二元保形非对称膨胀喷管流场特性

谢文忠; 郭荣伟

二元保形非对称膨胀喷管流场特性

南京航空航天大学能源与动力学院,南京 210016

计量
- 文章访问数: 1754
- HTML浏览量: 87
- PDF量: 15
- 被引次数: 0
出版历程
- 收稿日期: 2010-07-01
- 修回日期: 2010-10-10
- 刊出日期: 2011-01-28

Flow field characteristics of a two-dimensional integrated asymmetry-expansion nozzle

College of Energy and Power Engineering, Nanjing University of Aeronautics and Astronautics,Nanjing 210016,China

摘要

摘要: 利用数值模拟方法对一种与无人飞行器后体一体化设计的二元保形大宽高比非对称膨胀喷管在地面状态的流场特性进行了研究,获得了尾喷管推力性能和三维流动特征随落压比的变化趋势.结果表明:虽然二元保形非对称膨胀喷管沿横向存在非等强度膨胀,但在研究范围内最佳落压比仍主要取决于上方短膨胀面结束位置面积与喉道面积之比;沿横向不等强度膨胀诱发的二次流及旋涡流动能够增强环境冷流与喷流之间的掺混;在研究的落压比范围内,随着落压比的增加喷管的推力性能变化很缓慢.
- 非对称膨胀喷管 /
- 二元保形喷管 /
- 流场特性 /
- 二次流 /
- 数值模拟
Abstract: The flow field characteristics of a two-dimensional uninhabited combat air vehicle (UCAV) aft-body integrated asymmetry-expansion nozzle in ground condition were simulated using a numerical approach which has been validated by NASA (National Aeronautics and Space Administration) experimental data.This study was conducted at NPR (nozzle pressure ratios) from 2.0 to 5.5.Results indicate:(1) In spite of nonuniform expansion at different transverse slices of the UAV (unmanned aerial vehicle) aft-body integrated nozzle,the maximum propulsive performance strongly lies on area ratio of upper shorter ramp end location to the throat. (2) The mixture of internal jet and external cold air can be enhanced by secondary flow and vortex,which are induced by the nonuniform expansion at different transverse slices of the UAV aft-body integrated nozzle. (3) As the NPR increases within this study,the propulsive performance of the nozzle varies a little.
- asymmetry-expansion nozzle /
- two-dimensional integrated nozzle /
- flow field characteristics /
- secondary flow /
- numerical simulation

HTML

参考文献(12)

[1]	Johansson M.Propulsion integration in an UAV .AIAA Paper 2006-2834,2006.
[2]	理查森 D.现代隐身飞机[M].魏志祥,顾维征,李景忠,等,译.北京:科学出版社,1991.
[3]	郑礼宝.全尺寸二元喷管红外辐射特性研究[J].航空学报,2002,23(2):140-142. ZHENG Libao.Infrared emissions from turbojet with two dimensional nozzle[J].Acta Aeronautic et Astronautic Sinica,2002,23(2):140-142.(in Chinese)
[4]	张勃,吉洪湖.大宽高比矩形喷管的射流与外流掺混特性的数值研究[J].航空动力学报,2005,20(1):104-110. ZHANG Bo,JI Honghu.Numerical investigation of mixing characteristics of jets from rectangular nozzles with large aspect ratio[J].Journal of Aerospace Power,2005,20(1):104-110.(in Chinese)
[5]	张勃,吉洪湖,罗明东.宽高比对尾向可见明火矩形喷管红外抑制特性影响研究[J].航空动力学报,2007,22(11):1820-1825. ZHANG Bo,JI Honghu,LUO Mingdong.Research of the influence of aspect ratio on infrared suppressing characteristics of rectangular nozzles[J].Journal of Aerospace Power,2007,22(11):1820-1825.(in Chinese)
[6]	Capone F J,Re R J,Bare E A.Parametric investigation of single-expansion-ramp nozzles at Mach numbers from 0.60 to 1.20 .NASA-TP-3240,1992.
[7]	Berrier B L,Leavitt L D.Static internal performance of single-expansion-ramp nozzles with thrust-vectoring capability up to 60 deg .NASA-TP-2364,1984.
[8]	Capone F J,Re R J,Bare E A.Parametric study of single expansion ramp nozzles at subsonic/transonic speeds .AIAA Paper 87-1836.1987.
[9]	MacLean M K.Static internal performance tests of single expansion ramp nozzle concepts designed with LO considerations .AIAA Paper 93-2429,1993.
[10]	汪维娜,王占学,乔渭阳.单斜面膨胀喷管几何参数对流场和性能的影响[J].航空动力学报,2006,21(2):280-284. WANG Weina,WANG Zhanxue,QIAO Weiyang.Investigation of the influence of single expansion ramp nozzle geometric parameters on flow field and performance[J].Journal of Aerospace Power,2006,21(2):280-284.(in Chinese)
[11]	Capone F J,Schirmer A W.Static internal performance of a single expansion ramp nozzle with multiaxis thrust vectoring capability .NASA-TM-4450,1994.
[12]	黄宏艳,王强.V形尾缘喷管流场与红外特性的数值模拟[J].北京航空航天大学学报,2008,34(2):158-161. HUANG Hongyan,WANG Qiang.Numerical simulation on flow field and infrared characteristics[J].Journal of Beijing University of Aeronautics and Astronautics,2008,34(2):158-161.(in Chinese)
