黏性彻体力建模方法及其应用

刘超; 宁方飞

黏性彻体力建模方法及其应用

刘超,
宁方飞

北京航空航天大学能源与动力工程学院,北京 100191

基金项目: 航空科学基金(2009ZB51022)

计量
- 文章访问数: 1766
- HTML浏览量: 69
- PDF量: 16
- 被引次数: 0
出版历程
- 收稿日期: 2009-11-11
- 修回日期: 2010-04-06
- 刊出日期: 2011-01-28

Investigation on distributed viscous body force modeling and its application

School of Jet Propulsion, Beijing University of Aeronautics and Astronautics,Beijing 100191,China

摘要

摘要: 研究了将Navier-Stokes方程中黏性项简化为黏性彻体力的建模方法,并将该模型加入已有的计算流体力学(CFD)程序中,实现了用三维欧拉方程加黏性彻体力模型快速模拟叶轮机三维非定常流动的方法.使用该方法对进气周向总压畸变条件下的某双级压气机非定常流场进行了模拟,并与雷诺平均的Navier-Stokes(RANS)程序的计算结果进行了对比,结果表明,基于黏性彻体力模型的方法能以很少的计算资源给出与RANS模拟基本相当的计算结果.
- 黏性彻体力模型 /
- 进气畸变 /
- 三维非定常流 /
- 多级压气机 /
- 压气机稳定性
Abstract: The modeling method of viscous terms of Navier-Stokes equations using distributed viscous body forces was investigated.Then a fast calculation code for the three-dimensional(3-D)unsteady flow in turbomachine was developed,by solving 3-D unsteady Euler equations with the distributed viscous body force model.The code was used to simulate the unsteady flow in a two-stage compressor under circumferential total pressure inlet distortion,and the results were compared with Reynolds averaged Navier-Stokes(RANS) results.This demonstrates that,in the simulation of the unsteady flow in the multi-stage compressor under inlet distortion,the results obtained by the distributed viscous body force model agree well with the RANS results,with substantially less computational cost.
- distributed viscous body force model /
- inlet distortion /
- three-dimensional（3-D）unsteady flow /
- multi-stage compressor /
- compressor stability

HTML

参考文献(12)

[1]	赵勇.某风扇／增压级非设计点性能计算及进气畸变影响分析[J].航空动力学报,2007,22(7):1087-1092. ZHAO Yong.Analysis of the influence of inlet flow distortion on the off-design performance of fan/booster [J].Journal of Aerospace Power,2007,22(7):1087-1092.(in Chinese)
[2]	王永明.进气畸变对轴流压气机性能影响的准三维计算[J].推进技术,2004,25(4):343-348. WANG Yongming.Quasi-3D calculation of influence of inlet distortion on axial flow compressor performance [J].Journal of Propulsion Technology,2004,25(4):343-348.(in Chinese)
[3]	Joo W G,Hynes T P.The simulation of turbomachinery blade rows in asymmetric flow using actuator disks [J].Journal of Turbomachinery,1997,119(4):723-732.
[4]	Gong Y,Tan C S,Gordon K A,et al.A computational model for short-wavelength stall inception and development in multistage compressors [J].Journal of Turbomachinery,1999,121(4):726-734.
[5]	Gong Y.A computational model for rotating stall and inlet distortions in multistage compressors .Cambridge,MA:Massachusetts Institute of Technology,1998.
[6]	Chima R V.A three-dimensional unsteady CFD model of compressor stability .ASME GT2006-90040,2006.
[7]	郑宁.风扇进气畸变三维非定常模拟技术研究[J].航空动力学报,2007,22(1):60-65. ZHENG Ning.3-D unsteady numerical simulation of fan/compressor with inlet distortion [J].Journal of Aerospace Power,2007,22(1):60-65.(in Chinese)
[8]	Meneveau C,Katz J.A deterministic stress model for rotor-stator interactions in simulations of average-passage flow [J].Journal of Turbomachinery,2002,124(2):550-554.
[9]	Xu L.Assessing viscous body forces for unsteady calculations [J].Journal of Turbomachinery,2003,125(3):425-432.
[10]	Xu L,Hynes T P,Denton J D.Towards long length scale unsteady modeling in turbomachines [J].Journal of Power and Energy,2003,217(1):75-82.
[11]	Denton J D.The use of a distributed body force to simulate viscous effects in 3D flow calculations .ASME Paper 86-GT-144,1986.
[12]	宁方飞.考虑真实几何复杂性的跨声压气机内部流动的数值模拟 .北京:北京航空航天大学,2002. NING Fangfei.Numerical simulation of the transonic compressor inner flow considering real geometrical complexity .Beijing:Beijing University of Aeronautics and Astronautics,2002.(in Chinese)
