环形脉冲爆震发动机引射性能

秦亚欣; 于军力; 高歌

环形脉冲爆震发动机引射性能

北京航空航天大学能源与动力工程学院航空发动机气动热力科技重点实验室,北京 100191

计量
- 文章访问数: 1992
- HTML浏览量: 375
- PDF量: 21
- 被引次数: 0
出版历程
- 收稿日期: 2009-11-23
- 修回日期: 2010-05-13
- 刊出日期: 2011-01-28

Performance studies of annular pulse detonation engine ejectors

National Key Laboratory of Science and Technology on Aero-Engines, School of Jet Propulsion,Beijing University of Aeronautics and Astronautics, Beijing 100191,China

摘要

摘要: 采用解析方法得出爆震波在爆震管内的参数分布,应用数值方法对爆震波衰退为激波后的传播、排除过程进行了多循环模拟.通过对环形爆震管非稳态引射过程的分析,得出非稳态引射过程可以分成四个阶段,环形爆震管比传统的圆形爆震管的引射作用更强.不同结构参数的引射喷管对环形爆震管的引射增推性能不同,经过分析,得到了较佳的引射喷管的入口尺寸、内表面形状、长度/直径比以及轴向位置,为提高脉冲爆震发动机的性能提供参考.
- 脉冲爆震发动机 /
- 爆震波 /
- 环形 /
- 引射 /
- 数值计算
Abstract: The distributions of detonation parameters in detonation chamber were gained by analytical numeration,and then multiple-cycle numerical simulations were carried out after detonation wave broke up to shock wave.The analysis on the mechanism of unsteady ejection shows that the process of unsteady ejection can be divided to four stages,and the ejection performance of annular pulse detonation duct is stronger than round pulse detonation duct.Different structures and parameters could induce different time-averaged thrust augmentations.The better shape of the ejector inlet,interior surface,ejector length-to-diameter ratio and axial placement were obtained through analysis,offering references to augment the performance of pulse detonation engine.
- pulse detonation engine /
- detonation wave /
- annular /
- ejection /
- numerical simulation

HTML

参考文献(12)

[1]	Tangirala V E,Dean A J,Nobuyuki T,et al.Performance of a pulse detonation engine under subsonic and supersonic flight conditions .AIAA 2007-1245,2007.
[2]	刘建文,钟诚文,赵书苗.多管脉冲爆震发动机流场数值研究[J].推进技术,2007,28(6):674-678. LIU Jianwen,ZHONG Chengwen,ZHAO Shumiao.Numerical investigation of multi-tube pulse detonation engine[J].Journal of Propulsion Technology,2007,28(6):674-678.(in Chinese)
[3]	Wintenberger E,Austin J M,Cooper M,et al.Analytical model for the impulse of single-cycle pulse detonation tube[J].Journal of Propulsion and Power,2003,19(1):22-38.
[4]	Hofer D C,Tangirala V E,Suresh A.Performance metrics for pulse detonation combustor turbine hybrid systems .AIAA 2009-292,2009.
[5]	张群,严传俊,范玮,等.多循环脉冲爆震发动机概念化设计[J].推进技术,2003,24(6):500-504. ZHANG Qun,YAN Chuanjun,FAN Wei,et al.Conceptual design of multi-cycle pulse detonation engines[J].Journal of Propulsion Technology,2003,24(6):500-504.(in Chinese)
[6]	严传俊,范玮.脉冲爆震发动机原理及关键技术[M].西安:西北工业大学出版社,2005. YAN Chuanjun,FAN Wei.The theory and key technology of pulse detonation engine[M].Xian:Northwestern Polytechnical University Press,2005.(in Chinese)
[7]	邱华.脉冲爆震发动机性能分析及数值模拟 .西安:西北工业大学,2003. QIU Hua.Performance analysis and numerical simulation of pulse detonation engine .Xian:Northwestern Polytechnical University,2003.(in Chinese)
[8]	秦亚欣,于军力,高歌.脉冲爆震发动机喷管性能数值分析[J].航空动力学报,2010,25(2):366-372. QIN Yaxin,YU Junli,GAO Ge.Computational analysis on the nozzle performance of pulse detonation engines[J].Journal of Aerospace Power,2010,25(2):366-372.(in Chinese)
[9]	Glaser A J.Performance and environmental impact assessment of pulse detonation based engine systems .Cincinnati:University of Cincinnati,2007.
[10]	Allgood D,Gutmark E,Hoke J,et al.Performance studies of pulse detonation engine ejectors[J].Journal of Propulsion and Power,2008,24(6):1317-1323.
[11]	Wilson J,Sgondea A,Paxson D E,et al.Parametric investigation of thrust augmentation by ejectors on a pulsed detonation tube[J].Journal of Propulsion and Power,2007,23(1):108-115.
[12]	Yungster S,Perkins H D.Multiple-cycle simulation of a pulse detonation engine ejector .AIAA 2002-3630,2002.
