小型航空二冲程风冷发动机缸体流固耦合传热的仿真

唐梓杰; 丁水汀; 杜发荣

小型航空二冲程风冷发动机缸体流固耦合传热的仿真

北京航空航天大学交通科学与工程学院,北京 100191

计量
- 文章访问数: 1958
- HTML浏览量: 351
- PDF量: 22
- 被引次数: 0
出版历程
- 收稿日期: 2010-05-07
- 修回日期: 2010-10-12
- 刊出日期: 2011-01-28

Simulation of fluid-solid coupled heat transfer of cylinder of a small two-stroke air-cooled aero-engine

School of Transportation Science and Engineering, Beijing University of Aeronautics and Astronautics,Beijing 100191,China

摘要

摘要: 以某小型航空二冲程风冷发动机为研究对象,结合风冷发动机缸体的传热特点和汽油机的燃烧规律并基于流固耦合理论,对风冷发动机缸体传热进行了模拟计算.根据耦合传热理论,将缸体与缸套的导热转化为系统内部边界条件进行简化处理,并将模拟计算的结果与地面试验结果相比较,证明了耦合传热方法在研究缸体热负荷方面的可靠性.在考虑飞行器整个飞行包线下的外界大气环境下,对风冷发动机在整个工作高度范围内缸体的传热仿真进行了模拟计算,为发动机缸体传热的进一步研究开发奠定了基础.
- 二冲程 /
- 风冷发动机 /
- 流固耦合 /
- 传热 /
- 缸体
Abstract: Based on a small two-stroke air-cooled aero-engine,the heat transfer of cylinder for air-cooled engine was simulated according to the theory of the fluid-solid coupled heat transfer,in combination with characteristics of heat transfer and discipline of combustion.In this theory,the heat conduction between the cylinder and cylinder liner was considered as internal condition of the system,which can make the simulation simple and convenient;as compared with the experiment result;this shows that coupled analysis is reliable about the heat transfer of the cylinder.Considering the whole working condition of the aerial vehicle,the heat transfer of the cylinder within the working altitude was simulated, thus establishing a basis for further study of the cylinder heat transfer.
- two-stroke /
- air-cooled engine /
- fluid-solid coupled /
- heat transfer /
- cylinder

HTML

参考文献(18)

[1]	秦有方.车辆内燃机原理[M].北京:北京理工大学出版社,1997.
[2]	周龙保.内燃机学[M].北京:机械工业出版社,2000.
[3]	荆晓东,徐寒清.航空活塞发动机使用[J].中国科技信息,2005(19A):77. JING Xiaodong,XU Hanqing.Use of the aero piston engine[J].China Science and Technology Information,2005(19A):77.(in Chinese)
[4]	李卫东,赵廷渝.航空活塞动力装置[M].成都:西南交通大学出版社,2004.
[5]	Morel T,Fort E,Blumberg P.Effect of insulation strategy and design parameters on diesel heat rejection and performance .SAE Trans.850506,1985.
[6]	XIN Jun,Shih S,Itano E.Integration of 3D combusion simulation and conjugate heat transfer analysis to quantitatively evaluate component temperatures .SAE Paper 2003-01-3128,2003.
[7]	陶文铨.数值传热学[M].2版.西安:西安交通大学出版社,2004.
[8]	陈红岩,李迎,俞小莉.柴油机流固耦系统稳态传热数值仿真[J].农业机械学报,2007,38(2):56-60. CHEN Hongyan,LI Ying,YU Xiaoli.Numerical simulation study on steady heat transfer of fluid-solid coupled system in diesel engine[J].Transactions of the Chinese Society for Agricultural Machinery,2007,38(2):56-60.(in Chinese)
[9]	赵宏国,白敏丽.耦合法在柴油机传热研究中的应用[J].小型内燃机与摩托车,2007,36(6):1-5. ZHAO Hongguo,BAI Minli.Application of coupled methods on heat transfer of diesel engine[J].Small Internal Combustion Engine and Motorcycle,2007,36(6):1-5.(in Chinese)
[10]	姜明.基于ANSYS的内燃机活塞-缸套耦合系统的传热模拟[J].科学技术与工程,2008,8(6):1437-1440. JIANG Ming.Simulation of coupled methods on heat transfer of internal combustion engine based on ANSYS[J].Science Technology and Engineering,2008,8(6):1437-1440.(in Chinese)
[11]	陈红岩,李迎,李孝禄.柴油机流固耦合传热仿真研究[J].中国计量学院学报,2006,17(4):284-288. CHEN Hongyan,LI Ying,LI Xiaolu.Simulation study on the fluid-solid coupled heat transfer of diesel engine[J].Journal of China Jiliang University,2006,17(4):284-288.(in Chinese)
[12]	李迎,俞小莉.发动机冷却系统流固耦合稳态传热三维数值仿真[J].内燃机学报,2007,25(3):252-257. LI Ying,YU Xiaoli.3-D simulation of steady heat transfer of fluid-solid coupled system in engine coolant system[J].Transactions of CSICE,2007,25(3):252-257.(in Chinese)
[13]	赵立峰,李云清.风冷航空发动机的活塞形状恢复研究[J].航空动力学报,2009,24(10):2255-2259. ZHAO Lifeng,LI Yunqing.Piston reshapes study for the air-cooled engine of aerial vehicle[J].Journal of Aerospace Power,2009,24(10):2255-2259.(in Chinese)
[14]	钟春敏.内燃机燃烧过程数学模拟的研究现状及其发展[J].科技与经济,2004,6(10):36-38. ZHONG Chunmin.Research on mathematics simulation during the combustion for internal combustion engine[J].Technology and Economy in Aeras of Communications,2004,6(10):36-38.(in Chinese)
[15]	Woshni G,Fieger J.Determination of local heat transfer coefficients at the piston of a high speed diesel engine by evaluation of measured temperature distribution .SAE Paper 790834,1979.
[16]	俞小莉,郑飞,严兆大.内燃机气缸体内表面稳态传热边界条件的研究[J].内燃机学报,1987,5(4):324-332. YU Xiaoli,ZHENG Fei,YAN Zhaoda.Study on steady heat transfer condition of cylinder surface in internal combustion engine[J].Transactions of CSICE,1987,5(4):324-332.(in Chinese)
[17]	郑飞,严兆大.风冷柴油机的传热与热负荷[J].内燃机学报,1985,3(1):77-88. ZHENG Fei,YAN Zhaoda.Study on heat transfer and heat duty of air-cooled engine[J].Transactions of CSICE,1985,3(1):77-88.(in Chinese)
[18]	朱访君,吴坚.内燃机工作过程数值计算及其优化[M].北京:国防工业出版社,1997.
