全流量补燃循环发动机系统参数模型与设计(Ⅰ)动力平衡特性
Parametric model and design of full flow staged combustion cycle engine system for (Ⅰ) engine balance characteristics
-
摘要: 为了深入理解全流量补燃循环发动机系统的特点,建立了全流量补燃循环发动机系统动力平衡模型,补充了压力平衡方程,研究了预燃室混合比对发动机系统参数的影响规律.研究结果表明:①富燃、富氧预燃室的混合比是相互匹配的,随着富燃预燃室混合比增大,富氧预燃室混合比减小,混合比组合的规律是保持富燃、富氧预燃室燃气做功能力的平衡;②随着富燃预燃室混合比增大,预燃室燃气温度升高,富燃预燃室燃气流量增大(富氧预燃室燃气流量减小),燃气做功能力增强,燃料泵(氧化剂泵)的扬程降低;③预燃室混合比直接决定了预燃室燃气温度,影响了预燃室燃气物性参数,参与了发动机系统的流量分配,控制了系统燃气做功能力,最终影响了泵的扬程.
-
关键词:
- 全流量补燃循环发动机 /
- 动力平衡 /
- 预燃室混合比 /
- 燃气做功 /
- 泵扬程
Abstract: The full flow staged combustion (FFSC) cycle engine balance model was established and the pressure relationship between the fuel-rich flow and the oxygen-rich flow was added in this model.These results show that (1) mixture ratios of preburners are matched for each other,mixture ratio of ox-rich preburner decreases with increasing mixture ratio of fuel-rich preburner,helping to balance the work of two side preburner gases;(2) with the increase of mixture ratio of fuel-rich preburner,the preburner gas temperature is enhanced,the fuel-rich preburner gas mass flowrate is enlarged (the ox-rich preburner gas mass flowrate reduced),the working ability of preburner gas is reinforced,and the fuel pump lift falls down(the oxidizer pump lift ascends);(3) the mixture ratio of preburner determines the preburner gas temperature,influences the preburner gas properties,participates in the mass flow distribution,controls the working ability of preburner gas,and then affects the pump lift. -
[1] Davis J A,Campbell R L.Advantages of a full-flow staged combustion cycle engine system .AIAA 97-3318,1997. [2] 陈杰.液体火箭发动机系统动力平衡参数通用计算方法[J].上海航天,1991(4):1-5. CHEN Jie.General calculation method for liquid rocket engine system power balance[J].Journal of Shanghai Space,1991(4):1-5.(in Chinese) [3] 陈杰,王克昌,陈启智.液氧/煤油推进剂液体火箭发动机循环动力平衡分析[J].国防科技大学学报,1992,14(2):53-58. CHEN Jie,WANG Kechang,CHEN Qizhi.Cycle power balance analysis for liquid rocket engine with LO2/RP-1 propellant combustion[J].Journal of National University of Defense Technology,1992,14(2):53-58.(in Chinese) [4] 许琨,张宝炯.液体火箭发动机运动循环参数通用计算方法的研究[J].宇航学报,1996,17(4):26-33. XU Kun,ZHANG Baojiong.Study of general calculating method for power cycle parameters of liquid rocket engine[J].Journal of Astronautics,1996,17(4):26-33.(in Chinese) [5] Christoph G.A modular method for the analysis of liquid rocket engine cycles .AIAA 95-2966,1995. [6] 黄卫东,朱恒伟,王克昌,等.液体发动机分级燃烧循环最高室压通用模块化计算方法[J].上海航天,1997(2):11-15. HUANG Weidong,ZHU Hengwei,WANG Kechang,et al.A general modular method for calculating the maximum combustion chamber pressure of the liquid engine with stage combustion cycles[J].Journal of Shanghai Space,1997(2):11-15.(in Chinese) [7] 黄卫东,朱恒伟,王克昌,等.液体火箭发动机功率平衡通用计算方法[J].国防科技大学学报,1998,20(2):22-25. HUANG Weidong,ZHU Hengwei,WANG Kechang,et al.A general method for the cycle power balance calculation of the liquid rocket engine[J].Journal of National University of Defense Technology,1998,20(2):22-25.(in Chinese) [8] 黄卫东,王克昌,陈启智.液体火箭发动机系统面向对象分析方法[J].中国空间科学技术,2000(4):48-53. HUANG Weidong,WANG Kechang,CHEN Qizhi.An object-oriented analysis method for liquid rocket engine system[J].Chinese Space Science and Technology,2000(4):48-53.(in Chinese) [9] 张一夫,张宝炯.分级燃烧循环发动机燃烧室最高室压的计算[J].上海航天,1992(3):4-9. ZHANG Yifu,ZHANG Baojiong.Calculation of maximum combustion chamber pressure of staged combustion cycle engine [J].Journal of Shanghai Space,1992(3):4-9.(in Chinese) [10] 朱森元.氢氧火箭发动机及其低温技术[M].北京:国防工业出版社,1995. [11] 张贵田.高压补燃液氧煤油发动机[M].北京:国防工业出版社,2005. [12] Hueter U,Hutt J J.NASAs next generation launch technology program—Next generation space access roadmap .AIAA 2003-6941,2003. -
