某微型发动机轴流涡轮与向心涡轮的气动性能及尺寸对比分析

夏晨; 黄国平; 邱建

某微型发动机轴流涡轮与向心涡轮的气动性能及尺寸对比分析

南京航空航天大学能源与动力学院,南京 210016

基金项目: 国家自然科学基金(50576034); 基础预研项目

计量
- 文章访问数: 1994
- HTML浏览量: 165
- PDF量: 26
- 被引次数: 0
出版历程
- 收稿日期: 2010-01-31
- 修回日期: 2010-07-03
- 刊出日期: 2011-03-28

Comparison research on performance and size of micro axial turbine and radial turbine

College of Energy and Power Engineering, Nanjing University of Aeronautics and Astronautics,Nanjing 210016,China

摘要

摘要: 为确定厘米级微型涡轮发动机在相对较大功率、流量需求时的涡轮形式,基于某直径为12cm的微型发动机样机开展研究.估算了该样机整机环境下单级轴流涡轮的做功能力,并按参数优选规律设计了一台微型轴流涡轮,将之与该样机采用的微型向心涡轮对比,分析了两种叶轮在功率、效率及尺寸质量方面的差别.研究表明:在先进微型发动机压比提高(>4)的情况下,涡轮为了保持效率且满足压气机更高功率需求,轴流式必须采用双级方案,向心式单级即可满足要求;在压气机压比为4~6条件下,进一步对比双级轴流与单级向心方案的结果显示,当流量小于500g/s时,向心式具有尺寸质量优势,发动机能实现较高的推质比.针对厘米级微型发动机,在发动机压比较高且没有超出单级向心涡轮做功能力的范围时,向心涡轮方案是更好的选择.
- 微型涡轮发动机 /
- 轴流涡轮 /
- 向心涡轮 /
- 压比 /
- 数值模拟
Abstract: The selection of an axial turbine or a radial turbine is a key problem for advanced micro-turbine engine with larger mass flow rate and power.A comparative research was completed to determine the suitable turbine form.For a micro-turbine engine of 12 centimeters diameter,one-dimension estimative model of axial turbine was established,and the output characteristic of axial turbine was analyzed.A micro axial turbine was designed,and the differences of power,efficiency,size and mass between the axial turbine and radial turbine were compared.The results indicate that:axial turbine has more compact size and lighter mass,but radial turbine has larger power.For an advanced micro-turbine engine,when the total pressure ratio of the compressor exceeds 4,a two-stage scheme is required for the axial turbine to provide enough power output,rather than one-stage for radial turbine.The comparison between two-stage axial turbine and one-stage radial turbine indicates that,radial turbine-stage has smaller size and mass when the flow rate is less than 500g/s,and the total pressure ratio is 4~6,and the engine has a high thrust-mass ratio.So when a high pressure ratio is required but the power output of one-stage radial turbine isn't exceeded,the radial turbine has more advantages.
- micro-turbine engine /
- axial turbine /
- radial turbine /
- pressure ratio /

HTML

参考文献(12)

[1]	刘大响,金捷.21 世纪世界航空动力技术发展趋势与展望[J].中国工程科学,2004,6(9):1-8. LIU Daxiang,JIN Jie.Development tendency and prospect of world aerospace power techniques in 21 century[J].Engineering Science,2004,6(9):1-8.(in Chinese)
[2]	黄国平,温泉,李博,等.微型涡喷发动机顶层设计研究[J].航空动力学报,2003,18(6):832-838. HUANG Guoping,WEN Quan,LI Bo,et al.Top level design of micro turbine jet engine[J].Journal of Aerospace Power,2003,18(6):832-838.(in Chinese)
[3]	Harris M M,Jones A C,Alexander E J.Miniature turbojet development at Hamilton Sundstrand:the TJ-50,TJ-120 and TJ-30 turbojets .AIAA Paper 2003-6568,2003.
[4]	Yang H S,Rho M S,Park H Y,et al.Permanent magnet high speed starter/generator system development directly coupled to gas turbine engine for mobile auxiliary power unit .ASME Paper GT2004-53165,2004.
[5]	Kang Y,Mckeirnan R.Annular recuperator development and performance test for 200kW microturbine .ASME Paper GT2003-38522,2003.
[6]	梁德旺,黄国平.厘米级微型涡轮喷气发动机主要研究进展[J].燃气涡轮试验与研究,2004,17(2):9-13. LIANG Dewang,HUANG Guoping.Recent development and key techniques of micro-turbine in centimeter size[J].Gas Turbine Experiment and Research,2004,17(2):9-13.(in Chinese)
[7]	梁德旺,黄国平.厘米级微型涡轮喷气发动机发展现状及关键技术 .北京:中国航空学会航空百年学术论坛动力学分论坛第五届动力年会,2003.
[8]	黄治国,单鹏,王延荣.微型涡喷发动机结构设计研究[J].北京航空航天大学学报,2004,30(3):206-209. HUANG Zhiguo,SHAN Peng,WANG Yanrong.Structural design study of a micro-turbojet engine[J].Journal of Beijing University of Aeronautics and Astronautics,2004,30(3):206-209.(in Chinese)
[9]	Rodgers C.Review of mixed flow and radial turbine options .AIAA Paper 90-2414,1990.
[10]	舒士甄,朱力,柯玄龄,等.叶轮机械原理[M].北京:清华大学出版社,1991. SHU Shizhen,ZHU Li,KE Xuanling,et al.Turbo machinery theory[M].Beijing:Tsinghua University Press,1991.(in Chinese)
[11]	格拉兹曼.涡轮设计与应用[M].老文雄,许海荣,蔡睿贤,译.北京:国防工业出版社,1982. Gelaziman. Turbine design and application [M].LAO Wenxiong,XU Hairong,CAI Ruixian,trans.Beijing:National Defence Industry Press,1982.(in Chinese)
[12]	McLallin K L,Haas J E.Experimental performance and analysis of 15.04-centimeter-tip-diamenter,radial-inflow turbine with work factor of 1.126 and thick blading .NASA Paper TP 1730,1980.
