动量轮维纳过程退化建模与寿命预测
Momentum wheel Wiener process degradation modeling and life prediction
-
摘要: 针对动量轮寿命预测无失效数据问题,利用有漂移的维纳过程对其轴承温度建立性能退化模型,同时,考虑由于加工工艺、制造误差等因素所造成的不确定性,利用随机变量来描述其漂移参数和扩散参数,并结合自助法获取纠偏估计.根据所建模型仿真了轴承温度维纳过程的样本路径,最后,对动量轮进行随机失效阈值情形的寿命预测和剩余寿命预测.该模型为动量轮退化建模与寿命预测提供了一种方法,理论与方法可推广用于类似的高可靠、长寿命产品的退化建模和寿命预测.Abstract: For the problem that there is no failure data to use in momentum wheel's life prediction, a model of the degradation of momentum wheel' bear temperature was established using Wiener process with drift.At the same time,considering of the uncertainty which was made by the process technics and manufacturing error, the drift and the diffusion parameters were described as stochastic variables,and the bias correction estimate was obtained using bootstrap method.And then, the sample path was simulated based on the established model.At last, the life prediction and residual life prediction were performed at the uncertain failure threshold.The model provides a method for the degradation modeling and life prediction of momentum wheel,and the theory and method can be generalized for the degradation modeling and life prediction of some similar high reliability and long life products.
-
Key words:
- life prediction /
- degradation modeling /
- Wiener process /
-
[1] 厉海涛,金光,周经伦,等.动量轮在轨状态可靠性贝叶斯网络建模与评估[J].航空学报,2009,30(6):1084-1089. LI Haitao,JIN Guang,ZHOU Jinglun,et al.Bayesian network reliability modeling and assessment of momentum wheel on orbit[J].Acta Aeronautica et Astronautica Sinica,2009,30(6):1084-1089.(in Chinese) [2] 刘强,周经伦,金光,等.基于可信度的动量轮Bayes可靠性评估[J].宇航学报,2009,30(1):382-386. LIU Qiang,ZHOU Jinglun,JIN Guang,et al.Bayesian reliability estimation for momentum wheel based on credibility[J].Journal of Astronautics,2009,30(1):382-386.(in Chinese) [3] 刘强,金光,周经伦.基于EMD的卫星动量轮性能可靠性建模[J].计算机仿真,2007,24(11):32-35. LIU Qiang,JIN Guang,ZHOU Jinglun.A modeling method of performance reliability of momentum wheel based on EMD[J].Computer Simulation,2007,24(11):32-35.(in Chinese) [4] 金光.一种综合性能与寿命数据的Bayes-bootstrap方法[J].宇航学报,2007,28(3):731-735. JIN Guang.A Bayes-bootstrap method synthesizing performance and life data[J].Journal of Astronautics,2007,28(3):731-735.(in Chinese) [5] 樊幼温,杨晓丽,李春伟,等.动量轮失效物理模型试验方案研究[J].空间科学学报,2009,29(1):78-86. FAN Youwen,YANG Xiaoli,LI Chunwei,et al.Experimental research on the momentum wheel failure physical model[J].Chinese Journal of Space Science,2009,29(1):78-86.(in Chinese) [6] Whitmore G A.Estimating degradation by a Wiener diffusion process subject to measurement error[J].Lifetime Data Analysis,1995,1(3):307-319. [7] Whitmore G A,Schenkelberg F.Modelling accelerated degradation data using Wiener diffusion with a scale transformation[J].Lifetime Data Analysis,1997,3(1):27-45. [8] Efron B,Tibshirani R.An introduction to the bootstrap[M].New York:Chapman & Hall,1993. [9] Efron B.More efficient bootstrap computations[J].J.Am Statist. Assoc.,1990,85(409):79-89. [10] YUAN Xianxun.Stochastic modeling of deterioration in nuclear power plant components .Ontario,Canada:University of Waterloo,2007. [11] Lee M LT,Whitmore G A.Threshold regression for survival analysis:modeling event times by a stochastic process reaching a boundary[J].Statistical Science,2006,21(4):501-513. [12] Balka J,Desmond A F,McNicholas P D.Review and implementation of cure models based on first hitting times for Wiener processes[J].Lifetime Data Analysis,2009,15(12):147-176.
