四种飞行器绕流的三维DSMC计算与传热分析

王保国; 李耀华; 钱耕

四种飞行器绕流的三维DSMC计算与传热分析

北京理工大学宇航学院, 北京 100081

基金项目: 国家自然科学基金(50376004); 高等学校博士学科点专项基金(20030007028)

计量
- 文章访问数: 2060
- HTML浏览量: 63
- PDF量: 31
- 被引次数: 0
出版历程
- 收稿日期: 2010-09-18
- 修回日期: 2010-10-20
- 刊出日期: 2011-01-28

Three-dimensional DSMC calculation and heat transfer analysis of four capsules for hypersonic rarefied conditions

School of Aerospace Engineering,Beijing Institute of Technology,Beijing 100081,China

摘要

摘要: 在地球大气层与火星大气层中,使用自己编制的DSMC(direct simulation Monte Carlo)源程序完成了四种飞行器(即Apollo,Orion,Mars Pathfinder以及Mars Microprobe)高超声速穿越稀薄气体时的三维绕流计算,给出了上述飞行器42个典型飞行工况(其中包括在地球大气层中,飞行高度从250km变到90km,飞行攻角从45°变到-45°,Knudsen数从111.0变到0.0057,飞行速度从7.6km/s变到9.6km/s;在火星大气层中,飞行高度从141.8km变到80.28km,飞行攻角从45°变到0°,Knudsen数从100.0变到0.0546,飞行速度从7.47km/s变到6.908km/s)时详细气动力与气动热的数值结果,并与国外的飞行数据以及美国NASA(National Aeronautics and Space Administration) Langley研究中心发表的计算结果进行了比较,所得结果令人满意.文中采用了三种无量纲参数分别刻画这四种典型飞行器绕流流动的热力学非平衡、化学反应非平衡以及壁面热流分布的特征,这些结果对于指导空间飞行器的热防护气动设计十分有益.
- 直接模拟蒙特卡罗 (DSMC) 算法 /
- 热力学非平衡 /
- 化学反应非平衡 /
- 高温传热分析 /
- 飞行器/探测器
Abstract: Hypersonic rarefied flow field of four vehicles (Apollo, Orion, Mars Pathfinder and Mars Microprobe) in the atmosphere of Earth and Mars was calculated using the DSMC(direct simulation Monte Carlo) source code compiled by us. Detailed aerodynamic coefficients and thermodynamic coefficients of these vehicles under 42 conditions (with the altitude from 250km to 90km, attack angle from 45° to -45°, Knudsen number from 111.0 to 0.0057, velocity from 7.6km/s to 9.6km/s for the Earth atmosphere; with the altitude from 141.8km to 80.28km, attack angle from 45° to 0°, Knudsen number from 100.0 to 0.0546, velocity from 7.47km/s to 6.908km/s for the Mars a tmosphere) were presented and compared with flight data announced by other countries and calculation results published by NASA (National Aeronautics and Space Administration) Langley Research Center. The results are satisfactory. Three-dimensionless parameters were used to describe the characteristics of thermodynamic non-equilibrium, chemical non-equilibrium and wall heat flux of these four typical vehicles respectively. These results are quite useful for thermal protection design of spacecrafts.
- DSMC (direct simulation Monte Carlo) algorithm /
- thermodynamic non-equilibrium /
- chemical reaction non-equilibrium /
- high temperature heat transfer analysis /
- vehicles/entry probes

HTML

参考文献(23)

[1]	Ball A J,Garry J R,Lorenz R D,et al.Planetary landers and entry probes[M].Cambridge:Cambridge University Press,2007.
[2]	Siddiqi A A.Deep space chronicle:a chronology of deep space and planetary probes,1958-2000 .Washington:NASA SP 2002-4524,2002.
[3]	Miele A.Recent advance in the optimization and guidance of aeroassisted orbital transfer[J].Acta Astronautica,1996,38(10):747-768.
[4]	沈青.稀薄气体动力学[M].北京:国防工业出版社,2003.
[5]	王保国,李学东,刘淑艳.高温高速稀薄流的DSMC算法与流场传热分析[J].航空动力学报,2010,25(6):1203-1220. WANG Baoguo,LI Xuedong,LIU Shuyan.DSMC algorithm and heat transfer analysis of high temperature and high velocity rarefied gas flow[J].Journal of Aerospace Power,2010,25(6):1203-1220.(in Chinese)
[6]	Chapman S,Cowling T G.The mathematical theory of non-uniform gases[M].New York:Cambridge University Press,1970.
[7]	Cheremisin F G.Solution of the Wang Chang-Uhlenbeck master equation[J].Doklady Physics,2002,47(12):872-875.
[8]	Bird G A.Molecular gas dynamics and the direct simulation of gas flow[M].Oxford:Clarendon Press,1994.
[9]	Moss J N,Glass C E,Greene F A.Blunt body aerodynamics for hypersonic low density flows //Proceeding of the 25th International Symposium on Rarefied Gas Dynamics.Saint-Petersburg,Russia:Publishing House of Siberian Branch of the Russian Academy of Sciences,2006.
[10]	Shirley D L,McCleese D J.Mars exploration program strategy:1995-2020 .AIAA Paper 96-0333,1996.
[11]	卞荫贵,徐立功.气动热力学[M].合肥:中国科学技术大学出版社,1997.
[12]	姜贵庆,刘连元.高速气流传热与烧蚀热防护[M].北京:国防工业出版社,2003.
[13]	陈懋章.粘性流体动力学基础[M].北京:高等教育出版社,2002.
[14]	陶文铨.传热学[M].西安:西北工业大学、北京理工大学、北京航空航天大学、哈尔滨工业大学、哈尔滨工程大学出版社,2006.
[15]	曹玉璋,陶智,徐国强,等.航空发动机传热学[M].北京:北京航空航天大学出版社,2005.
[16]	王保国,刘淑艳,王新泉,等.传热学[M].北京:机械工业出版社,2009.
[17]	范绪箕.气动加热与热防护系统[M].北京:科学出版社,2004.
[18]	王保国,李翔.多工况下高超声速飞行器再入时流场的计算[J].西安交通大学学报,2010,44(1):71-76. WANG Baoguo,LI Xiang.Prediction of hypersonic vehicle reentry flowfields in multiple cases[J].Journal of Xian Jiaotong University,2010,44(1):71-76.(in Chinese)
[19]	王保国,李翔,黄伟光.激波后高温高速流场中的传热特性研究[J].航空动力学报,2010,25(5):963-980. WANG Baoguo,LI Xiang,HUANG Weiguang.Analytical study of heat transfer of high-temperature and high-velocity flow field behind shock waves[J].Journal of Aerospace Power,2010,25(5):963-980.(in Chinese)
[20]	王保国,刘淑艳,黄伟光.气体动力学[M].北京:北京理工大学、北京航空航天大学、西北工业大学、哈尔滨工业大学、哈尔滨工程大学出版社,2005.
[21]	王保国,刘淑艳,姜国义,等.高阶格式及其在内外流场计算中的应用[J].航空动力学报,2008,23(1):55-63. WANG Baoguo,LIU Shuyan,JIANG Guoyi,et al.High-order scheme and its application to the computation of the internal and external flow field[J].Journal of Aerospace Power,2008,23(1):55-63.(in Chinese)
[22]	王保国,刘淑艳,张雅.双时间步长加权ENO-强紧致高分辨率格式及在叶轮机械非定常流动中的应用[J].航空动力学报,2005,20(4):534-539. WANG Baoguo,LIU Shuyan,ZHANG Ya.Pseudo-time method of weighted ENO-strongly compact high resolution schemes and its application to turbomachinery unsteady flow[J].Journal of Aerospace Power,2005,20(4):534-539.(in Chinese)
[23]	王保国,吴俊宏,朱俊强.基于小波奇异分析的流场计算方法及应用[J].航空动力学报,2010,25(12):2728-2747. WANG Baoguo,WU Junhong,ZHU Junqiang.A method based on wavelet sigularity analysis for complicated flow and its application[J].Journal of Aerospace Power,2010,25(12):2728-2747.(in Chinese)
