压气机转子叶片颤振边界的预测方法

张小伟; 王延荣; 徐可宁

压气机转子叶片颤振边界的预测方法

北京航空航天大学能源与动力工程学院,北京 100191

基金项目: 国家重点基础研究发展计划(2007CB210103); 北京航空航天大学博士研究生创新基金

计量
- 文章访问数: 1757
- HTML浏览量: 1
- PDF量: 12
- 被引次数: 0
出版历程
- 收稿日期: 2009-12-15
- 修回日期: 2010-03-16
- 刊出日期: 2011-02-28

Prediction method of blade flutter boundary in a compressor stage

School of Jet Propulsion, Beijing University of Aeronautics and Astronautics,Beijing 100191,China

摘要

摘要: 通过发展的基于能量法的颤振数值预测方法得到了压气机转子叶片的颤振边界.将计算结构动力学(CSD)分析得到的叶片表面节点位移插值到耦合面的流体网格点上,并将设计的多层动网格技术应用于计算流体动力学(CFD)方法,实现叶栅振荡作用下的非定常分析,得到叶片表面的非定常气动功以及模态气动阻尼比.以某第一级压气机转子叶片为例,对比了不同振型、不同工况下的气动弹性稳定性,并最终在压气机转子特性图上给出了叶片的失速颤振边界.计算结果表明:所发展的数值预测方法可以用于分析压气机叶片的气动弹性稳定性,并通过模态气动阻尼比能够较好地给出压气机叶片的颤振边界.
- 叶片颤振 /
- 能量法 /
- 模态气动阻尼比 /
- 颤振边界 /
- 预测方法
Abstract: The blade flutter boundary in a compressor stage was obtained by the developed numerical prediction method based on the energy method.The displacements of blade surface structural nodes,obtained from the computational structural dynamics (CSD) analysis,were transferred to fluid interface grids,and the designed multi-layer moving grid technique was applied to computational fluid dynamics (CFD).The unsteady analysis under the oscillating cascades was achieved to calculate the unsteady aerodynamic work for aerodynamic modal damping ratio.For a certain first-stage compressor rotor,the aeroelastic stability of different operating conditions was investigated and compared at different blade modes.And the blade flutter boundary has been obtained by analyzing the distribution of aerodynamic modal damping ratio in compressor characteristic map.The results show that the developed numerical method for aerodynamic modal damping ratio to determine the flutter boundary is feasible to preliminarily predict the aeroelastic stability of compressor blade.
- blade flutter /
- energy method /
- aerodynamic modal damping ratio /
- flutter boundary /
- prediction method

HTML

参考文献(14)

[1]	周盛.叶轮机气动弹性力学引论[M].北京:国防工业出版社,1986.
[2]	Carta F O.Coupled blade-disk-shroud flutter instabilities in turbojet engine rotors[J].Journal of Engineering for Power,1967,89(3):419-426.
[3]	Bendiksen O O.Aeroelastic problems in turbomachines .AIAA Paper 90-1157,1990.
[4]	Moffatt S,He L.Blade forced response prediction for industrial gas turbines: PartⅠ-Methodologies .ASME Paper GT 2003-38640,2003.
[5]	He L.An Euler solution for unsteady flows around oscillating blades[J].Journal of Turbomachinery,1990,112(4):714-722.
[6]	Hall K C,Lorence C B.Calculation of three-dimensional unsteady flows in turbomachinery using the linearized harmonic euler equations .ASME Paper 92-GT-136,1992.
[7]	Kielb R E.CFD for turbomachinery unsteady flows-An aeroelastic design perspective .AIAA Paper 2001-16317,2001.
[8]	Ekici K,Voytovych D M,Hall K C.Time-linearized Navier-Stokes analysis of flutter in multistage turbomachines .AIAA 2005-836,2005.
[9]	张小伟,王延荣,张潇,等.涡轮机械叶片的流固耦合数值计算方法[J].航空动力学报,2009,24(7):1622-1626. ZHANG Xiaowei,WANG Yanrong,ZHANG Xiao,et al.Numerical method for fluid-structure interaction in turbomachinery bladings[J].Journal of Aerospace Power,2009,24(7):1622-1626.(in Chinese)
[10]	Kielb R E,Chiang H D.Recent advancements in turbomachinery forced response analysis .AIAA Paper 92-0012,1992.
[11]	Gottfried D A,Fleeter S.Aerodynamic damping predictions for turbomachine blade rows using a three-dimensional time marching simulation .AIAA Paper 99-2810,1999.
[12]	Sadeghi M,Liu F,Lai K L,et al.Application of three-dimensional interfaces for data transfer in aeroelastic computations .AIAA Paper 2004-5376,2004.
[13]	Hsiao C,Bendiksen O.Finite element calculations of transonic flutter in cascades .AIAA Paper 93-2083,1993.
[14]	宋兆泓.航空发动机典型故障分析[M].北京:北京航空航天大学出版社,1993.
