一种基于热管理的热端部件轻量化研究

付德斌; 丁水汀; 陶智; 李果; 张弓; 李烨

一种基于热管理的热端部件轻量化研究

北京航空航天大学能源与动力工程学院航空发动机气动热力国家级重点实验室,北京 100191

计量
- 文章访问数: 1712
- HTML浏览量: 103
- PDF量: 18
- 被引次数: 0
出版历程
- 收稿日期: 2010-03-26
- 修回日期: 2010-07-05
- 刊出日期: 2011-04-28

Study on heated components mass reduction based on thermal management

National Key Laboratory of Science and Technology on Aero-Engine Aero-thermodynamics, School of Jet Propulsion,Beijing University of Aeronautics and Astronautics, Beijing 100191,China

摘要

摘要: 基于对航空发动机使用热管理的思路,采用单向流固耦合(fluid structure interaction,FSI)算法,在等冷气耗量条件下,对旋转轮盘内应力水平与其盘心开槽加热及轻量化的关联性进行了计算研究.在转速为10000r/min,盘腔冷却空气进出口边界条件、盘内外缘加热热流密度均保持不变的条件下,借鉴双辐板盘的拓扑结构,在盘心开不同大小的加热槽,研究盘内等效应力水平随盘心加热槽结构变化的规律.结果表明:通过盘心开槽加热方式,可以得到盘内温度场的U型分布,盘内应力水平得以有效降低,说明了盘内应力水平与盘心开槽加热的方式和大小存在着较强的关联性,在保证航空发动机整体气动性能、涡轮盘性能和使用寿命的前提下,探索通过对涡轮盘的主动热管理,实现对热端部件的显著轻量化是值得预期的.
- 热管理 /
- 轻量化 /
- 应力水平 /
- 旋转轮盘 /
- 温度分布
Abstract: The relationship between stress level and disk mass reduction in a rotating disk with heat channel and warming-up in disk root at a fixed flux of cooling air was numerically studied,by using fluid structure interaction (FSI) method based on the thermal management for heated components.The regulation between stress level and disk mass reduction was studied under the boundary condition of disk space and the heat flux of different heat channel configurations’ fixed condition.The rotating speed was also fixed at 10000r/min.Numerical results reveal that there exists a strong relevance between stress level and the construction of heat channel and heat flux.By heating the disk root,the U-temperature distribution can reduce the disk stress level.It means that the method of active thermal management can achieve the disk mass reduction,while guaranteeing the performance of aero-engine and working life.
- thermal management /
- mass reduction /
- stress level /
- rotating disk /

HTML

参考文献(12)

[1]	姜旭峰,彭著良,费逸伟.航空发动机减重技术研究[J].航空维修与工程,2005(1):54-56. JIANG Xufeng,PENG Zhuliang,FEI Yiwei.The study on aero-engine reducing weight techniques[J].Aviation Maintenance & Engineering,2005(1):54-56.
[2]	江义军.推重比12~15发动机技术途径分析[J].航空动力学报,2001,16(2):103-107. JIANG Yijun.Technical approaches to thrust-weight ratio 12~15 of aeroengine[J].Journal of Aerospace Power,2001,16(2):103-107.(in Chinese)
[3]	吴学辉,程邦勤,陶增元.推重比10一级发动机技术改进方案分析[J].航空动力学报,2005,20(1):38-43. WU Xuehui,CHENG Bangqin,TAO Zengyuan.Technical improvement scheme analysis of thrust-weight ratio 10 aeroengine[J].Journal of Aerospace Power,2005,20(1):38-43.(in Chinese)
[4]	U.S.Department of Transportation.Advisory circular .2005-04-29.http://wenku.baidu.com/view/79a0f20f7cd184254b3535bd.html.
[5]	尹泽勇.航空发动机设计手册(第18册)[M].北京:航空工业出版社,2001.
[6]	苏清友.航空涡喷、涡扇发动机主要零部件定寿指南[M].北京:航空工业出版社,2004.
[7]	杨兴宇,阎晓军,赵福星,等.某型航空发动机涡轮盘低循环疲劳寿命分析[J].机械强度,2004,26(z1):229-233. YANG Xingyu,YAN Xiaojun,ZHAO Fuxing,et al.Low cycle fatigue life of an aeroengine gas turbine disk[J].Journal of Mechnical Strength,2004,26(z1):229-233.(in Chinese)
[8]	Matthew E M,Erwin V Z,Richard A.Probabilistic analysis of aircraft gas turbine disk life and reliability .AIAA-97-10714,1997.
[9]	Michael T T,Ian H,Louis J G.A computer code for gas turbine engine weight and disk life estimation[J].Journal of Engineering for Gas Turbines and Power,2004,126(2):265-270.
[10]	范钦珊.轴对称应力分析[M].北京: 高等教育出版社,1985.
[11]	付德斌,丁水汀,陶智.旋转盘应力水平与温度分布的关联分析[J].航空动力学报,2008,23(4):623-628. FU Debin,DING Shuiting,TAO Zhi.Analysis of the effects of temperature distribution on stress level in a rotation disk[J].Journal of Aerospace Power,2008,23(4):623-628.(in Chinese)
[12]	江和甫.对涡轮盘材料的需求及展望[J].燃气涡轮试验与研究,2002,15(4):1-6. JIANG Hepu.Requirements and forecast of turbine disk materials[J].Gas Turbine Experiment and Research,2002,15(4):1-6.(in Chinese)
