加力式涡扇发动机非加力状态部件红外辐射分析

黄伟; 吉洪湖

加力式涡扇发动机非加力状态部件红外辐射分析

黄伟^1,2,
吉洪湖¹

1.
南京航空航天大学能源与动力学院,南京 210016
2.
中国人民解放军徐州空军学院航空四站系,徐州 221000

基金项目: 国防基础研究

计量
- 文章访问数: 1555
- HTML浏览量: 3
- PDF量: 11
- 被引次数: 0
出版历程
- 收稿日期: 2009-11-23
- 修回日期: 2010-04-04
- 刊出日期: 2011-01-28

Analysis of components infrared radiation of afterburning turbofan engine under non-afterburning condition

HUANG Wei^1,2,
JI Hong-hu¹

1.
College of Energy and Power Engineering, Nanjing University of Aeronautics and Astronautics,Nanjing 210016,China
2.
Department of Aerial Four Stations,Xuzhou Air Force College, The Chinese Peoples Liberation Army,Xuzhou 221000,China

摘要

摘要: 采用反向蒙特卡罗法计算分析了加力式涡扇发动机非加力状态各固体壁面的有效辐射强度(包括自身辐射强度和反射辐射强度)、燃气辐射强度以及总辐射强度特性,并对它们的分布规律进行了讨论分析.结果表明:在新计算分析的状态中,中心锥是探测角度小于15°时的主要红外辐射源,在尾向贡献了最大辐射强度的65%以上;在探测角小于20°的范围内,末级涡轮叶片和径向稳定器是次于中心锥的重要红外辐射源;喷管扩张段对整个后半球的红外辐射都有明显的贡献,尤其是探测角度大于20°以后;中心锥、末级涡轮叶片和径向稳定器等部件的反射辐射强度不足自身辐射强度的10%.
- 涡扇发动机 /
- 加力燃烧室 /
- 红外辐射 /
- 自身辐射 /
- 反射辐射 /
- 反向蒙特卡罗
Abstract: The effective infrared radiation intensity (self-radiation intensity and reflected radiation intensity),gas radiation intensity and total radiation intensity of afterburning turbofan engine under non-afterburning condition were calculated and analyzed using reverse Monte-Carlo method.The distributions of them were discussed and analyzed.The results show that,under the conditions given hereto,the cone is the strongest infrared radiation source,which contributes more than 65% to the maximum infrared radiation intensity;the turbine blade and radial flame holder are the second ones when the detective angle is less then 20°;the divergent part of nozzle plays an important role to the spatial distribution of infrared radiation towards the aft-hemisphere,especially in the region with detective angle bigger than 20°;the reflected radiation intensity of cone,turbine blade and radial are less than 10% of the self-radiation intensity.
- turbofan engine /
- afterburner /
- infrared radiation /
- self-radiation /
- reflected radiation /
- reverse Monte-Carlo

HTML

参考文献(12)

[1]	Rao G A,Mahulikar S P.Effect of atmospheric transmission and radiance of aircraft infrared signatures[J].Journal of Aircraft,2005,42(4):1046-1054.
[2]	《航空发动机手册》编委会.航空发动机手册(第七分册)进排气装置[M].北京:航空工业出版社,2002:276-277.
[3]	金捷,朱谷君,徐南荣,等.发动机高速排气系统红外辐射特性的数值计算和分析[J].航空动力学报,2002,17(5):582-585. JIN Jie,ZHU Gujun,XU Nanrong,et al.Numerical simulation of infrared radiation characteristics for aeroengine high-speed exhaust system[J].Journal of Aerospace Power,2002,17(5):582-585.(in Chinese)
[4]	额日其太,王强,陈渭鹏.两种涡扇发动机排气系统红外辐射特性的比较[J].推进技术,2003,24(4):334-336. Eriqitai,WANG Qiang,CHEN Weipeng.Comparative investigation of the infrared characteristics for two exhaust systems of a turbofan engine[J].Journal of Propulsion Technology,2003,24(4):334-336.(in Chinese)
[5]	吴剑锋,何广军,赵玉芹.飞机尾向的红外辐射特性计算[J].空军工程大学学报(自然科学版),2006,7(6):26-28. WU Jianfeng,HE Guangjun,ZHAO Yuqin.The calculation for strength of infrared radiation in the opposite direction of the airplane[J].Journal of Air Force Engineering University(Natural Science Edition),2006,7(6):26-28.(in Chinese)
[6]	刘友宏,卲万仁,张锦绣.发动机排气系统及尾喷流的流场和红外特征数值模拟[J].航空动力学报,2008,23(4):591-597. LIU Youhong,SHAO Wanren,ZHANG Jinxiu.Numerical simulation of flow field and infrared characteristics of an aeroengine exhaust system and its plume[J].Journal of Aerospace Power,2008,23(4):591-597.(in Chinese)
[7]	单勇,张靖周,卲万仁,等.某型涡扇排气系统缩比模型红外辐射特性实验[J].航空动力学报,2009,24(10):2228-2234. SHAN Yong,ZHANG Jingzhou,SHAO Wanren,et al.Experiments on infrared radiation characteristics of exhaust system for a turbofan engine[J].Journal of Aerospace Power,2009,24(10):2228-2234.(in Chinese)
[8]	邓洪伟,周胜田,卲万仁,等.航空发动机排气系统红外辐射特征数值计算研究[J].航空发动机,2009,35(1):26-29. DENG Hongwei,ZHOU Shengtian,SHAO Wanren,et al.Numerical calculation of infrared characteristics for aeroengine exhaust system[J].Aeroengine,2009,35(1):26-29.(in Chinese)
[9]	ZHANG Jiandong,WANG Zhanxue,CAI Yuanhu.Computation of an exhaust system flow field and infrared radiaiton .AIAA 2009-4904,2009.
[10]	Everson J.Development and application of a reverse Monte Carlo radiative transfer code for rocket plume base heating .AIAA 93-0138,1993.
[11]	Modest M F.Radiative heat transfer[M].2nd ed.San Diego:Academic Press,2003.
[12]	谈和平,夏新林,刘林华,等.红外辐射特性与传输的数值计算——计算热辐射学[M].哈尔滨:哈尔滨工业大学出版社,2006.
