涡轮风扇发动机紧凑压缩系统气动性能

阙晓斌; 侯安平; 周盛

涡轮风扇发动机紧凑压缩系统气动性能

北京航空航天大学能源与动力工程学院航空发动机气动热力国家级重点实验室,北京 100191

基金项目: 国家自然科学基金(60934001)

计量
- 文章访问数: 1548
- HTML浏览量: 2
- PDF量: 10
- 被引次数: 0
出版历程
- 收稿日期: 2010-01-06
- 修回日期: 2010-06-30
- 刊出日期: 2011-02-28

Aerodynamic performance investigation of a compact compression system for turbofan engine

National Key Laboratory of Science and Technology on Aero-Engine Aero-thermodynamics, School of Jet Propulsion,Beijing University of Aeronautics and Astronautics, Beijing 100191,China

摘要

摘要: 通过数值方法研究了由2级风扇、4级高压压气机及外涵组成的紧凑压缩系统的气动性能.探讨了双涵双轴压缩系统气动性能的评估方法及数值计算中相应的边界给定方法.通过对紧凑压缩系统的一体化数值模拟,分别获取了风扇及高压压气机的设计转速特性,并与设计值进行了对比,结果表明流量、压比、效率都达到了设计要求,而风扇失速裕度仅为7.8%,低于设计指标.对节流过程中流动分析表明,内涵节流时,压缩系统的失稳起始于高压压气机出口级;外涵节流时,风扇进口级叶尖泄露涡在通道激波作用下发生破裂,导致较大范围的堵塞,是压缩系统失稳的主要原因.
- 涡轮风扇发动机 /
- 风扇/压气机 /
- 紧凑压缩系统 /
- 双涵 /
- 分流环
Abstract: The performance of a compact compression system with fan-bypass-core compressor configuration was investigated numerically in this paper.The throttling methodology for accessing performance of fan-bypass-core compression system and its implementation during the numerical simulation was discussed.The calculated design speed performance of fan and high pressure compressor (HPC) shows that the design targets are achieved for mass flow,total pressure ratio and efficiency,while the stall margin of fan is only 7.8%,lower than the required value.Analysis of the flow field evolution shows that,during core nozzle throttling,the system instability is initiated in the exit stage of HPC;during bypass nozzle throttling,however,the large extent blockage,which is caused by the interaction of rotor tip vortex and passage shock,may contribute to the instability of the compression system.
- turbofan engine /
- fan/compressor /
- compact compression system /
- fan bypass /
- splitter

HTML

参考文献(16)

[1]	Hosny W M,Steenken W G.TF34 engine compression system computer study-simulation of flow stability .NASA-CR-159889,1979.
[2]	Dawes W N.Multi-blade row Navier-Stokes simulation of fan-bypass configurations .ASME Paper 91-GT-148,1991.
[3]	Sayma A I.Steady-flow analysis of low pressure compression system for turbofan engines .ASME Paper 2007-GT-27625,2007.
[4]	Vahdati M,Sayma A I,Freeman C,et al.On the use of atmospheric boundary conditions for axial-flow compressor stall simulations[J].Journal of Turbomachinery,2005,127(2):349-351.
[5]	Turner M G.Full 3D analysis of the GE90 turbofan primary flowpath .NASA/CR 2000-209951,2000.
[6]	Turner M G,Ryder R,Norris A.High fidelity 3D turbofan engine simulation with emphasis on turbomachinery-combustor coupling .AIAA 2002-3769,2002.
[7]	Turner M G,Norris A,Veres J P.High fidelity 3D simulation of the GE90 .AIAA 2003-3996,2003.
[8]	李晓娟,桂幸民.风扇／增压级设计与非设计性能数值模拟[J].推进技术,2005,26(6):522-525. LI Xiaojuan,GUI Xingmin.Numerical simulation of fan/compressor design and off-design performance[J].Journal of Propulsion Tchnology,2005,26(6):522-525.(in Chinese)
[9]	李晓娟,桂新民.风扇／增压级带间隙三维粘性流场数值模拟[J].北京航空航天大学报,2006,32(1):4-7. LI Xiaojuan,GUI Xingmin.Numerical simulation of three dimension viscous flow of fan／compressor with tip clearance[J].Journal of Beijing University of Aeronautics and Astronautics,2006,32(1):4-7.(in Chinese)
[10]	赵永辉.涡扇发动机风扇及内外涵道匹配的数值分析 .北京:中国科学院,2005. ZHAO Yonghui.Numerical analysis on matching between internal and external bypass and fan of aero-engine .Beijing:Chinese Academy of Sciences,2005.(in Chinese)
[11]	WU Hong,LI Qiushi,ZHOU Sheng.Optimization of highly loaded fan rotor based on throughflow model .ASME Paper 2007-GT-27603,2007.
[12]	YANG Yantao,WU Hong,LI Qiushi,et al.Vorticity dynamics in axial compressor flow diagnosis and design[J].Journal of Fluids Engineering,2008,130(4):1-9.
[13]	吴宏.高负荷风扇/压气机涡量动力学设计方法的应用研究 .北京:北京航空航天大学,2009. WU Hong.Design method based on vorticity dynamics for highly loaded fan/compressor .Beijing:Beijing University of Aeronautics and Astronautics,2009.(in Chinese)
[14]	陈玉春,徐思远,刘振德.涡扇发动机加减速控制规律设计的功率提取法[J].航空动力学报,2009,24(4):868-874. CHEN Yuchun,XU Siyuan,LIU Zhende.Power extraction method for acceleration and deceleration control law design of turbofan engine[J].Journal of Aerospace Power,2009,24(4):868-874.(in Chinese)
[15]	Riegler C,Bauer M,Kurzke J.Some aspects of modeling compressor behavior in gas turbine performance calculations .ASME GT2000-574,2000.
[16]	Adamczyk J J,Greitzer E M.The role of tip clearance in high-speed fan stall[J].Journal of Turbomachinery,1993,115(1):28-38.
