火花型合成射流激励器流动特性及其激励参数数值研究

单勇; 张靖周; 谭晓茗

火花型合成射流激励器流动特性及其激励参数数值研究

南京航空航天大学能源与动力学院,南京 210016

基金项目: 教育部博士点基金(200802871017,20070287040)

计量
- 文章访问数: 1918
- HTML浏览量: 402
- PDF量: 19
- 被引次数: 0
出版历程
- 收稿日期: 2010-01-26
- 修回日期: 2010-04-01
- 刊出日期: 2011-03-28

Numerical study of the flow characteristics and excitation parameters for the sparkjet actuator

College of Energy and Power Engineering, Nanjing University of Aeronautics and Astronautics,Nanjing 210016,China

摘要

摘要: 利用能量方程中的源项模拟电火花能量的输入,数值模拟了火花型合成射流激励器的流场,获得了激励器的能量蓄积、喷射和吸入过程.结果表明:电火花瞬间能量的输入产生了腔体内的高温、高压环境,从而诱发合成射流的形成;在周期性激励下,合成射流在3个周期后稳定,喷口处的速度呈现非正弦的周期性变化,射流喷射过程时间极短,吸入外界环境气体的过程时间较长,与压电式合成射流明显不同;喷口下游周期性出现的涡对强度大、卷吸能力强.在输入能量和腔体体积不变时,喷口速度随激发频率的增加,先增加后减小,存在最佳激发频率.激发频率的增加缩短了腔体内气体的冷却时间,实验时对激发频率的选取要考虑腔体的耐温能力.
- 火花型合成射流激励器 /
- 合成射流 /
- 数值模拟 /
- 流动特性 /
- 激励参数
Abstract: The way of using the source term in energy equation to simulate the input energy of actuator was reasonably compared with the experimental data for the sparkjet actuator.The processing of energy deposition,discharge and recovery of actuator was obtained.The instance energy input can produce the condition of high pressure and temperature in the actuator,inducing the formation of synthetic jet.Under the periodic action,the velocity of synthetic jet on the nozzle is stabilized on a non-sinusoidal law after three periodic times.The characteristic of short discharge time and long recovery time is different from the piezoelectric synthetic jet.The vortices pair at the downstream of nozzle with high intensity has an ability to roll environment air.While the input energy and actuator volume remain unchanged,the velocity at nozzle is enhanced firstly and then decreased with the increase of the excitation frequency.The recovery stage time is shortened with the increase of excitation frequency.So,the choice of excitation frequency is considered in view of the temperature resistance of actuator.
- sparkjet actuator /
- synthetic jet /
- numerical simulation /

HTML

参考文献(19)

[1]	Ingard U,Labate S.Acoustic circulation effects and the nonlinear impedance of orifices[J].Journal of the Acoustical Society of America,1950,22(2):211-218.
[2]	罗振兵,夏智勋.合成射流技术及其在流动控制中应用的进展[J].力学进展,2005,35(2):221-234. LUO Zhenbing,XIA Zhixun.Advances in synthetic jet technology and applications in flow control[J].Advances in Mechanics,2005,35(2):221-234.(in Chinese)
[3]	Luo Z B,Xia Z X,Liu B.New generation of synthetic jet actuators[J].AIAA Journal,2000,44(10):2418-2420.
[4]	刘艳明,伍耐明,董金钟,等.合成射流作用机理及其对共轴射流掺混的影响[J].北京航空航天大学学报,2007,33(1):5-9. LIU Yanming,WU Naiming,DONG Jinzhong,et al.Process mechanism of synthetic jet and its effect on the mixing in coaxial jets[J].Journal of Beijing University of Aeronautics and Astronautics,2007,33(1):5-9.(in Chinese)
[5]	赵宏,杨治国,娄慧娟.合成射流流动特性实验研究及在燃烧中的应用探讨[J].航空动力学报,2004,19(4):512-519. ZHAO Hong,YANG Zhiguo,LOU Huijuan.Experimental investigation of flow characteristics of synthetic jet and it's preliminary application to combustion[J].Journal of Aerospace Power,2004,19(4):512-519.(in Chinese)
[6]	张堃元,李念,董玥,等.零质量自耦合射流控制喷流矢量实验[J].推进技术,2004,25(3):224-226. ZHANG Kunyuan,LI Nian,DONG Yue,et al.Experimental investigation of flow vectoring by using zero-mass synthetic jets actuator[J].Journal of Propulsion Technology,2004,25(3):224-226.(in Chinese)
[7]	郝礼书,乔志德.合成射流用于翼型分离流动控制的研究[J].西北工业大学学报,2006,24(4):528-531. HAO Lishu,QIAO Zhide.Maximizing the effect of synthetic jet on airfoil separation flow control[J].Journal of Northwestern Polytechnical University,2006,24(4):528-531.(in Chinese)
[8]	Kiddy J,Chen P,Niemczuk J,et al.Active flow control using micro electro-mechanical systems .AIAA Paper 2000-1561,2000.
[9]	Zhong S,Jabbal M,Tang H,et al.Toward the design of sythetic jet actuators for full scale flight conditions[J].Flow,Turbulence and Combustion,2007,78(3-4):283-307.
[10]	谭晓茗,张靖周.自耦合射流流动特性和相关参数影响规律的数值研究[J].航空动力学报,2005,20(5):836-840. TAN Xiaoming,ZHANG Jingzhou.Numerical investigation of influence factors and flow characteristics for a synthetic jet[J].Journal of Aerospace Power,2005,20(5):836-840.(in Chinese)
[11]	谭晓茗,张靖周.多股自耦合射流相干流动和换热特性数值研究[J].航空动力学报,2008,23(4):642-646. TAN Xiaoming,ZHANG Jingzhou.Numerical study on the flow and heat transfer characteristics of coupled synthetic jets[J].Journal of Aerospace Power,2008,23(4):642-646.(in Chinese)
[12]	Davis S A,Glezer A.The manipulation of large- and small- scales in coaxial jets using synthetic jet actuators .AIAA Paper 2000-0403,2000.
[13]	李念,张堃元,沙江,等.不同出口型与驱动频率的活塞型自耦合射流研究[J].航空动力学报,2007,22(3):412-418. LI Nian,ZHANG Kunyuan,SHA Jiang,et al.Experimental investigation of the characteristics of synthetic jet with different orifice aspect ratio and frequency[J].Journal of Aerospace Power,2007,22(3):412-418.(in Chinese)
[14]	罗小兵,李志信,过增元.压电驱动合成喷的设计及分析[J].功能材料与器件学报,2001,7(2):116-120. LUO Xiaobing,LI Zhixin,GUO Zengyuan.Design and analysis of synthetic jet actuated by piezoelectric actuator[J].Journal of Functional Materials and Devices,2001,7(2):116-120.(in Chinese)
[15]	ZHANG Jingzhou,TAN Xiaoming.Experimental study on flow and heat transfer characteristics of synthetic jet driven by piezoelectric actuator[J].Science in China Series E:Technological Sciences,2007,50(2):221-229.
[16]	Parekh D E,Kibens V,Glezer A,et al.Innovative jet flow control:mixing enhancement experiments .AIAA 96-0308,1996.
[17]	Grossman K R,Cybyk B Z,Van Wie D M.Sparkjet actuators for flow control .AIAA Paper 2003-0057,2003.
[18]	Cybyk B Z,Wilkerson J T,Grossman K R.Performance characteristics of the sparkjet flow control actuator .AIAA Paper 2004-2131,2004.
[19]	Cybyk B Z,Grossman K R,Wilkerson J T.Single-pulse performance of the sparkjet flow control actuator .AIAA 2005-401,2005.
