2002,40:37-48.
[15]	Robbe-Valoire F.Theoretical prediction and experimental results for mixed lubrication between parallel surfaces[J].Tribology Series,2002,40:129-137.
[16]	ASME Tribology Division Technical Commit.ISO 281/2 Life ratings for modern rolling bearings — a design guide for the application of international standard[S].New York:American Society of Mechanical Engineers,2003.
