横流对冲击射流换热特性影响机理的数值研究

张传杰; 孙纪宁; 谭屏

横流对冲击射流换热特性影响机理的数值研究

北京航空航天大学能源与动力工程学院航空发动机气动热力科技重点实验室,北京 100191

基金项目: 中央高校基本科研业务费专项资金(YWF-10-02-043); “凡舟”青年科研基金(20080402)

计量
- 文章访问数: 1468
- HTML浏览量: 1
- PDF量: 10
- 被引次数: 0
出版历程
- 收稿日期: 2009-11-27
- 修回日期: 2010-04-21
- 刊出日期: 2011-01-28

Numerical investigation on heat transfer mechanism of impingement jet with cross-flow

National Key Laboratory of Science and Technology on Aero-Engines, School of Jet Propulsion,Beijing University of Aeronautics and Astronautics, Beijing 100191,China

摘要

摘要: 采用数值模拟的方法对冲击腔上游冲击产生的横流对下游冲击射流的影响进行了研究.结果表明,①随横流增大,射流冲击靶面平均努塞尔数呈现复杂的变化规律.②横流对冲击靶面平均努塞尔数的影响主要体现在两个方面:随横流雷诺数增大,冲击下游的拉伸涡对强度呈现先增大后减小的趋势,对换热的影响也是先增大后减小;横流使冲击射流偏移,导致高换热区域后移.③射流和横流对于换热强度的影响随着横流增大不断变化,造成冲击靶面复杂的换热规律.
- 横流 /
- 冲击射流 /
- 马蹄涡 /
- 数值模拟 /
- 换热
Abstract: Numeration analysis was made to simulate the influence induced by upstream jet on downstream jets in impingement chamber.The results shows that,(1) As the cross-flow increases,the heat transfer efficiency on the impinged surface changes in a very complicated way.(2) Cross-flow influences the heat transfer of the impinged surface mainly in two aspects:as the cross-flow Reynolds number increases,the strength of stretched vortex pair downstream of the jet firstly increases and then decreases,resulting in the same influence on the heat transfer of the target surface;the deviation of the impinging jet induced by cross-flow makes the high heat transfer zone move backward. (3) As cross-flow increases,the heat transfer efficiency induced by impingement and cross-flow changes,making the heat transfer on the target surface more complicated.
- cross-flow /
- impingement jet /
- horseshoe vortex /
- numerical simulation /
- heat transfer

HTML

参考文献(12)

[1]	Taslim M E,Bethka D.Experimental and numerical impingement heat transfer in an airfoil leading-edge cooling channel with cross-flow[J].ASME Journal of Turbomachinery,2009,131(1):011021(7 pages).
[2]	谭蕾,张靖周,谭晓茗.非均匀横流作用下冲击射流冷却的数值研究[J].航空动力学报,2006,21(3):528-532. TAN Lei,ZHANG Jingzhou,TAN Xiaoming.Numerical investigation of jet impingement cooling with non-uniform crossflow[J].Journal of Aerospace Power,2006,21(3):528-532.(in Chinese)
[3]	张大林,常海萍,韩东.有初始横流的冲击壁面强化的换热特性实验研究[J].航空动力学报,1996,11(1):269-272. ZHANG Dalin,CHANG Haiping,HAN Dong.An experimental study of heat transfer by jet impingement on roughened surface with initial crossflow[J].Journal of Aerospace Power,1996,11(1):269-272.(in Chinese)
[4]	Pamula G,Ekkad S V,Acharya S.Influence of crossflow-induced swirl and impingement on heat transfer in a two-pass channel connected by two rows of holes [J].ASME Journal of Turbomachinery,2001,123(2):281-287.
[5]	Florschuetz L W,Truman C R,Metzger D E.Streamwise flow and heat transfer distributions for jet array impingement with crossflow[J].ASME Journal of Heat Transfer,1981,103(2):337-342.
[6]	Florschuetz L W,Metzger D E,Su C C.Heat transfer characteristics for jet array impingement with initial crossflow[J].ASME Journal of Heat Transfer,1984,106(1):34-41.
[7]	Metzger D E,Florschuetz L W,Takeuchi D I,et al.Heat transfer characteristics for inline and staggered arrays of circular jets with crossflow of spent air[J].ASME Journal of Heat Transfer,1979,101(3):526-531.
[8]	Katti V V,Prabhu S V.Influence of spanwise pitch on local heat transfer for multiple jets with crossflow[J].Journal of Thermophysics and Heat Transfer,2008,22(4):654-668.
[9]	Katti V V,Prabhu S V.Influence of streamwise pitch on the local heat transfer characteristics for in-line arrays of circular jets with crossflow of spent air in one direction[J].Heat Mass Transfer,2009,45(9):1167-1184.
[10]	Goldstein R J,Behbahani A I.Impingement of a circular jet with and without cross flow[J].International Journal of Heat and Mass Transfer,1982,25(9):1377-1382.
[11]	Bouchez J P,Goldstein R J.Impingement cooling from a circular jet in a cross flow[J].International Journal of Heat and Mass Transfer,1975,18(6):719-730.
[12]	Spring S,Weigand B,Krebs W,et al.CFD heat transfer predictions of a single circular jet impinging with crossflow //Proceedings of 9th AIAA/ASME Joint Thermophysics and Heat Transfer Conference.San Francisco,CA,USA:AIAA/ASME,2006:1-11.
