时频展缩随机共振用于航空发动机转子故障检测

王国富; 张海如; 张法全; 叶金才

时频展缩随机共振用于航空发动机转子故障检测

1.
桂林电子科技大学信息与通信学院,桂林 541004
2.
中国科学院西安光学精密机械研究所,西安 710119

基金项目: 国家重点基础研究发展计划(2008CB317109); 预研基金(A1120106BW0315)

计量
- 文章访问数: 1702
- HTML浏览量: 169
- PDF量: 17
- 被引次数: 0
出版历程
- 收稿日期: 2010-06-13
- 修回日期: 2010-10-25
- 刊出日期: 2011-03-28

Incipient fault detection for aero-engine rotor based on frequency compression of stochastic resonance

1.
School of Information and Communication Engineering, Guilin University of Electronic Technology,Guilin 541004,China
2.
Xi'an Institute Optics and Precision Mechanics, Chinese Academy of Sciences,Xi'an 710119,China

摘要

摘要: 提出一种基于时频展缩的随机共振算法,用于检测转子早期故障信号,该方法充分利用了随机共振检测弱信号的优势,通过引入时频展缩,消除了随机共振系统对待测信号频率的限制,实现了在绝热近似理论下,从强噪声中提取出转子微弱早期故障信号.理论分析和实测结果表明:对埋在强噪声中的未知频率的早期故障信号,采用连续的压缩算法,以获得一个适当的输入信号到随机共振体系,根据输出信号共振谐振峰的变化,经反变换运算可得待测微弱故障信号的未知频率.与传统方法相比,计算速度提高了4个数量级,能在极限信噪比(信噪比-50dB)下,提取出目标信号.
- 航空发动机 /
- 转子 /
- 随机共振 /
- 时频展缩 /
- 早期故障检测 /
- 弱信号检测
Abstract: A frequency compression based on stochastic resonance (SR) for detecting incipient fault weak signal was presented because of the benefits of SR for detecting weak signals.The frequency limitation of SR was eliminated by introducing frequency compression.The incipient fault signal was detected from heavy noise under the condition of adiabatic approximation.Theoretical analysis and experiment results show that:to deal with the unknown incipient fault signals mixed with heavy noise,the mixed signal is compressed continuously to achieve a suitable frequency and then input to SR system.According to the change of resonance spectral peak value,the unknown incipient fault frequency can be obtained from heavy noise by inverse transform algorithm.Compared with traditional methods,the computing speed is increased by four magnitudes.The target signal is detected under -50dB.
- aero-engine /
- rotor /
- stochastic resonance (SR) /
- frequency compression /

HTML

参考文献(16)

[1]	Chiang H W D,Kuan C P,Li H L.Turbomolecular pump rotor-bearing system analysis and testing [J].Journal of Vacuum Science & Technology A:Vacuum,Surfaces,and Films,2009,27(5):1196-1203.
[2]	Wen P,Lu T W.Decoupling control of a twin rotor mimo system using robust deadbeat control technique[J].Control Theory & Applications,IET,2008,2(1):999-1007.
[3]	Yang S M,Huang C L.A hall sensor-based three-dimensional displacement measurement system for miniature magnetically levitated rotor[J].IEEE Sensors Journal,2009,9(12):1872-1878.
[4]	Drrell D G,Cossar C.A vibration-based condition monitoring system for switched reluctance machine rotor eccentricity detection[J].IEEE Transactions on Magnetics,2008,44(9):2204-2214.
[5]	Zhou J B,Meng G,Chen J Y.Bifurcation analysis of ultra short self-acting gas journal bearings for MEMS[J].IEEE Transactions on Industrial Electronics,2009,56(8):3188-3194.
[6]	陈果,李兴阳.航空发动机整机振动中的不平衡-不中-碰摩耦合故障研究[J].航空动力学报,2009,24(10):2277-2284. CHEN Guo,LI Xingyang.Study on imbalance-misal ign ment-rubbing coupling faults in aero-engine vibration[J].Journal of Aerospace Power,2009,24(10):2277-2284.(in Chinese)
[7]	Chau K T,Chan C C,Liu C H.Overview of permanent-magnet brushless drives for electric and hybrid electric vehicles[J].IEEE Transactions on Industrial Electronics,2008,55(6):2246-2257.
[8]	周海仑,陈果.航空发动机双转子-滚动轴承-机匣耦合系统动力学分析[J].航空动力学报,2009,24(6):1284-1291. ZHOU Hailun,CHEN Guo.Dynamic response analysis of dual rotor-ball bearing-stator coupling system for aero-engine[J].Journal of Aerospace Power,2009,24(6):1284-1291.(in Chinese)
[9]	鲁峰,黄金泉.航空发动机部件性能参数融合预测[J].航空学报,2009,30(10):1795-1800. LU Feng,HUANG Jinquan.Engine component performance prognostics based on decision fusion[J].Acta Aeronautica et Astronautica Sinica,2009,30(10):1795-1800.(in Chinese)
[10]	林敏,黄咏梅.调制与解调用于随机共振的微弱周期信号检测[J].物理学报,2006,55(7):3277-3282. LIN Min,HUANG Yongmei.Modulation and demodulation for detecting weak periodic signal of stochastic resonance[J].Acta Physica Sinica,2006,55(7):3277-3282.(in Chinese)
[11]	Chen H,Pramod K,Michels J H.Noise enhanced parameter estimation[J].IEEE Transactions on Signal Processing,2008,56(10):5074-5081.
[12]	Benzi R,Srutera A,Vulpiani A.The mechanism of stochastic resonance[J].Physics Letters A,1981,4(11):453-457.
[13]	Hartmann F,Hartmann D,Kowalzik P,et al.Stochastic resonance in a nonsocial Y-branch switch[J].Applied Physics Letters,2010,96(17):7210-7216.
[14]	Sowers R B.Averaging of stochastic flows:twist maps and escape from resonance[J].Stochastic Processes and Their Applications,2009,119(10):3549-3582.
[15]	Takatsugu A,Keiichi K,Daichi N,et al.Internal noise determines external stochastic resonance in visual perception[J].Vision Research,2008,48(14):1569-1573.
[16]	Mirko L,Massimiliano I,Leone F,et al.The rate matching effect:a hidden property of a periodic stochastic resonance[J].Physics Letters A,2008,372(15):2608-2913.
