基于代理模型的浮动壁式火焰筒壁温优化设计

郭家良; 温卫东; 崔海涛; 高建辉

基于代理模型的浮动壁式火焰筒壁温优化设计

南京航空航天大学能源与动力学院,南京 210016

计量
- 文章访问数: 1860
- HTML浏览量: 280
- PDF量: 15
- 被引次数: 0
出版历程
- 收稿日期: 2010-03-09
- 修回日期: 2010-05-24
- 刊出日期: 2011-03-28

Approximate model-based optimum design for wall temperature of floatwall

College of Energy and Power Engineering, Nanjing University of Aeronautics and Astronautics,Nanjing 210016,China

摘要

摘要: 为了使得浮动壁结构具有更好的冷却效果,开展了浮动壁壁温优化研究;将代理模型技术与遗传算法相结合,并发展应用于某气动参数下的浮动壁式火焰筒壁温优化设计,使浮动壁的平均壁温降低了2.4%;同时根据构造所得的代理模型,对浮动壁壁温随几何参数的变化规律展开分析,研究了壁温随孔径和冲击间距的变化规律.分析结果表明,在选择的尺寸约束范围内和气动参数条件下,浮动壁结构的冷却效果随着气膜孔直径D_d的增大而变好,随着冲击孔直径D_i的减小而变好,随着冲击间距 H的减小而变好.
- 浮动壁 /
- 火焰筒 /
- 代理模型 /
- 遗传算法 /
- 优化设计
Abstract: In order to realize better cooling effect for the floatwall structure,optimization study about the floatwall's wall temperature was performed;approximate model and genetic algorithm were combined;and the optimization method was developed and applied to the floatwall's wall temperature optimum design under a certain aerodynamic parameter.The results show that,the average temperature of the floatwall decreases by 2.4%.At the same time,according to the approximate model constructed,this paper analyzed the wall temperature's changing rules of the geometric parameters,and gained the changing rules of the aperture and the pitch of impact.The results show that:under the size constraints and aerodynamic parameters selected in this article,the cooling effect gets better with the enlargement of the film hole diameter,or with the reduction of the impaction hole diameter and the reduction of the pitch of impact.
- floatwall /
- flame tube /
- approximate model /
- genetic algorithm /

HTML

参考文献(12)

[1]	Mellor A M.Design of modern turbine combustor[M] .New York:Academic Press,1990.
[2]	赵清杰,李彬.浮动瓦块冷却结构在燃烧室中的应用和发展[J].燃气涡轮试验与研究,2001,14(1):10-13. ZHAO Qingjie,LI Bin.Application and development of floating panel cooling structure in combustors[J].Gas Turbine Experiment and Research,2001,14(1):10-13.(in Chinese)
[3]	胡超,许全宏,徐剑,等.冲击/发散冷却壁温分布和冷却效率研究[J].航空动力学报,2008,23(10):1800-1804. HU Chao,XU Quanhong,XU Jian,et al.Investigation of the wall temperature distribution and cooling efficiency for impingement/effusion cooling scheme[J].Journal of Aerospace Power,2008,23(10):1800-1804.(in Chinese)
[4]	李彬,吉洪湖,江义军.冲击-发散冷却火焰筒浮动瓦片三维壁温计算分析[J].航空动力学报,2007,22(3):370-374. LI Bin,JI Honghu,JIANG Yijun.Numerical analysis of 3D temperature field of an impingement-effusion cooled flame tube floating tile[J].Journal of Aerospace Power,2007,22(3):370-374.(in Chinese)
[5]	葛继科,邱玉辉,吴春明,等.遗传算法研究综述[J].计算机应用研究,2008,25(10):2911-2916. GE Jike,QIU Yuhui,WU Chunming,et al.Summary of genetic algorithms research[J].Application Research of Computers,2008,25(10):2911-2916.(in Chinese)
[6]	Oyama A,Liou M S,Obayashi S.Transonic axial flow blade shape optimization using evolutionary algorithm and three-dimensional Navier-Stokes solver[J].AIAA 2002-5642,2002.
[7]	YU Yanglai,XIN Yuan.Blade design optimization with three-dimensional viscous analyses and hybrid optimization approach .AIAA-2002-5658,2002.
[8]	Giunta A A.Aircraft multidisciplinary design optimization using design of experiments theory and response surface modeling methods .Virginia:Virginia Polytechnic Institute,1997.
[9]	薛亮,韩万金.基于遗传算法与近似模型的全局气动优化方法[J].推进技术,2008,29(3):360-366. XUE Liang,HAN Wanjin.Global aerodynamic optimization method using genetic algorithms and surrogate model[J].Journal of Propulsion Technology,2008,29(3):360-366.(in Chinese)
[10]	Giunta A A,Wojtkiewicz S F,Jr,Eldred M S.Overview of modern design of experiments methods for computational simulations[J].AIAA 2003-0649,2003.
[11]	GAO Yuehua,WANG Xicheng.An effeetive warpage optimization method in injection molding based on kriging model[J].Intemational Journal of Advaneed Manufacturing Technology,2008,37(9-10):953-960.
[12]	李彬,吉洪湖,江义军,等.燃烧室壁冲击-逆向对流-气膜冷却特性的数值研究[J].航空动力学报,2007,22(3):365-369. LI Bin,JI Honghu,JIANG Yijun,et al.Numerical simulation for impingement-counter flow convection-film cooling of a combustor wall[J].Journal of Aerospace Power,2007,22(3):365-369.(in Chinese)
