多相等离子体气动激励抑制翼型 失速分离的实验
Experimental investigation on airfoil stall separation suppression by multiphase plasma aerodynamic actuation
-
摘要: 开展了多相等离子体气动激励抑制NACA0015翼型失速分离的实验,详细研究了翼型升阻特性随激励电压、激励相角、输入电压波形和占空比等激励参数的影响.研究表明:雷诺数Re=4.9×105(来流速度60m/s)时,多相等离子体气动激励可有效抑制NACA0015翼型吸力面的流动分离,将翼型临界失速攻角提高2°;相位对流动控制效果的影响不大;电压幅值和占空比必须达到一定的阈值才能有效抑制流动分离;流动分离被抑制后,维持流动保持附着状态所需的激励电压幅值可以显著降低.研究为揭示多相等离子体流动控制作用机理奠定了基础.
-
关键词:
- 等离子体流动控制 /
- 多相等离子体气动激励 /
- 翼型 /
- 失速分离 /
- 升阻特性
Abstract: Experiments on NACA0015 airfoil stalling separation control based on multiphase plasma aerodynamic actuation were performed in the paper.The effects of the plasma actuation voltage amplitude,phase,input waveform and duty cycle on the lift and drag of the airfoil were examined specifically.The results show that,when the Reynolds number is 4.9 ×105,multiphase plasma aerodynamic actuation can suppress flow separation very well.The critical stalling attack angle of NACA0015 airfoil can increase by 2°.The flow suppression effect is not sensitive to phase difference.The separated flow can be suppressed when the voltage amplitude and duty cycle reach their threshold values.Once the separated flow is suppressed,the actuation voltage magnitude maintaining flow attachment could be reduced significantly.The research can lay a foundation for the mechanism of multiphase plasma flow control. -
[1] 马清源.多相等离子体气动激励及其抑制翼型失速分离的实验研究 .西安:空军工程大学,2009. MA Qingyuan.Experimental research on airfoil stalling separation control based on multiphase plasma aerodynamic actuation .Xi’an:Air Force Engineering University,2009.(in Chinese) [2] 梁华.翼型等离子体流动控制研究 .西安:空军工程大学,2009. LIANG Hua.Airfoil flow control base on plasma aerodynamic actuation .Xi’an:Air Force Engineering University,2009.(in Chinese) [3] 李应红,梁华,马清源,等.脉冲等离子体气动激励抑制翼型吸力面流动分离的实验研究[J].航空学报,2008,29(6):1429-1435. LI Yinghong,LIANG Hua,MA Qingyuan,et al.Experimental investigation on airfoil suction side flow separation suppression by pulse plasma aerodynamic actuation [J].Acta Aeronautica et Astronautica Sinica,2008,29(6):1429-1435.(in Chinese) [4] WANG Jian,LI Yinghong,CHENG Bangqing,et al.Effects of plasma aerodynamic actuation on oblique shock wave in a cold supersonic flow [J].Journal of Physics D:Applied Physics,2009,42(1):1-8. [5] WU Yun,LI Yinghong,JIA Ming,et al.Influence of operating pressure on surface dielectric barrier discharge plasma aerodynamic actuation characteristics[J].Applied Physics Letters,2008,93(3):1-3. [6] Roth J R,Sherman D M,Wilkinson S P.Boundary layer flow control with a one atmosphere uniform glow discharge surface plasma .AIAA 98-0328,1998. [7] Roth J R,Tsai P P,Liu C Y,et al.One atmosphere uniform glow discharge plasma:US,5414324 .1995-05-09. [8] Hojung Sin,Roth J R.A polyphase power supply and peristaltic flow accelerator system using a OAUGDP .Knoxville:The University of Tennessee,2002. [9] Grundmann S,Tropea C.Experimental transition delay using glow-discharge plasma actuators[J].Experiments in Fluids,2007,42(4):653-657. [10] Roupassov D V,Nikipelov A A,Nudnova M M,et al.Flow separation control by plasma actuator with nanosecond pulsed-periodic discharge[J].AIAA Journal,2009,47(1):168-185. [11] Roth J R,Sin H,Madhan R C M,et al.Flow reattachment and acceleration by paraelectric and peristaltic electrohydrodynamic(EHD) effects .AIAA 2003-0531,2003. [12] Roth J R,Madhan R C M,Yadav M,et al.Flow field measurements of paraelectric,peristaltic and combined plasma actuators based on the one atmosphere uniform glow discharge plasma (OAUGDPTM) .AIAA 2003-0845,2003. [13] Roth J R.Aerodynamic flow acceleration using paraelectric and peristaltic electrohydrodynamic effects of one atmosphere uniform glow discharge plasma[J].Physics of Plasmas,2003,10(5):2117-2126. [14] Madhan R C M.Boundary layer flow acceleration by paraelectric and peristaltic EHD effects of aerodynamic plasma actuators .Knoxville:The University of Tennessee, 2004. [15] Roth J R,Dai X,Rahel J,et al.The physics and phenomenology of paraelectric one atmosphere uniform glow discharge plasma (OAUGDPTM) actuators for aerodynamic flow control .AIAA 2005-0781,2005.
