航天控制力矩陀螺的润滑系统研究

盛明伟; 陈维山; 刘军考; 石胜君

航天控制力矩陀螺的润滑系统研究

哈尔滨工业大学机电工程学院,哈尔滨 150001

基金项目: 国家自然科学基金(50875057)

计量
- 文章访问数: 1682
- HTML浏览量: 1
- PDF量: 10
- 被引次数: 0
出版历程
- 收稿日期: 2009-12-09
- 修回日期: 2010-05-27
- 刊出日期: 2011-01-28

Simulation of lubricating system for control momentum gyroscopes in spacecraft

School of Mechatronics Engineering, Harbin Institute of Technology,Harbin 150001,China

摘要

摘要: 为了提高航天器控制力矩陀螺的使用寿命,提出一种可按需喷油润滑的润滑系统.润滑系统由储油器和基于按需喷墨(DOD)打印技术的压电润滑装置组成.为了解决润滑油液滴喷射过程中在液气两相流体界间连续拓扑变化问题,采用流体体积算法中的分段线性界面构造技术分析两相界面间的运动.基于两相流体积算法,利用计算机仿真方法对润滑油液滴喷射过程进行有限元分析.重点对不同喷孔形状和空间温度变化对润滑油微喷过程的影响情况进行了分析.实验结果表明,喷孔直径越大,产生液滴越困难;空间温度变化对润滑油液滴的速度有影响,但对液滴形成时间影响却很小.
- 控制力矩陀螺 /
- 润滑系统 /
- 两相流体积算法 /
- 喷射过程 /
- 空间温度
Abstract: To obtain a longer longevity of control momentum gyroscopes in spacecraft,a positive-feed on-demand lubricating system was proposed.The system consists of an oil container and a piezoelectric lubricating device based on drop on demand technology.To solve the interface movements with continuing topology changes during the ejection process,volume-of-fluid method along with the piecewise linear interface construction technique was implemented to describe the interfacial movements.A computational approach based on VOF(volume of fluid) method was applied to analyze the ejection process of lubricating oil droplet.In simulations,the ejection process of lubricating oil was examined by varying diameter of nozzle and temperature in the aerospace.The experimental results show that it is difficult to form droplet with larger nozzle,and the variety of space temperature has impact on the lubricating oil droplet velocity,but little effect on the formation time.
- control momentum gyroscope /
- lubricating system /
- volume-of-fluid method /
- ejection process /
- temperature in the aerospace

HTML

参考文献(13)

[1]	汪洋,刘秋生,阎嘉坪.空间液体润滑多孔储油器特性研究[J].空间科学学报,2008,28(6):592-596. WANG Yang,LIU Qiusheng,YAN Jiaping.Characteristic study on the porous reservoir of liquid lubricant in space [J].Chinese Journal of Space Science,2008,28(6):592-596.(in Chinese)
[2]	翁立军,刘维民,孙嘉奕,等.空间摩擦学的机遇和挑战[J].摩擦学学报,2005,25(1):92-95. WENG Lijun,LIU Weimin,SUN Jiayi,et al.Opportunities and challenges to space tribology [J].Tribology,2005,25(1):92-95.(in Chinese)
[3]	Jones W R,Jansen M J.Tribology for space applications[J].Proceedings of the Institution of Mechanical Engineers,Part J:Journal of Engineering Tribology,2008,222(8):997-1004.
[4]	Miyoshi K.Considerations in vacuum tribology (adhesion,friction,wear and solid lubrication in vacuum)[J].Tribology International,1999,32(11):605-616.
[5]	姚志雄,黄立峰,黄健.影响空间液体润滑的环境因素[J].润滑与密封,2005(3):155-157. YAO Zhixiong,HUANG Lifeng,HUANG Jian.The environmental factors to affect the performance of lubrication for space application [J].Lubrication Engineering,2005(3):155-157.(in Chinese)
[6]	陈晓伟,梁宇翔.液体空间润滑剂的现状与发展[J].润滑与密封,2006(6):176-178. CHEN Xiaowei,LIANG Yuxiang.Status and development of liquid space lubricants [J].Lubrication Engineering,2006(6):176-178.(in Chinese)
[7]	吴超,刘晓华.空间运动部件液体润滑加速寿命试验可行性分析[J].润滑与密封,2007,32(6):115-117. WU Chao,LIU Xiaohua.The feasibility analysis on the accelerated life test of liquid lubricated space mechanical moving components [J].Lubrication Engineering.2007,32(6):115-117.(in Chinese)
[8]	Roberts E W,Todd M J.Space and vacuum tribology[J].Wear,1990,136(1):157-167.
[9]	Conley P L,Bohner J J.Experience with synthetic fluorinated fluid lubricants //Proceedings of the 24th Aerospace Mechanisms Symposium.US:NASA,1990.
[10]	Asai A,Toshitami H,Ichiro E.One dimensional model of bubble growth and liquid flow in bubble jet printers[J].Japanese Journal of Applied Physics,1987,20(10):1794-1801.
[11]	Fromm J E.Numerical calculations of the fluid dynamics of drop-on-demand jets[J].IBM Journal of Research and Development,1984,28(3):322-333.
[12]	Asai A,Hirasawa S,Ichiro E.Bubble generation mechanism in the bubble jet recording process[J].Journal of Imaging Technology,1988,14(5):120-124.
[13]	Asai A.Three-dimensional calculation of bubble growth and drop ejection in a bubble jet printer[J].Journal of Fluids Engineering,1992,114(44):638-641.
