基于耗散函数的低速扩压叶栅损失机理探讨

刘华坪; 陈焕龙; 杨晓光; 陈浮

基于耗散函数的低速扩压叶栅损失机理探讨

哈尔滨工业大学能源科学与工程学院推进理论与技术研究所,哈尔滨 150001

基金项目: 国家自然科学基金(50976026)

计量
- 文章访问数: 1815
- HTML浏览量: 2
- PDF量: 11
- 被引次数: 0
出版历程
- 收稿日期: 2009-12-18
- 修回日期: 2010-03-30
- 刊出日期: 2011-02-28

Study of loss mechanism in low speed compressor cascade using dissipation function

Institute of Propulsion Theory and Technology, School of Energy Science and Engineering, Harbin Institute of Technology,Harbin 150001,China

摘要

摘要: 推导了含耗散函数项的总压输运方程,利用总压损失、熵增、耗散函数等参数分析某扩压叶栅流动与损失特性,探讨其损失产生机理.研究表明:栅内损失主要来源于叶片前缘附近、流道表面、尾迹区、分离区与主流交界区的流动耗散;分离区仅是高总压损失和高熵值的低能流体聚集区,而非高损失来源区;通过减小分离区以提高叶栅性能的控制方法本质是通过增加分离区的速度或减小分离区来减弱其与主流的剪切强度或减小强剪切作用区;控制叶片前缘附近附面层和马蹄涡的发展也是提高叶栅气动性能的途径之一.上述研究为叶栅流动损失控制研究提供了一种思路.
- 扩压叶栅 /
- 流动分离 /
- 损失来源 /
- 熵增 /
- 耗散函数
Abstract: The transport equation of total pressure containing dissipation function was derived.Through experimental and numerical studies of a low speed compressor cascade,the characteristics of flow and loss distribution were discussed in detail,then the loss mechanism was obtained.The results show that:the high cascade loss originates from dissipation in the area near the blade leading edge,blade and end wall surface,wakes,as well as the area between the separation and mainstream.Moreover,the separation zone is only a low-energy fluid gathering area for large total pressure loss and entropy rather than a zone of loss source.The essences of improving the cascade performance by controlling separation are weakening the shear strength and reducing the strong shear zone in the area between the separation and mainstream by increasing the velocity and reducing separation area.A method of improving the cascade performance by controlling the evolution of boundary layer and horseshoe vortex at the cascade inlet is recommended.This paper presents a new thought of controlling cascade losses.
- compressor cascade /
- flow separation /
- loss source /
- entropy increase /
- dissipation function

HTML

参考文献(12)

[1]	Van Zante D E,Wai M T,Chen J P.Blade row interaction effects on the performance of a moderately loaded NASA transonic compressor stage .ASME 2002-GT-30575,2002.
[2]	Jennions I K,Adamczyk J J.Evaluation of the interaction losses in a transonic turbine HP rotor/LP vane configuration[J].Journal of Turbomachinery,1997,119(1):68-76.
[3]	孙宇涛,任玉新.单级跨音速压气机内流场的非定常模拟及损失分析[J].清华大学学报(自然科学版),2009,49 (5):148-152. SUN Yutao,REN Yuxin.Simulation and unsteady loss analyses of the flow in single-stage transonic compressor[J].Journal of Tsinghua University(Science and Technology),2009,49 (5):148-152.(in Chinese)
[4]	Denton J D.Loss mechanisms in turbomachines[J].Journal of Turbomachinery,1993,115(4):621-656.
[5]	SONG Bo,Wing N G,Toyotaka S,et al.Loss mechanisms of high-turning supercritical compressor cascades[J].Journal of Propulsion and Power,2008,24(3):416-423.
[6]	Loughery R,Horn R A.Single stage experimental evaluation of boundary layer blowing and bleed techniques for high lift stator blades .NASA-CR-54573,1971.
[7]	Reijnen D P.Experimental study of boundary layer suction in a transonic compressor .Cambridge,MA:Massachusetts Institute of Technology,1997.
[8]	Merchant A A,Kerrebrock J L.Experimental investigation of a high pressure ratio aspirated fan stage .NASA/TM-2004-213080,2004.
[9]	FENG Dongmin,CHEN Fu,SONG Yanping,et al.Enhancing aerodynamic performances of highly loaded compressor cascades via air injection[J].Chinese Journal of Aeronautics,2009,22(2):121-128.
[10]	冯冬民,陈浮,陈焕龙,等.孔隙射流结构对扩压叶栅出口流场特性的影响[J].航空动力学报,2009,24(6):1364-1371. FENG Dongmin,CHEN Fu,CHEN Huanlong,et al.Effects of air injection on outlet flow field of compressor cascade[J].Journal of Aerospace Power,2009,24(6):1364-1371.(in Chinese)
[11]	CHEN Fu,SONG Yanping,CHEN Huanlong,et al.Effects of boundary layer suction on the performance of compressor cascades .ASME 2006-GT-90082,2006.
[12]	陈懋章.粘性流体力学基础[M].北京:高等教育出版社,2004:38-42. CHEN Maozhang.Fundamentals of vicious fluid dynamics[M].Beijing:Higher Education Press,2004:38-42.(in Chinese)
