运输机翼型结冰的计算和实验

易贤 桂业伟 朱国林 杜雁霞

易贤, 桂业伟, 朱国林, 杜雁霞. 运输机翼型结冰的计算和实验[J]. 航空动力学报, 2011, 26(4): 808-813.
引用本文: 易贤, 桂业伟, 朱国林, 杜雁霞. 运输机翼型结冰的计算和实验[J]. 航空动力学报, 2011, 26(4): 808-813.
YI Xian, GUI Ye-wei, ZHU Guo-lin, DU Yan-xia. Experimental and computational investigation into ice accretion on airfoil of a transport aircraft[J]. Journal of Aerospace Power, 2011, 26(4): 808-813.
Citation: YI Xian, GUI Ye-wei, ZHU Guo-lin, DU Yan-xia. Experimental and computational investigation into ice accretion on airfoil of a transport aircraft[J]. Journal of Aerospace Power, 2011, 26(4): 808-813.

运输机翼型结冰的计算和实验

基金项目: 国家自然科学基金(10672174,10772191); 国家重点基础研究发展计划(2009CB723802)

Experimental and computational investigation into ice accretion on airfoil of a transport aircraft

  • 摘要: 采用数值计算和结冰风洞实验相结合的手段,对某运输机机翼剖面缩比翼型的结冰特性进行了研究.结冰实验在气动中心0.3m×0.2m结冰风洞中进行,实验模型为弦长0.18m的层流翼型.翼型的绕流流场通过求解低速黏流的时均Navier-Stokes(N-S)方程得到,采用拉格朗日法计算水滴撞击特性,在此基础上,求解结冰热力学模型,获得结冰外形.对计算和实验结果进行了对比分析,发现虽然局部冰形轮廓还存在差异,但计算和实验得到的冰形在结冰极限、冰形体积和主要特征等方面基本一致.研究显示:在结冰的初始阶段,翼型前缘的冰形较规则,随着结冰时间的增加,冰形逐渐变得不规则;翼型下表面冰体前部为明冰,冰体后部、尤其是结冰极限附近则呈现典型的霜冰特征;翼型上表面的结冰范围远小于下表面,在结冰极限附近也不再有明显的霜冰.



  • [1] Frank T L,Abdollah K.Effects of ice accretions on aircraft aerodynamics[J].Progress in Aerospace Sciences,2001,37(8):669-767.
    [2] Bragg M B,Broeren A P,Blumenthal L A.Iced-airfoil aerodynamics [J].Progress in Aerospace Sciences,2005,41(5):323-362.
    [3] Kind R J,Potapczuk M G.Experimental and computational simulation of in-flight icing phenomena [J].Progress in Aerospace Sciences,1998,34(5-6):275-345.
    [4] Cebeci T,Kafyeke F.Aircraft icing[J].Annual Review of Fluid Mechanics,2003,35(1):11-21.
    [5] Potapczuk M G.A review of NASA Lewis’ development plans for computational simulation of aircraft icing .AIAA-99-0243,1999.
    [6] Wright W B.Users manual for the improved NASA Lewis ice accretion code LEWICE 1.6 .NASA CR 198355, 1995.
    [7] Wright W B.User manual for the NASA Glenn ice accretion code LEWICE Version 2.0 .NASA CR 209409, 1999.
    [8] Ghenai C,Kulkarni S,Lin C X.Validation of LEWICE 2.2 icing software code:comparison with LEWICE 2.0 and experimental data .AIAA-2005-1249,2005.
    [9] Wright W B.Validation results for LEWICE 3.0 .AIAA-2005-1243,2005.
    [10] Shin J,Bond T H.Results of an icing test on a NACA0012 airfoil in the NASA Lewis Icing Research Tunnel .AIAA-92-0647,1992.
    [11] 易贤.飞机积冰的数值计算与积冰试验相似准则研究 .绵阳:中国空气动力研究与发展中心,2007. YI Xian.Numerical computation of aircraft icing and study on icing test scaling law .Mianyang:China Aerodynamics Research and Development Center,2007.(in Chinese)
    [12] Langmuir I,Blodgett K.A mathematical investigation of water droplet trajectories .Army Air Force Technical Report No.5418,1946.
    [13] 易贤,桂业伟,朱国林.飞机三维结冰模型及其数值求解方法[J].航空学报,2010,31(11):2152-2158. YI Xian,GUI Yewei,ZHU Guolin.Numerical method of a three-dimensional ice accretion model of aircraft[J].Acta Aeronautica et Astronautica Sinica,2010,31(11):2152-2158.(in Chinese)
