缝式处理机匣轴向位置对压气机特性影响的机理
Mechanism of influences of axial positions of axial skewed slot casing treatment on a compressor performance
-
摘要: 对轴向倾斜缝处理机匣轴向位置的改变如何影响轴流压气机性能进行了研究.试验与数值结果均表明三个轴向位置的处理机匣均扩宽压气机的稳定工作范围,轴向位置不变时扩稳效果最好,轴向位置后移时效果最差.同时轴向位置前移或后移使压气机等熵效率损害程度降低.通过详细地分析压气机内部流场表明:处理机匣轴向位置后移使叶顶机匣约1/3的轴向弦长宽度无处理机匣,因此不能抑制叶顶泄漏流的发展,后移处理机匣缝的抽吸能力弱,致使扩稳效果差;与处理机匣轴向位置未变时比较,轴向位置前移或后移能够减少间隙流及二次流带来的流动损失,并使叶顶加功量上升,使压气机转子等熵效率提高.Abstract: Two investigations were performed for an axial-flow compressor rotor to explore the effects of axial positions of axial skewed slot casing treatment on the rotor performance.The steady operating range of compressor rotor was extended and the compressor efficiency was reduced with all casing treatments in the experimental and numerical investigations.The ability to improve the rotor steady operating range was the best when the axial position of casing treatment was unchanged.The ability was depressed obviously by moving the axial position of casing treatment backwards.The degree of damage on compressor isentropic efficiency was decreased when the axial position of casing treatment was moved forwards or backwards.The detailed analyses of the flow-filed in compressor with casing treatment indicate that,the development of tip leakage vortex could not been restrained by moving the axial position of casing treatment backwards,and the pumping ability of slot was reduced likewise,thus weakening the effect of extending the steady operating range of compressor;the work of blade forcing on air in the blade tip was not only increased,but also the flow loss caused by tip leakage flow and secondary flow were reduced when the axial position of casing treatment was moved forwards or backwards,making the rotor isentropic efficiency increase if compared the slot with axial position unchanged.
-
Key words:
- compressor /
- casing treatment /
- axial position /
- the leakage flow /
- the flow loss
-
[1] Moss J E,Jr.Effect of slotted casing treatment on performance of a multistage compressor .NASA TM X-3350,1976. [2] Osbor W M,Moore R D.Effect of casing treatment of axial-flow transonic fan stage with pressure ratio of 1.75 and tip solidity of 1.5 .NASA TM X-3477,1977. [3] Cheng P,Prell M E,Greitzer E M,et al.Effect of compressor hub treatment on stator stall margin and performance[J].Journal of Aircraft,1984,21(7):469-475. [4] Johnson M C,Greitzer E M.Effect of slotted hub and casing treatments on compressor endwall flow fields[J].ASME Journal of Turbomachinery,1987,109(3):380-387. [5] Smith G D.Casing treatment in an axial compressor .Cambridge,UK:University of Cambridge,1980. [6] Pundhir D S,Sharma P B,Chaudhary K K.Effect of casing treatment on aerodynamic performance of a contra-rotating axial compressor stage[J].Proceedings of the Institution of Mechanical Engineers,1990,240(1):47-55. [7] Fujita H,Takata H.A study on configurations of casing treatment for axial flow compressors[J].Bulletin of the JSME,1984,27(230):1675-1681. [8] 楚武利,刘志伟,朱俊强.折线斜缝式机匣处理的实验研究及机理分析[J].航空动力学报,1999,14(3):270-274. CHU Wuli,LIU Zhiwei,ZHU Junqiang.Experimental research and analysis of sloped slotted casing treatment[J].Journal of Aerospace Power,1999,14(3):270-274.(in Chinese) [9] Wilke I,Kau H P.A numerical investigation of the influence of casing treatments on the tip leakage flow in a HPC front stage .ASME Paper GT-2002-30642,2002. [10] Schnell R,Voges M,Mnig R,et al.Investigation of blade tip interaction with casing treatment in a transonic compressor:Part 2—Numerical results .ASME GT2008-50212,2008. [11] Wilke I,Kau H P.A numerical investigation of the flow mechanisms in a HPC front stage with axial slots .ASME Paper GT2003-38481,2003. [12] Emmrich R,Kunte R,Hnen H,et al.Time resolved investigation of an axial compressor with casing treatment:Part 2—Simulation .ASME Paper GT2007-27582,2007. -
