某直升机主减速器传动系统的寿命与可靠性计算方法

薛向珍; 李育锡; 王三民

某直升机主减速器传动系统的寿命与可靠性计算方法

西北工业大学机电学院,西安 710072

基金项目: 国家高技术研究发展计划(2009AA04Z404)

计量
- 文章访问数: 2318
- HTML浏览量: 245
- PDF量: 28
- 被引次数: 0
出版历程
- 收稿日期: 2010-02-28
- 修回日期: 2010-06-29
- 刊出日期: 2011-03-28

Method of lifetime and reliability of some helicopter's main reducer

School of Mechanical Engineering, Northwestern Polytechnical University,Xi'an 710072,China

摘要

摘要: 通过对直升机典型任务剖面原始载荷数据谱进行统计处理,经三维有限元分析将所编系统载荷谱转化为齿轮应力谱;结合Goodman公式及材料P-S-N曲线(给定存活率下的疲劳寿命曲线)算出该系统各齿轮在各级载荷下的疲劳寿命,利用统计软件Minitab对寿命数据进行分析,得出齿轮的接触疲劳寿命服从两参数威布尔分布,根据威布尔分布的可靠度函数计算出各传动部件的可靠度,并结合传动系统的混联可靠度模型,获得了主减速器的可靠度.为确定复杂传动系统的寿命与可靠性提供了方法.
- 直升机传动系统 /
- 载荷谱 /
- 疲劳寿命 /
- 可靠性 /
- 威布尔分布
Abstract: The reliability of the main reducer drive system was acquired by dealing with the original load date of a typical mission profile of the helicopter,the load spectrum was changed into the stress spectrum of all gears using three-dimensional finite element analysis;the fatigue life of all gears at each load stage was calculated with Goodman formula and materials P-S-N curves,the life date was analyzed using Minitab.It's concluded that the contact fatigue life of gears is subject to Weibull distribution with two parameters,thus working out the reliability of each transmission part according to the reliability function of Weibull distribution and based on series-to-parallel reliability model of the system.Then,this thesis can provide a method for determining life and reliability of complex drive systems.
- rotorcraft drive system /
- load spectrum /
- fatigue life /
- reliability /

HTML

参考文献(14)

[1]	McFarland J M,Riha D S.Uncertainty quantification methods for helicopter fatigue reliability analysis //Proceedings of the American Helicopter Society 65th Annual Forum.Grapevine,TX:American Helicopter Society,2009.
[2]	McFalls M,White D,Jackson A.Fatigue life analysis of helicopter components based on usage monitoring //Proceedings of the American Helicopter Society 60th Annual Forum.Baltimore,MD:American Helicopter Society,2004.
[3]	Giglio M,Manes A,Fossati M.Fatigue life analysis of Al 8090 helicopter fuselage panels[J].Key Engineering Materials,2007,348-349:637-640.
[4]	Brown M A,Chang J H.Analytical techniques for helicopter component reliability //Proceedings of the American Helicopter Society 64th Annual Forum.Montr'al,Canada:American Helicopter Society,2008.
[5]	Pulikollu R V,McDaniels R,Krishnan G.Model based fatigue life prediction for AA 7075-T651 .Huntsville,AL:American Helicopter Society International Condition Based Maintenance Specialists Meeting,2009.
[6]	杨芳芳.涡轮起动机齿轮传动系统动载分析与寿命预估 .西安:西北工业大学,2007. YANG Fangfang.Dynamic load analysis and life prediction of the turbine starter transmission system .Xi'an:Northwestern Polytechnical University,2007.(in Chinese)
[7]	Savage M,Paridon C A,Coy J J.Reliability model for planetary gear trains[J].Journal of Mechanisms,Transmissions,and Automation in Design,1983,105:291-297.
[8]	Rao S S.Reliability analysis and design of epicyclic gear trains [J].ASME Journal of Mechanical Design,1979,101(3):625-632.
[9]	胡青春,段福海,吴上生.封闭行星齿轮传动系统的可靠性研究[J].中国机械工程,2007,18(2):146-149. HU Qingchun,DUAN Fuhai,WU Shangsheng.Research on reliability of closed planetary transmission systems[J].China Mechanical Engineering,2007,18(2):146-149.(in Chinese)
[10]	郭耀斌,张文明,张国芬.基于蒙特卡罗法的螺旋锥齿轮接触疲劳可靠性分析[J].农业机械学报,2008,39(4):157-159. GUO Yaobin,ZHANG Wenming,ZHANG Guofen.Contact fatigue reliability analysis of spiral bevel gear based on Monte-Carlo[J].Transactions of the Chinese Society of Agricultural Machinery,2008,39(4):157-159.(in Chinese)
[11]	Chaari F,Fakhfakh T,Haddar M.Dynamic analysis of a planetary gear failure caused by tooth pitting and cracking [J].Journal of Failure Analysis and Prevention,2006,6(2):73-78.
[12]	吕文林,金家楣,宋乐民.伴有高频振动情况折叠传动轴疲劳寿命可靠度计算[J].机械科学与技术,1994(3):79-83 LV Wenlin,JIN Jiamei,SONG Lemin.Calculating the fatigue life and reliability of folding trassmission shaft with high frequency vibration[J].Mechanical Science and Technology,1994(3):79-83.(in Chinese)
[13]	徐灏,蔡春源,严隽琪.机械设计手册[M].2版.北京:机械工业出版社,2003.
[14]	Rhee S J,Ishii K.Using cost based FMEA to enhance reliability and serviceability[J].Advanced Engineering Informatics,2003,17(3-4):179-188.
