不同长度吸力面小翼对压气机叶栅间隙影响的数值研究

韩少冰; 钟兢军; 严红明

不同长度吸力面小翼对压气机叶栅间隙影响的数值研究

1.
大连海事大学轮机工程学院,大连 116026
2.
哈尔滨工业大学能源科学与工程学院,哈尔滨 150001

计量
- 文章访问数: 1751
- HTML浏览量: 83
- PDF量: 17
- 被引次数: 0
出版历程
- 收稿日期: 2010-03-09
- 修回日期: 2010-06-30
- 刊出日期: 2011-03-28

Influence of suction-side winglet length on tip leakage flow in compressor cascade

1.
Marine Engineering College,Dalian Maritime University,Dalian 116026,China
2.
School of Energy Science and Engineering, Harbin Institute of Technology,Harbin 150001,China

摘要

摘要: 对常规直叶栅和三种具有不同长度和起始位置的吸力面小翼叶栅内的三维黏性流场进行了数值模拟.结果表明,不同长度吸力面小翼都不同程度上改善了叶栅顶部的气流流动状况;在叶顶吸力面侧加装与其型线等长度的小翼可以较好地削弱泄漏涡的强度,随着叶顶间隙的增大,泄漏流动增强,其作用效果逐渐降低.
- 压气机叶栅 /
- 吸力面小翼 /
- 叶顶间隙 /
- 数值模拟 /
- 泄漏流
Abstract: The numerical simulation was performed to investigate the influence of the suction-side winglet with different lengthes on the tip leakage flow in compressor cascade.The simulation results show that the suction-side winglets can improve the tip clearance flow condition.It is found that the winglet is most effective to weaken the intensity of the leakage vortices if their length is the same with that of the blade tip.With increasing clearance and stronger intensity leakage flow,the winglet's effect is gradually decreased.
- compressor cascade /
- suction-side winglet /
- tip clearance /

HTML

参考文献(15)

[1]	邓向阳.压气机叶顶间隙流的数值模拟研究 .北京:中国科学院工程热物理研究所,2006. DENG Xiangyang.Numerical investigation on tip clearance flow in compressor .Beijing:Institute of Engineering Thermophysics,Chinese Academy of Sciences,2006.(in Chinese)
[2]	Moss J E.Effects of slotted casing treatment on performance of a multistage compressor .NASA TX-X-3360,1976.
[3]	Papa M,Goldstein R J,Gori F.Effects of tip geometry and tip clearance on the mass/heat transfer from a large-scale gas turbine blade .ASME Turbo.Expo.,GT-2002-30192,2002.
[4]	耿少娟,张宏武,朱俊强,等.喷气对低速轴流压气机转子叶顶区域流动的影响[J].工程热物理学报,2007,28(3):395-398. GENG Shaojuan,ZHANG Hongwu,ZHU Junqiang,et al.Effects of micro air injection on rotor tip flow in a low-speed isolated axial compressor rotor[J].Journal of Eneingeering Thermophysics,2007,28(3):395-398.(in Chinese)
[5]	韩万金,钟兢军,黄洪雁,等.具有叶顶间隙的涡轮正弯叶栅流场的拓扑分析与旋涡结构[J].空气动力学报,1999,17(2):141-149. HAN Wanjin,ZHONG Jingjun,HUANG Hongyan,et al.Topological and vortex structure of the flow field of positively curved cascade with the tip clearance[J].Acta Aerodynamica Sinica,1999,17(2):141-149.(in Chinese)
[6]	McNulty G S,Decker J.Beacher B F.The impact of forward swept rotors on tip clearance flows in subsonic axial compressors[J].Journal of Turbomachinery,2004,126(4): 445-454.
[7]	Morris S,Corke T,Van Ness D,et al.Tip clearance control using plasma actuators .AIAA-2005-782,2005.
[8]	郑国胜,戴韧.轴流风扇叶片端导叶作用的研究[J].工程热物理学报,2006,27(增1):165-168. ZHENG Guosheng,DAI Ren.An investigation on the effection of tip winglet of axial flow fan[J].Journal of Eneingeering Thermophysics,2006,27(Suppl.1):165-168.(in Chinese)
[9]	Camci C,Akturk A.Tip-leakage vortex minimization in ducted axial fans using novel pressure side tip platform extensions .Ankara:Ankara International Aerospace Conference,2007-METU,2007.
[10]	黄中华,陈泽,戴韧.带端导叶平面叶栅流动结构与性能的数值研究[J].流体机械,2008,36(6):30-33. HUANG Zhonghua,CHEN Ze,DAI Ren.CFD analysis of tip winglet effects on planar cascade flow[J].Fluid Machinery,2008,36(6):30-33.(in Chinese)
[11]	钟兢军,韩少冰,陆华伟.叶尖小翼对扩压叶栅气动特性影响的数值研究[J].工程热物理学报,2010,31(2):243-246. ZHONNG Jingjun,HAN Shaobing,LU Huawei.Numerical simulation of blade tip winglet on the aerodynamic performance of compressor cascade[J].Journal of Eneingeering Thermophysics,2010,31(2):243-246.(in Chinese)
[12]	Inoue M,Kuroumaru M.Structure of tip clearance flow in an isolated axial compressor rotor[J].Journal of Turbomachinery,1989,111(2):250-256.
[13]	Store J A,Cumpsty N A.Tip leakage flow in axial compressors[J].ASME Journal of Turbomachinery,1991,113(2):252-259.
[14]	Moore J,Ransmayr A.Flow in a turbine cascade PartⅠ:losses and leading-edge effects .ASME Paper 83-GT-68,1983.
[15]	Denton J D.Loss mechanisms in turbomachines .ASME 93-GT-435,1993.
