航空发动机涡轮榫接结构齿形 基本参数研究

申秀丽; 齐晓东; 王荣桥; 樊江; 刘海

航空发动机涡轮榫接结构齿形基本参数研究

1.
北京航空航天大学能源与动力工程学院,北京 100191
2.
中国航空工业集团公司沈阳发动机设计研究所,沈阳 110015

计量
- 文章访问数: 2621
- HTML浏览量: 2
- PDF量: 18
- 被引次数: 0
出版历程
- 收稿日期: 2010-03-15
- 修回日期: 2010-07-14
- 刊出日期: 2011-04-28

Research on the dentiform basic parameters of aero-engine turbine joint structure

1.
School of Jet Propulsion, Beijing University of Aeronautics and Astronautics,Beijing 100191,China
2.
Shenyang Aeroengine Research Institute, Aviation Industry Corporation of China,Shenyang 110015,China

摘要

摘要: 通过大量有限元分析和优化设计数值计算方法研究了楔形角、榫头颈宽、榫槽高度、上侧角、下侧角及拉削角等齿形基本参数对榫接结构强度的影响,并根据计算结果设计了新的结构模型,经过实验验证,新结构最大应力有所改善.研究表明,可以采用二维有限元分析结果来研究齿形基本参数对榫接结构应力分布的影响,但是其不能反映应力在轴向方向的变化.
- 榫头 /
- 榫槽 /
- 楔形角 /
- 拉削角 /
- 上侧角 /
- 光弹实验
Abstract: The impacts on joint structure strength of the dentiform basic parameters,such as wedge angle,blade root neck width,disc groove height,top flank angle,bottom flank angle and skew angle,were studied by lots of finite element and optimization design numerical methods.Based on the calculated results,a new model was established and verified experimentally,indicating that the maximum stress has been reduced.Results show that two-dimensional finite element analysis can be used to study the influence of dentiform basic parameters on the joint structure stress distribution,but this does not reflect changes of the stress in the axial direction.
- blade root /
- disc groove /
- wedge angle /
- skew angle /
- top flank angle /
